StarTech.com PEX100SFP System manual

PCI Express 10/100 Mbps Ethernet Fiber SFP PCIe Network Card Adapter NIC

StarTech ID: PEX100SFP

The PEX100SFP PCI Express 10/100 Mbps Ethernet Fiber Open SFP Network Card lets you connect a PCI

Express-based PC directly to a fiber optic network using the 10/100 Mbps SFP of your choice.

A versatile solution for connecting a computer directly to a 10/100 Mbps fiber network, the PCIe SFP network

adapter enables you to choose the 10/100 Mbps SFP that best suits your network fiber connection and distance

requirements (see our full line of 100 Mbps transceivers for compatible solutions).

Ideal for secure network setups, the open SFP NIC offers a direct fiber connection which is not susceptible to

electronic interference like standard RJ45 networks.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Ideal for secure setups - a direct fiber connection means no electronic interference, which can be a problem

with RJ45 network cards

Perfect for remote embedded industrial monitoring systems, and high speed video surveillance

Retain full 100 Mbps network speeds to a remote terminal over long distances

intrl.startech.com

Features

PCI Express SFP network card

Supports Full/Half-duplex Auto-Negotiation, Auto-MDI/MDIX

Compliant with IEEE 802.3u 100Base-FX, IEEE802.1Q VLAN Tagging, IEEE802.1p Layer 2 Priority

Encoding, IEEE 802.3x full duplex flow control, RFC 1157 SNMP v1

Supports PCI Message Signaled Interrupt (MSI)

Preboot Execution Environment (PXE) 2.1

Cable diagnostic utility

intrl.startech.com

Technical Specifications

Warranty 2 Years

Bus Type PCI Express

Card Type Low Profile

Chipset ID Realtek - RTL8168B; Marvell - 88E1111-RCJ1

Industry

Standards

IEEE 802.3u 100Base-FX, IEEE802.1Q VLAN Tagging, IEEE802.1p Layer 2 Priority

Encoding, IEEE 802.3x full duplex flow control, RFC 1157 SNMP v1

Ports 1

Connector

Type(s)

1 - PCI Express x1

Auto MDIX Yes

Buffer Size 48 KB

Compatible

Networks

10/100 Mbps

Full Duplex

Support

Yes

Maximum Data

Transfer Rate

200 Mbps (Full-Duplex)

OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), 2000

Windows® Server 2008 R2, 2003(32/64)

Linux 2.4.x/ 2.6.x

Product Height 3.1 in [80 mm]

Product Length 4.5 in [115 mm]

Product Weight 1.5 oz [42 g]

Product Width 0.8 in [20 mm]

LED Indicators 1 - Activity (Yellow)

LED Indicators 1 - Link (Green)

Power

Consumption

2.3 W Max

Humidity 5~95% RH (Non-condensing)

Operating

Temperature

0°C to 45°C (32°F to 113°F)

Storage

Temperature

-10°C to 70°C (14°F to 158°F)

Note Fiber data transfer speeds and distances are dependent on the SFP used (sold separately)

Shipping

(Package) Weight

6.5 oz [185 g]

intrl.startech.com

Included in

Package

1 - PCI Express Open SFP Network Card

Included in

Package

1 - Driver CD

Included in

Package

1 - Instruction Manual (on CD)

Certifications, Reports and Compatibility

intrl.startech.com
