Sharp SD-CX1H User manual

– 1 –

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

This Quick Guide will help you to correctly

install and operate your system.

SD-CX1H

1-BIT DIGITAL AUDIO SYSTEM

If you require any advice or assistance re-

garding your Sharp product, please visit

our web-site www.sharp.co.uk/support.

Customers without internet access may

telephone 08705 274277 during office

hours (or (01) 676 0648 if telephoning from

Ireland).

Accessories

Non-slip sheet

for speakers × 8

“AA” size battery

(UM/SUM-3, R6, HP-7 or similar) × 2

Remote control × 1 FM aerial × 1

Speaker wire × 2

1 2 3

Battery installation of remote control

Use 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar).

Open the

Insert the batteries

Close the

battery cover.

as shown.

battery cover.

TINSE0353AWZZ A0012.YT

AM loop aerial × 1

AC power lead × 1

– 3 –

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

– 2 –

Web-site: www.sharp.co.uk/support Help Line: 0990 274277 (office hours)

System Connections

Wall socket

(AC 230V, 50 Hz)

FM aerial

Left speaker

Right speaker

To the line

output sockets

RCA lead

(Not supplied)

VCR, DVD, etc.

Left speaker

Clear

Black line

Right speaker

AM loop aerial

Adhere the non-slip

sheets to the bottom

of the speaker.

Adhere the non-slip sheets on

the lower back of the speaker,

and then mount it to the wall.

How to apply non-slip sheet

– 5 –

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

– 4 –

Web-site: www.sharp.co.uk/support Help Line: 0990 274277 (office hours)

Listening to a MiniDisc

1Press the CD HH

Hbutton.

2Press the CD 77

button to open the CD cover.

3Set the CD and press the CD 77

7 button.

4Press the CD 0606

0606

06 button to start playback.

Listening to a CD

Total number of tracks

Turn on your System

The first time the unit is plugged in,

the unit will enter the demonstration

mode.You will see words scroll.

Press the AUX (DEMO)

button to cancel the

demonstration mode.

Press the ON/STAND-

BY button to turn the

power on.

Total playing time

Disc name Total number of

tracks Total playing time

1Open the control panel cover.

Control panel cover

2Press the MD HH

Hbutton.

3Load a MiniDisc into the MD compartment, label side up.

4Press the MD 0606

0606

06 button to start playback.

Label side facing you.

Label side up.

– 6 –

Web-site: www.sharp.co.uk/support Help Line: 0990 274277 (office hours)

■If trouble occurs (reset)

When this product is subjected to strong external interference (mechanical shock, excessive static electricity,

abnormal supply voltage due to lightning, etc.) or if it is operated incorrectly, it may malfunction.

If such a problem occurs, do the following:

Unplug the power lead from the AC socket.Then, plug it in again and retry the operation.

■Before transporting the unit

Remove the CD and MD from the unit.Your unit

checks whether there are any discs inside. "CD

NO DISC" and "MD NO DISC" appear if no disc is

inside. Then, set the unit to the power stand-by

mode. Carrying the unit with discs left inside can

damage it.

1Press theTUNER (BAND) button repeatedly to select the desired frequency

band (FM STEREO, FM or AM).

2Press theTUNING (XX

Xor WW

W) button to tune in to the desired station.

●When the TUNING (Xor W) button is pressed for more than 0.5 seconds, scanning will

start automatically and the tuner will stop at the first receivable broadcast station.

3To receive an FM stereo transmission, press the TUNER (BAND) button.

The“STEREO” indicator lights up.

●“ST” will appear when an FM broadcast is in stereo.

Listening to the Radio
