Texas Instruments AM1810 User manual

AM1810 Evaluation Module (EVM)

Quick Start Guide

For more information:

www.ti.com/am1810

For more information on the AM1810

processor or to download the latest

software, please visit:

www.ti.com/am1810.

For support questions, please contact:

support.ti.com or www.ti.com/e2e.

Important Notice: The products and services of Texas Instruments Incorporated

and its subsidiaries described herein are sold subject to TI’s standard terms and

conditions of sale. Customers are advised to obtain the most current and complete

information about TI products and services before placing orders. TI assumes no

liability for applications assistance, customer’s applications or product designs,

software performance, or infringement of patents. The publication of information

regarding any other company’s products or services does not constitute TI’s

approval, warranty or endorsement thereof.

Trademarks in this issue: The platform bar and Sitara are trademarks of Texas

Instruments. All other trademarks are the property of their respective owners.

SPRT591B

513310-0001 Rev B

Troubleshooting

• If you are having trouble accessing the

demos on the included SD card, try the

following:

•

•Verify DIP switches 6 and 7 on S7 are set

to ON and all others are set to OFF.

Printed in U.S.A. by (Printer, City, State)

The following items will be used in this Quick Start Guide.

Baseboard, AM1810, 4.3” LCD,

PROFIBUS Daughter Card

(pre-assembled)

Ethernet

cable

USB SD

card reader

Important baseboard locations

(Numbers correspond to the steps on the right.)

Serial

cable

Power supply,

US cord, and

universal AC adapter

(use AC adapter

for regions outside

the US)

* See back of board

SD card

(Linux™

SDK)

Sitara™

514232-0001A

SPRW210

AM1810 EVM

Linux SDK

Congratulations on your purchase of the AM1810 EVM and welcome to the Quick Start Guide.

This guide

is designed to help you through the initial setup of your EVM. The EVM provides

a product-ready hardware

and software platform for evaluating the functionality of the Texas

Instruments (TI) AM1810 processor.

Next steps

To prepare your work-

station for software devel-

opment, power off the kit,

remove the SD card and

insert into the included

USB SD card reader

Quick start setup (OS demo)

7You are now ready to

explore the application

launcher which con-

tains various example

applications and demos.

Matrix GUI shown

1Verify DIP switches 6

and 7 on S7 are set to

ON and all others are

set to OFF

2Connect the supplied

serial cable to the

UART-1/2 DB-9

connector. Connect the

other end of the cable

to a PC or workstation

4Insert the Linux SDK

SD card in the AM1810

EVM SD slot on back

of board

6Switch power on

5Connect power to

baseboard

3Connect Ethernet cable

to the RJ-45 jack on

the board. Connect the

other end to a router or

Ethernet switch

Connect the USB SD card

reader into your Linux™-

based PC, locate the START

HERE folder on the SD

card and view setup.htm.

The setup.htm ﬁle includes

the software development

guide which will provide

information to guide you

through the software

installation.

(Continued on following page)
