RADIAL ROCKET 10cc Instruction Manual.

ank you for choosing the RADIAL ROCKET TD 10CC ARTF by SEAGULL MODELS

COMPANY LTD,. e RADIAL ROCKET TD 10CC was designed with the intermedi-

ate/advanced sport yer in mind. It is a semi scale airplane which is easy to y and quick

to assemble. e airframe is onventionally built using balsa, plywood to make it stronger

than the average ARTF, yet the design allows the aeroplane to be kept light. You will nd

that most of the work has been done for you already. e motor mount has been tted

and the hinges are pre-installed. Flying the RADIAL ROCKET TD 10CC is simply a joy.

is instruction manual is designed to help you build a great ying earoplane. Please read

this manual throughly before starting assembly of your RADIAL ROCKET TD 10CC . User

the parts listing below to indentify all parts.

Please be awere that this aeroplane is not a toy and if assembley or used incorrectly it is

capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU

ASSUME ALL RISK & REPONSIBILITY.

If you are inexperianced with basic R/C ight we strongly recommend you contact your R/C

supplier and join your local R/C model Flying Club. R/C Model Flying Clubs oer a variety

of training procedures designed to help the new pilot on his way to successful R/C ight.

ey will also be able to advise on any insurance and safety regulations that may apply.

INTRODUCTION.

WARNING.

KIT CONTENTS

WWW.SEAGULLMODELS.COM

KIT CONTENTS.

SEA229 RADIAL ROCKET TD 10CC

SEA22901 Fuselage

SEA22902 Wing set

SEA22903 Tail set

SEA22904 Canopy

SEA22905 Wheel Spats

SEA22906 Cowling

SEA22907 Aluminium tube

ADDITIONAL ITEMS REQUIRED.

0.82 - 1.0 4-stroke.

10cc gasoline engine.

Computer radio with 7 servos.

Glow plug to suit engine.

Propeller to suit engine.

Protective foam rubber for radio

system.

TOOLS & SUPPLIES NEEDED.

ick cyanoacrylate glue.

30 minute epoxy.

5 minute epoxy.

Hand or electric drill.

Assorted drill bits.

Modelling knife.

Straight edge ruler.

2mm ball driver.

Phillips head screwdriver.

220 grit sandpaper.

90° square or builder’s triangle.

Wire cutters.

Masking tape & T-pins.

read-lock.

Paper towels.

HINGING THE FLAP.

.Hinge.

Note : e control surfaces, including the ai-

lerons, elevators, and rudder, are prehinged

with hinges installed, but the hinges are not

glued in place. It is imperative that you prop-

erly adhere the hinges in place per the steps

that follow using a high-quality thin C/A glue.

1) Carefully remove the aileron from one

of the wing panels. Note the position of the

hinges.

2) Remove each hinge from the wing panel

and aileron and place a T-pin in the center of

each hinge. Slide each hinge into the wing

panel until the T-pin is snug against the wing

panel. is will help ensure an equal amount

of hinge is on either side of the hinge line

when the aileron is mounted to the aileron.

3) Slide the wing panel on the aileron until

there is only a slight gap. e hinge is now

centered on the wing panel and aileron. Re-

move the T-pins and snug the aileron against

the wing panel. A gap of 1/64” or less should

be maintained between the wing panel and

aileron.

RADIAL ROCKET 10cc Instruction Manual.

HINGING THE AILERON.

Epoxy.

Hinge.

T-pin.

4) Deect the aileron and completely satu-

rate each hinge with thin C/A glue. e ailer-

ons front surface should lightly contact the

wing during this procedure. Ideally, when

the hinges are glued in place, a 1/64” gap or

less will be maintained throughout the lengh

of the aileron to the wing panel hinge line.

NOTE : e hinge is constructed of a spe-

cial material that allows the C/A to wick

or penetrate and distribute throughout

the hinge, securely bonding it to the wood

structure of the wing panel and aileron.

5) Turn the wing panel over and deect the

aileron in the opposite direction from the

opposite side. Apply thin C/A glue to each

hinge, making sure that the C/A penetrates

into both the aileron and wing panel.

6) Using C/A remover/debonder and a pa-

per towel, remove any excess C/A glue that

may have accumulated on the wing or in the

aileron hinge area.

7) Repeat this process with the other wing

panel, securely hinging the aileron in place.

8) Aer both ailerons are securely hinged,

rmly grasp the wing panel and aileron to

make sure the hinges are securely glued and

cannot be pulled out. Do this by carefully ap-

plying medium pressure, trying to separate

the aileron from the wing panel. Use caution

not to crush the wing structure.

Work the aileron up and down sev-

eral times to “work in” the hinges

and check for proper movement.

Note :

Note : e control surfaces, including the ai-

lerons, elevators, and rudder, are prehinged

with hinges installed, but the hinges are not

glued in place. It is imperative that you prop-

erly adhere the hinges in place per the steps

that follow using a high-quality thin C/A glue.

1) Carefully remove the aileron from one

of the wing panels. Note the position of the

hinges.

2) Remove each hinge from the wing panel

and aileron and place a T-pin in the center of

each hinge. Slide each hinge into the wing

panel until the T-pin is snug against the wing

panel. is will help ensure an equal amount

of hinge is on either side of the hinge line

when the aileron is mounted to the aileron.

WWW.SEAGULLMODELS.COM

3) Slide the wing panel on the aileron until

there is only a slight gap. e hinge is now

centered on the wing panel and aileron. Re-

move the T-pins and snug the aileron against

the wing panel. A gap of 1/64” or less should

be maintained between the wing panel and

aileron.

Hinge.

4) Deect the aileron and completely satu-

rate each hinge with thin C/A glue. e ailer-

ons front surface should lightly contact the

wing during this procedure. Ideally, when

the hinges are glued in place, a 1/64” gap or

less will be maintained throughout the lengh

of the aileron to the wing panel hinge line.

NOTE : e hinge is constructed of a spe-

cial material that allows the C/A to wick

or penetrate and distribute throughout

the hinge, securely bonding it to the wood

structure of the wing panel and aileron.

Epoxy.

5) Turn the wing panel over and deect the

aileron in the opposite direction from the

opposite side. Apply thin C/A glue to each

hinge, making sure that the C/A penetrates

into both the aileron and wing panel.

6) Using C/A remover/debonder and a pa-

per towel, remove any excess C/A glue that

may have accumulated on the wing or in the

aileron hinge area.

7) Repeat this process with the other wing

panel, securely hinging the aileron in place.

8) Aer both ailerons are securely hinged,

rmly grasp the wing panel and aileron to

make sure the hinges are securely glued and

cannot be pulled out. Do this by carefully ap-

plying medium pressure, trying to separate

the aileron from the wing panel. Use caution

not to crush the wing structure.

Work the aileron up and down sev-

eral times to “work in” the hinges

and check for proper movement.

Note :

HINGING THE ELEVATORS.

1) Locate the items for this section of the

manual.

RADIAL ROCKET 10cc Instruction Manual.

INSTALL THE AILERONS CONTROL

HORN.

Fiberglass control horn

Epoxy.

Aileron control horn.

2) Carefully remove the elevator from

one of the horizontal stabilizer panels.

Note the position of the hinges.

3) Remove each hinge from the hori-

zontal stabilizer panel and elevator

and place a T-pin in the center of each

hinge. Slide each hinge into the eleva-

tor until the T-pi n is snug against the

elevator. is will help ensure an equal

amount of hinge is on either side of the

hinge line when the elevator is mount-

ed to the horizontal stabilizer panel.

Glue the hinge hinges in place using the

same techniques used to hing the ailerons.

HINGING THE RUDDER.

Glue the rudder hinges in place using

the same techniques used to hinge the ai-

lerons.

WWW.SEAGULLMODELS.COM

INSTALL FLAP CONTROL HORN.

Install the ap control horn using the

same method as same as the aileron con-

trol horns.

Fiberglass control horn.

Epoxy.

INSTALL ELEVATOR CONTROL HORN.

Fiberglass control horn.

Epoxy.

Elevator berglass control horn.

Epoxy.

INSTALL RUDDER CONTROL HORN.

Repeat steps to install the rudder control

horn as same as steps done for ailerons.

Fiberglass control horn

Epoxy.

Rudder berglass control horn.

RADIAL ROCKET 10cc Instruction Manual.

INSTALLING THE FUSELAGE SERVOS.

Because the size of servos dier, you

may need to adjust the size of the precut

opening in the mount. e notch in the

sides of the mount allow the servo lead to

pass through.

1) Install the rubber grommets and brass

collets onto the throttle servo. Test t the

servo into the aileron servo mount.

2) Secure the servos with the screws pro-

vided with your radio system.

Rudder servo.

Elevator servo.

rottle servo.

THROTTLE SERVO ARM

INSTALLATION.

Install adjustable servo connector in the

servo arm as same as picture below:

Servo arm.

Adjustable servo

connector.

Loctite secure.

rottle servo arm.

INSTALLING THE SWITCH RECEIVER.

Install the switch into the precut hole in

the side, in the fuselage.

3/32” Hole.

Trim and cut.

Switch.

INSTALLING THE SWITCH ENGINE.

Trim and cut.

WWW.SEAGULLMODELS.COM

Switch.

INSTALLING THE STOPPER

ASSEMBLY.

1) Using a modeling knife, carefully cut

o the rear portion of one of the 3 nylon

tubes leaving 1/2” protruding from the

rear of the stopper. is will be the fuel

pick up tube.

2) Using a modeling knife, cut one length

of silicon fuel line. Connect one end of

the line to the weighted fuel pick up and

the other end to the nylon pick up tube.

Vent tube. Fuel pick up tube.

Fuel fill tube.

3) Carefully bend the second nylon tube up

at a 45º angle. is tube is the vent tube.

4) Test t the stopper assembly into the tank.

It may be necessary to remove some of the

ashing around the tank opening using a

modeling knife. If ashing is present, make

sure none falls into the tank.

5) With the stopper assembly in place, the

weighted pick-up should rest away from the

rear of the tank and move freely inside the

tank. e top of the vent tube should rest just

below the top of the tank. It should not touch

the top of the tank.

6) When satised with the alignment of the

stopper assembly tighten the 3 x 20mm ma-

chine screw until the rubber stopper expands

and seals the tank opening. Do not over-

tighten the assembly as this could cause the

tank to split.

FUEL TANK INSTALLATION.

You should mark which tube is the vent

and which is the fuel pickup when you attach

fuel tubing to the tubes in the stopper. Once the

tank is installed inside the fuselage, it may be

dicult to determine which is which.

RADIAL ROCKET 10cc Instruction Manual.

1010

7) Slide the fuel tank into the fuselage. Guide

the lines from the tank through the hole in

the rewall.

8) Use plywood template to hold in place the

fuel tank with C/A glue to secure the fuel

tank inside the fuselage.

C/A glue.

Balsa wood.

9) Connect the lines from the tank to the en-

gine and muer. e vent line will connect

to the muer and the line from the clunk to

the carburetor.

Vent tube.

Fuel pick up tube.

Fuel ll tube.

Blow through one of the lines to ensure

the fuel lines have not become kinked inside

the fuel tank compartment. Air should ow

through easily.

ENGINE MOUNT INSTALLATION.

1) Locate the items necessary to install

the engine mount included with your

model.

4x30mm

2) Use four 4x30mm head bolts and four

4mm washers to attach the engine mount

rails to the rewall. Tighten the screws .

Make sure to use threadlock on the screws to

help prevent them from vibrating loose.

read locker glue.

Table of contents

Other Seagull Models Toy manuals

Seagull Models

Seagull Models STEEN SKYBOLT N250SB 15CC User manual

Seagull Models

Seagull Models Arising Star User manual

Seagull Models

Seagull Models Seagull 2000 User manual

Seagull Models

Seagull Models THUNDERBOLT P47G SNAFU 60 ARF User manual

Seagull Models

Seagull Models SEA 304 User manual

Seagull Models

Seagull Models CESSNA 152 User manual

Seagull Models

Seagull Models Extra 300 User manual

Seagull Models

Seagull Models SEA EAGLE User manual

Seagull Models

Seagull Models Sparrow Hawk SEA-93 User manual

Seagull Models

Seagull Models ultra-jet User manual

Seagull Models

Seagull Models Husky User manual

Seagull Models

Seagull Models Savage Cruiser User manual

Seagull Models

Seagull Models L-4 Grasshopper 90 inches User manual

Seagull Models

Seagull Models WESTLAND LYSANDER MK. III 55CC SEA216 User manual

Seagull Models

Seagull Models SEA230B User manual

Seagull Models

Seagull Models MUSTANG P-51 User manual

Seagull Models

Seagull Models EDGE 540 EP User manual

Seagull Models

Seagull Models Embraer EMB-312 Tucano T-27 Brazilian Air Force 85 span... User manual

Seagull Models

Seagull Models ZERO FIGHTER User manual

Seagull Models

Seagull Models Extra 260 User manual

Seagull Models

Seagull Models Maxi Lift SEA209N User manual

Seagull Models

Seagull Models Grumman F8F Bearcat User manual

Seagull Models

Seagull Models Mini MXS-R EP User manual

Seagull Models

Seagull Models ERCOUPE User manual

Popular Toy manuals by other brands

marklin

marklin 37321 instruction manual

Canon

Canon PAPER CRAFT Assembly instructions

GREAT PLANES

GREAT PLANES Pitts M-12S instruction manual

NOCH

NOCH 14261 manual

Hausler

Hausler 450 SE V2 quick start

Dynaflite

Dynaflite Daydream instruction manual

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Build instructions

Kenner

Kenner Batman 63651 instructions

LEGO

LEGO 8527 instructions

iKarus

iKarus ECO 8 Assembly instruction

Multiplex

Multiplex EasyStar II Building instructions

Walkera

Walkera 38 User handbook

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE manual

MD MXION SWD user manual

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway instructions

marklin

marklin 39671 user manual

Meccano

Meccano 15103 instructions

LEGO

LEGO TECHNIC 8735 instructions
