Sound Ryder Free Wheelin User manual

USER GUIDE

FreeWheelin is the world’s most advanced stereo audio system worn on helmets

by cyclists, skiers, skaters, construction workers, equestrians and more. It also functions as

a high quality speakerphone for vehicle or desktop. Freedom to use your Bluetooth

speakers on helmets, in the car, or in the office is really what Bluetooth freedom —

or FreeWheelin — is all about!

• Installs easily on most recreational and safety helmets (Fits youth and adult-sized open face

half helmets including highly vented helmets — does not t full-face helmets)

• Works with any portable audio source including iPod, iPhone, smartphones, and MP3 players

— any device with a 3.5mm speaker/headphone port or Bluetooth compatibility

• Makes and receives phone calls while in Bluetooth mode using any iPhone or Bluetooth

enabled smartphone

• Safe and legal — unlike ear buds, FreeWheelin does not insert or cover the ears — ambient

sounds (car horns, sirens, etc.) may still be heard

• Lightweight amplier delivers powerful sound through dynamic miniature stereo speakers

• Control your music or receive phone calls using easy access buttons

• Dual mode — wired (cable) or wireless (Bluetooth)

• Rechargeable 450mAh lithium polymer battery provides up to 15 hrs. music or 10 hrs.

talk time

• Durable water resistant construction (not water proof)

• Bonus feature — unique visor clip accessory converts FreeWheelin into hands-free speaker-

phone for vehicle or desktop

iPod, iPhone, and SIRI are trademarks of Apple, Inc., registered in the U.S. and other countries.

PACKAGE CONTENTS

• FreeWheelin Bluetooth amp (1)

• FreeWheelin left/right speaker communication pods (2)

• 3.5mm audio cable for wired mode (48”)

• USB charge cable — Type A USB to 3.5mm plug (36”)

• Dual Lock pads — self-adhesive for helmet application (3)

• Amp Dual Lock adapter — for helmets with pointed backs (1)

•Visor clip accessory — for vehicle or desktop use (1)

• User guide

CHARGING FREEWHEELIN

1) Use included USB charge cable

2) Connect USB cable to any open USB port on computer

3) For faster charge connect to USB/AC wall adapter

4) Insert 3.5mm plug into 3.5mm port located at base of FreeWheelin amp (Figure A)

5) LED indicator illuminates red while charging (Figure A)

6) LED indicator shuts off when FreeWheelin is fully charged in about 1.5 hours

LED indicator

Charging port

INSTALLING FREEWHEELIN TO HELMET

1) Locate 3 pieces of Dual Lock to be applied

to helmet exterior

2) Locate installation point for the

FreeWheelin amp along rear of the helmet

3) Apply 1” square Dual Lock at this location

and press rmly for 20-30 seconds. Do not

apply Dual Lock to the Styrofoam portion

of the helmet

4) For helmets with a pointed back — use

amp Dual Lock adapter (included)

5) Locate left/right ear level installation points

for placement of FreeWheelin speaker pods

6) Apply ½" x 2" Dual Lock strips along left/

right locations and press for 20-30 seconds

7) Position FreeWheelin amp over Dual Lock

at rear helmet location and press on

8) Position FreeWheelin speaker pods over

Dual Lock along left/right sides and press on

Installation Notes: The amp adapter (Dual Lock with rubber square) provides a at area for attaching the amp on

helmets with pointed backs. Be sure area is completely dry and clean of all dirt, oil, etc. before installing Dual Lock.

To allow proper bond strength for Dual Lock adhesive, do not remove FreeWheelin amp/speaker pods for 24-48 hours

when rst applied to the helmet. Removing FreeWheelin components sooner may result in Dual Lock strips coming loose.

The amp doesn’t require a large contact area, so if the Dual Lock is only partially making at contact, you will nd it is

still secure.

Dual Lock

PAIRING FREEWHEELIN WITH BLUETOOTH DEVICE

1) Make sure FreeWheelin is powered o

2) Prepare your device for Bluetooth pairing mode (do not initiate yet)

3) Locate Multi Function Button (MFB) atop left FreeWheelin speaker pod

4) Press and hold FreeWheelin power button — blue LED illuminates

5) Continue to hold until LED ashes blue/red — FreeWheelin is ready to pair with your device

6) Initiate pairing mode on your device and it will recognize FreeWheelin — then ask it to pair

7) There is no code # to enter — when paired, the blue/red LED changes to ashing blue

8) FreeWheelin is now powered on and is paired with your device

9) Play music on your device and it will play through the

FreeWheelin speakers

Note: See Figure A for location of controls used in the following instructions.

Power button

LED Indicator

Figure A

PAIRING NOTES

1) Make sure FreeWheelin is turned o

2) Press & hold the MFB button

3) Continue holding the MFB button and press & hold the FORWARD button

4) In about 8 seconds the LED indicator illuminates pink

5) Pairing memory has now erased

FreeWheelin pairing mode lasts 2 minutes — make sure your Bluetooth device is ready to initiate.

If pairing is unsuccessful, repeat steps 1-7.

If you have paired many devices with FreeWheelin and experience pairing problems with new devices,

you may have reached the maximum number of paired devices.

FreeWheelin pairs up to eight unique devices that are stored in its pairing memory. If you have new

devices that you want to pair and have already paired 8 other devices, you can erase all devices from

memory in the following steps:

This procedure erases all devices from memory. It does not erase single devices. You can now re-pair any

of your original or pair new devices (up to 8 total).

USING AUDIO CABLE FOR WIRED CONNECTION

POWERING FREEWHEELIN’ ON/OFF

1) Insert 3.5mm audio cable into any audio device having a 3.5mm stereo output/headphone port

2) Insert opposite end of 3.5 audio cable into 3.5mm port located at base of FreeWheelin amp

(the charging port is also the audio cable port)

3) FreeWheelin automatically powers ON and LED illuminates (no need to press power button)

4) Play music from audio device

5) Remove cable to automatically power OFF FreeWheelin and save battery power

BLUETOOTH (WIRELESS) MODE

1) ON: press/hold FreeWheelin power button on left speaker pod for 3 seconds — LED illuminates

2) OFF: press/hold FreeWheelin power button for 3 seconds — LED shuts o

CABLE (WIRED) MODE

1) ON: insert 3.5mm audio cable into 3.5mm port located on FreeWheelin amp — LED illuminates

2) OFF: remove 3.5mm audio cable from FreeWheelin amp — LED shuts o

FREEWHEELIN CONTROLS OVERVIEW

MULTIFUCTION BUTTON (MFB)

• POWER ON

• POWER OFF

• PLAY

• PAUSE

• ANSWER CALL

• END CALL

• REJECT CALL

• MICROPHONE

LED INDICATOR

• BATTERY LEVEL

• CHARGING

• PAIRING

• BLUETOOTH CONNECT

• PHONE CALL STATUS

BACK BUTTON

• VOLUME DOWN

• PREVIOUS TRACK

FORWARD BUTTON

• VOLUME UP

• NEXT TRACK

PLAYING MUSIC

MAKING CALLS

FIGURE A

MULTI FUNCTION BUTTON (MFB)

- POWER ON

- POWER OFF

- PLAY

- PAUSE

- ANSWER CALL

- END CALL

- REJECT CAL

FORWARD BUTTON

- VOLUME UP

- NEXT TRACK

BACK BUTTON

- VOLUME DOWN

- PREVIOUS TRACK

LED INDICATOR

- BATTERY LEVEL

- CHARGING

- PAIRING

- BLUETOOTH CONNECT

- PHONE CALL STATUS

PLAYING MUSIC

FUNCTION

OPERATION

DEVICE STATUS

INDICATION

PLAY

SHORT PRESS MFB BUTTON

MUSIC PLAYING

SHORT AUDIBLE TONE

PAUSE

SHORT PRESS MFB BUTTON

MUSIC PAUSED

SHORT AUDIBLE TONE

VOLUME UP

SHORT PRESS FORWARD BUTTON

VOLUME INCREASES WHEN MUSIC

IS PLAYING

SHORT AUDIBLE TONE WHEN MAX

VOLUME IS REACHED

VOLUME DOWN

SHORT PRESS BACK BUTTON

VOLUME DECREASES WHEN MUSIC

IS PLAYING

SHORT AUDIBLE TONE WHEN MIN

VOLUME IS REACHED

NEXT TRACK

PRESS FORWARD BUTTON 2

SECONDS AND RELEASE

MUSIC ADVANCES TO NEXT TRACK

SHORT AUDIBLE TONE

PREVIOUS TRACK

PRESS BACK BUTTON 2 SECONDS /

RELEASE / PRESS 2 SECONDS

MUSIC ADVANCES TO PREVIOUS

TRACK

SHORT AUDIBLE TONE

MAKING CALLS

FUNCTION

OPERATION

DEVICE STATUS

INDICATION

VOICE DIAL OR USE SIRI ON IPHONE

PRESS MFB BUTTON FOR 2

SECONDS

READY TO RECEIVE VOICE

INSTRUCTIONS

SHORT AUDIBLE TONE

ANSWER CALL

SHORT PRESS MFB BUTTON

NGING-MUSIC FADES IF PLAYING

SHORT AUDIBLE TONE

END CALL

SHORT PRESS MFB BUTTON

CALL ENDS –MUSIC RETURNS IF

PLAYING

SHORT AUDIBLE TONE

REJECT CALL

PRESS MFB BUTTON 2 SECONDS

AND RELEASE

CALL WILL NOT BE ANSWERED –

MUSIC CONTINUES TO PLAY

SHORT AUDIBLE TONE

VOLUME UP

SHORT PRESS FORWARD BUTTON

CALL VOLUME INCREASES

SHORT AUDIBLE TONE WHEN MAX

VOLUME IS REACHED

VOLUME DOWN

SHORT PRESS BACK BUTTON

CALL VOLUME DECREASES

SHORT AUDIBLE TONE WHEN MIN

VOLUME IS REACHED

MUTE MICROPHONE

PRESS MFB BUTTON QUICKLY 2X

MICROPHONE MUTES DURING

PHONE CONVERSATIONS

SHORT AUDIBLE TONE EVERY 5

SECONDS

CANCEL MICROPHONE MUTE

PRESS MFB BUTTON QUICKLY 2X

CANCELS MICROPHONE MUTE

DURING PHONE CONVERSATIONS

RECEIVING CALLPARTY CAN HEAR

CONVERSATION

SWITCH CONVERSATIONS BETWEEN

FREEWHEELIN’ AND CELL PHONE

PRESS/HOLD MFB BUTTON AND

RELEASE WHEN AUDIBLE TONE IS

HEARD

CONVERSATION MODE SWITCHES

TO CELL PHONE

SHORT AUDIBLE TONE

STATUS LIGHTS AND TONES

FIGURE A

MULTI FUNCTION BUTTON (MFB)

- POWER ON

- POWER OFF

- PLAY

- PAUSE

- ANSWER CALL

- END CALL

- REJECT CAL

FORWARD BUTTON

- VOLUME UP

- NEXT TRACK

BACK BUTTON

- VOLUME DOWN

- PREVIOUS TRACK

LED INDICATOR

- BATTERY LEVEL

- CHARGING

- PAIRING

- BLUETOOTH CONNECT

- PHONE CALL STATUS

PLAYING MUSIC

FUNCTION

OPERATION

DEVICE STATUS

INDICATION

PLAY

SHORT PRESS MFB BUTTON

MUSIC PLAYING

SHORT AUDIBLE TONE

PAUSE

SHORT PRESS MFB BUTTON

MUSIC PAUSED

SHORT AUDIBLE TONE

VOLUME UP

SHORT PRESS FORWARD BUTTON

VOLUME INCREASES WHEN MUSIC

IS PLAYING

SHORT AUDIBLE TONE WHEN MAX

VOLUME IS REACHED

VOLUME DOWN

SHORT PRESS BACK BUTTON

VOLUME DECREASES WHEN MUSIC

IS PLAYING

SHORT AUDIBLE TONE WHEN MIN

VOLUME IS REACHED

NEXT TRACK

PRESS FORWARD BUTTON 2

SECONDS AND RELEASE

MUSIC ADVANCES TO NEXT TRACK

SHORT AUDIBLE TONE

PREVIOUS TRACK

PRESS BACK BUTTON 2 SECONDS /

RELEASE / PRESS 2 SECONDS

MUSIC ADVANCES TOPREVIOUS

TRACK

SHORT AUDIBLE TONE

MAKING CALLS

FUNCTION

OPERATION

DEVICE STATUS

INDICATION

VOICE DIAL OR USE SIRI ON IPHONE

PRESS MFB BUTTON FOR 2

SECONDS

READY TO RECEIVE VOICE

INSTRUCTIONS

SHORT AUDIBLE TONE

ANSWER CALL

SHORT PRESS MFB BUTTON

NGING-MUSIC FADES IF PLAYING

SHORT AUDIBLE TONE

END CALL

SHORT PRESS MFB BUTTON

CALL ENDS –MUSIC RETURNS IF

PLAYING

SHORT AUDIBLE TONE

REJECT CALL

PRESS MFB BUTTON 2 SECONDS

AND RELEASE

CALL WILL NOT BE ANSWERED –

MUSIC CONTINUES TO PLAY

SHORT AUDIBLE TONE

VOLUME UP

SHORT PRESS FORWARD BUTTON

CALL VOLUME INCREASES

SHORT AUDIBLE TONE WHEN MAX

VOLUME IS REACHED

VOLUME DOWN

SHORT PRESS BACK BUTTON

CALL VOLUME DECREASES

SHORT AUDIBLE TONE WHEN MIN

VOLUME IS REACHED

MUTE MICROPHONE

PRESS MFB BUTTON QUICKLY 2X

MICROPHONE MUTES DURING

PHONE CONVERSATIONS

SHORT AUDIBLE TONE EVERY 5

SECONDS

CANCEL MICROPHONE MUTE

PRESS MFB BUTTON QUICKLY 2X

CANCELS MICROPHONE MUTE

DURING PHONE CONVERSATIONS

RECEIVING CALLPARTY CAN HEAR

CONVERSATION

SWITCH CONVERSATIONS BETWEEN

FREEWHEELIN’ AND CELL PHONE

PRESS/HOLD MFB BUTTON AND

RELEASE WHEN AUDIBLE TONE IS

HEARD

CONVERSATION MODE SWITCHES

TO CELL PHONE

SHORT AUDIBLE TONE

STATUS LIGHTS AND TONES

FIGURE A

MULTI FUNCTION BUTTON (MFB)

- POWER ON

- POWER OFF

- PLAY

- PAUSE

- ANSWER CALL

- END CALL

- REJECT CAL

FORWARD BUTTON

- VOLUME UP

- NEXT TRACK

BACK BUTTON

- VOLUME DOWN

- PREVIOUS TRACK

LED INDICATOR

- BATTERY LEVEL

- CHARGING

- PAIRING

- BLUETOOTH CONNECT

- PHONE CALL STATUS

PLAYING MUSIC

FUNCTION

OPERATION

DEVICE STATUS

INDICATION

PLAY

SHORT PRESS MFB BUTTON

MUSIC PLAYING

SHORT AUDIBLE TONE

PAUSE

SHORT PRESS MFB BUTTON

MUSIC PAUSED

SHORT AUDIBLE TONE

VOLUME UP

SHORT PRESS FORWARD BUTTON

VOLUME INCREASES WHEN MUSIC

IS PLAYING

SHORT AUDIBLE TONE WHEN MAX

VOLUME IS REACHED

VOLUME DOWN

SHORT PRESS BACK BUTTON

VOLUME DECREASES WHEN MUSIC

IS PLAYING

SHORT AUDIBLE TONE WHEN MIN

VOLUME IS REACHED

NEXT TRACK

PRESS FORWARD BUTTON 2

SECONDS AND RELEASE

MUSIC ADVANCES TO NEXT TRACK

SHORT AUDIBLE TONE

PREVIOUS TRACK

PRESS BACK BUTTON 2 SECONDS /

RELEASE / PRESS 2 SECONDS

MUSIC ADVANCES TOPREVIOUS

TRACK

SHORT AUDIBLE TONE

MAKING CALLS

FUNCTION

OPERATION

DEVICE STATUS

INDICATION

VOICE DIAL OR USE SIRI ON IPHONE

PRESS MFB BUTTON FOR 2

SECONDS

READY TO RECEIVE VOICE

INSTRUCTIONS

SHORT AUDIBLE TONE

ANSWER CALL

SHORT PRESS MFB BUTTON

NGING -MUSIC FADES IF PLAYING

SHORT AUDIBLE TONE

END CALL

SHORT PRESS MFB BUTTON

CALL ENDS –MUSIC RETURNS IF

PLAYING

SHORT AUDIBLE TONE

REJECT CALL

PRESS MFB BUTTON 2 SECONDS

AND RELEASE

CALL WILL NOT BE ANSWERED –

MUSIC CONTINUES TO PLAY

SHORT AUDIBLE TONE

VOLUME UP

SHORT PRESS FORWARD BUTTON

CALL VOLUME INCREASES

SHORT AUDIBLE TONE WHEN MAX

VOLUME IS REACHED

VOLUME DOWN

SHORT PRESS BACK BUTTON

CALL VOLUME DECREASES

SHORT AUDIBLE TONE WHEN MIN

VOLUME IS REACHED

MUTE MICROPHONE

PRESS MFB BUTTON QUICKLY 2X

MICROPHONE MUTES DURING

PHONE CONVERSATIONS

SHORT AUDIBLE TONE EVERY 5

SECONDS

CANCEL MICROPHONE MUTE

PRESS MFB BUTTON QUICKLY 2X

CANCELS MICROPHONE MUTE

DURING PHONE CONVERSATIONS

RECEIVING CALLPARTY CAN HEAR

CONVERSATION

SWITCH CONVERSATIONS BETWEEN

FREEWHEELIN’ AND CELL PHONE

PRESS/HOLD MFB BUTTON AND

RELEASE WHEN AUDIBLE TONE IS

HEARD

CONVERSATION MODE SWITCHES

TO CELL PHONE

SHORT AUDIBLE TONE

STATUS LIGHTS AND TONES

RINGING - MUSIC FADES IF PLAYING

FIGURE A

MULTI FUNCTION BUTTON (MFB)

- POWER ON

- POWER OFF

- PLAY

- PAUSE

- ANSWER CALL

- END CALL

- REJECT CAL

FORWARD BUTTON

- VOLUME UP

- NEXT TRACK

BACK BUTTON

- VOLUME DOWN

- PREVIOUS TRACK

LED INDICATOR

- BATTERY LEVEL

- CHARGING

- PAIRING

- BLUETOOTH CONNECT

- PHONE CALL STATUS

PLAYING MUSIC

FUNCTION

OPERATION

DEVICE STATUS

INDICATION

PLAY

SHORT PRESS MFB BUTTON

MUSIC PLAYING

SHORT AUDIBLE TONE

PAUSE

SHORT PRESS MFB BUTTON

MUSIC PAUSED

SHORT AUDIBLE TONE

VOLUME UP

SHORT PRESS FORWARD BUTTON

VOLUME INCREASES WHEN MUSIC

IS PLAYING

SHORT AUDIBLE TONE WHEN MAX

VOLUME IS REACHED

VOLUME DOWN

SHORT PRESS BACK BUTTON

VOLUME DECREASES WHEN MUSIC

IS PLAYING

SHORT AUDIBLE TONE WHEN MIN

VOLUME IS REACHED

NEXT TRACK

PRESS FORWARD BUTTON 2

SECONDS AND RELEASE

MUSIC ADVANCES TO NEXT TRACK

SHORT AUDIBLE TONE

PREVIOUS TRACK

PRESS BACK BUTTON 2 SECONDS /

RELEASE / PRESS 2 SECONDS

MUSIC ADVANCES TOPREVIOUS

TRACK

SHORT AUDIBLE TONE

MAKING CALLS

FUNCTION

OPERATION

DEVICE STATUS

INDICATION

VOICE DIAL OR USE SIRI ON IPHONE

PRESS MFB BUTTON FOR 2

SECONDS

READY TO RECEIVE VOICE

INSTRUCTIONS

SHORT AUDIBLE TONE

ANSWER CALL

SHORT PRESS MFB BUTTON

NGING-MUSIC FADES IF PLAYING

SHORT AUDIBLE TONE

END CALL

SHORT PRESS MFB BUTTON

CALL ENDS –MUSIC RETURNS IF

PLAYING

SHORT AUDIBLE TONE

REJECT CALL

PRESS MFB BUTTON 2 SECONDS

AND RELEASE

CALL WILL NOT BE ANSWERED –

MUSIC CONTINUES TO PLAY

SHORT AUDIBLE TONE

VOLUME UP

SHORT PRESS FORWARD BUTTON

CALL VOLUME INCREASES

SHORT AUDIBLE TONE WHEN MAX

VOLUME IS REACHED

VOLUME DOWN

SHORT PRESS BACK BUTTON

CALL VOLUME DECREASES

SHORT AUDIBLE TONE WHEN MIN

VOLUME IS REACHED

MUTE MICROPHONE

PRESS MFB BUTTON QUICKLY 2X

MICROPHONE MUTES DURING

PHONE CONVERSATIONS

SHORT AUDIBLE TONE EVERY 5

SECONDS

CANCEL MICROPHONE MUTE

PRESS MFB BUTTON QUICKLY 2X

CANCELS MICROPHONE MUTE

DURING PHONE CONVERSATIONS

RECEIVING CALLPARTY CAN HEAR

CONVERSATION

SWITCH CONVERSATIONS BETWEEN

FREEWHEELIN’ AND CELL PHONE

PRESS/HOLD MFB BUTTON AND

RELEASE WHEN AUDIBLE TONE IS

HEARD

CONVERSATION MODE SWITCHES

TO CELL PHONE

SHORT AUDIBLE TONE

STATUS LIGHTS AND TONES

Table of contents

Popular Stereo System manuals by other brands

LG CM3330B owner's manual

Sony

Sony SS-CEP50 Service manual

Cetacea Sound

Cetacea Sound CVS-II user guide

Aiwa

Aiwa XR-H66MD operating instructions

Denon

Denon UCD-250 Service manual

Sanyo

Sanyo DC-MX41i instruction manual

Sharp

Sharp CD-ES600V Service manual

Exibel

Exibel BDX600-UK user manual

Sanyo

Sanyo DC-F320 Service manual

Philips

Philips FWM583X Specifications

Sharp

Sharp CD-C462 Service manual

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio instruction manual

Aiwa

Aiwa XR-EM70 Service manual

Cyrus

Cyrus Lyric user guide

Philips

Philips MCM159/98 quick start guide

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C owner's manual

RCA

RCA RS3965SB user manual

Sharp

Sharp XL-UH240 Operation manual
