Sharp XL-UH4H User manual
Black
Red
1
Accessories
Remote control ××
××
×1
92L02700552000
06G R MW 1
3
System connections
"AAA" size battery (UM-4, R03,
HP-16 or similar) ××
××
× 2
2
Remote control battery installation
1Open the battery cover.
2Insert the batteries as shown.
3Close the cover.
Use 2 "AAA" size battery (UM-4, R03, HP-16 or similar).
Wall socket (AC 230 V, 50 Hz)
Left speaker
FM aerial
AM loop aerial
Right speaker
MODEL
XL-UH4H
MICRO COMPONENT SYSTEM
This Quick Start Guide will help you to correctly install and operate your system.
AM loop aerial ××
××
× 1 FM aerial ××
××
× 1
XL-UH4H QG 7/20/06, 12:54 PM1
1Press the ON/STAND-BY button to turn the power on.
2Open the CD compartment.
3Place the disc on the spindle, label side up. 8 cm (3") discs may be
played without an adaptor.
4Close the CD compartment.
5Press the CD 0/ 6button to start playback.
4
Turn on your system
The first time the unit is plugged in, the unit will enter the
power stand-by mode.
1Press the ON/STAND-BY button to turn the power on.
Listening to a CD or MP3/WMA disc
8 cm (3")
Listening to USB/SD mass storage device / MP3 player
1Press the USB/SD 0/ 6button, and push up the USB door. Connect the USB memory device that has MP3/WMA format files on the
unit.
00
00
0
To select USB or SD function, press and hold the USB/SD 0/ 6button for more than 2 seconds.
2Press the TUNING/FOLDER (
44
44
4or 33
33
3
) button to select desired playback folder.
3Select desired track to be played back by pressing the 5 35 3
5 35 3
5 3 or 2 42 4
2 42 4
2 4 button.
4Press the USB/SD 0/ 6button. Playback will start and the track name will be displayed.
//
//
Total number of folders Total number of tracks
WMA MP3
USB
USB indicator SD indicator
or
Open USB door
Insert USB
memory device
Insert SD
memory device
12 cm (5")
XL-UH4H QG 7/20/06, 12:54 PM2
