Seagull Models Seagull 2000 User manual
Specifications:
Wingspan------------------------------78.7in(200cm).
Wingarea-------------------488.3sq.in(31.5sqdm).
Weight---------------------------------------2.2lbs(1kg).
Length-------------------------------------37in(94.1cm).
Enginemotor ----------------------------------400-480.
Radio------------------------------------------4channels.
Servo-----------------3miniservos(23x12x24mm).
Propeller----------------------------------------------9x5.
Speedcontrol----------------------------------------30A.
Partslistingrequired(notincluded)
ASSEMBLY MANUAL
MS:130
“Graphics and specifications may change without notice”.
2
SEAGULL. Instruction Manual.
INTRODUCTION.
Thank you for choosing the SEAGULL 2000 ARTF by SEAGULL MODELS. The SEAGULL 2000
was designed with the sports trainer flyer in mind. It is a High-wing aeroplane which is easy to fly
andquicktoassemble.Theairframeisconventionallybuiltusingbalsa,plywoodandveneertomake
itstrongerthantheaverageARTF,yetthedesignallowstheaeroplanetobekeptlight.Youwillfind
that most of the work has been done for you already. The pushrods are pre-made to the correct
lengths, the motor mount has been fitted and the hinges are pre-installed and pinned for security.
Flying the SEAGULL 2000 is simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual throughly before starting assembly of your SEAGULL 2000. Use the parts listing below to
identify all parts.
WARNING.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is capable
of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU ASSUME ALL
RISK & RESPONSIBILITY.
IfyouareinexperiencedwithbasicR/CflightwestronglyrecommendyoucontactyourR/Csupplier
and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
proceduresdesignedtohelpthenew pilotonhisway tosuccessfulR/C flight.Theywillalso beable
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED.
- motor 400 - 480
- 4 channel radio with 3 servos.
- Glow plug to suit engine.
- Propeller to suit engine.
- Protective foam rubber for radio
system.
- Silicone fuel line.
- Stick-on weights for balance
(If necessary).
TOOLS & SUPPLIES NEEDED.
- Thick cyanoacrylate glue.
- 30 minute epoxy.
- 5 minute epoxy.
- Hand or electric drill.
- Assorted drill bits.
-Modellingknife.
- Straight edge ruler.
- 2mm ball driver.
- Phillips head screwdriver.
- 220 grit sandpaper.
- 90° square or builder’s triangle.
- Wire cutters.
- Masking tape & T-pins.
- Thread-lock.
- Paper towels.
PARTS LISTING.
FUSELAGE ASSEMBLY
1) Fuselage.
WING ASSEMBLY
1) Right wing half with pre-installed
aileron.
2) Left winghalf withpre-installedaileron.
TAIL SECTION ASSEMBLY
1) Vertical stabilizer with pre-installed
rudder.
2) Horizontal stabilizer withpre-installed
elevartor halves.
3
Instruction Manual.
ELECTRIC POWER CONVERSION.
1) Locate the items neccessary to install the
electric power conversion included with your
model.
3.2mm.
3.2mm.
4
SEAGULL. Instruction Manual.
ELEVATOR SERVO.
Install the spinner backplate, propeller and
spinner cone.
The propeller should not touch any part
of the spinner cone. If it does, use a sharp
modeling knife and carefully trim away the
spinner cone where the propeller comes in
contact with it.
INSTALLING THE SPINNER.
Ply of wood.
5
Instruction Manual.
AILERON SERVO INSTALLATION.
Servos.
String.
Small weight.
1) Usingasmallweight(Weightedfuel pick-up
workswell)andstring, feedthestring through
the wing as indicated.
Because the size of servos differ, you
mayneedtoadjustthesizeoftheprecutopen-
ing in the mount. The notch in the sides of
themountallowtheservoleadtopassthrough.
C/Aglue.
Micro control connector.
6
SEAGULL. Instruction Manual.
3) Set the aileron hatch in place and use a
Phillips screw driver to install it with four wood
screws.
AILERONPUSHROD HORN INSTALLATION
2) A string has been provided in the wing to
pull the aileron lead through to the wing root.
Remove the string from the wing at the servo
location and use the tape to attach it to the
servoextensionlead.Pulltheleadthrough the
wing and remove the string.
Attach the string to the servo lead and carefully thread it though the wing.
M2x10mm.
M2x6mm.
Wing rib.
Wing.
Small weight.
String.
7
Instruction Manual.
3mm.
Cut.
WING ASSEMBLY.
Repeat the procedure for the other
aileron servo.
M2x10mm.
8
SEAGULL. Instruction Manual.
AILERON PUSHROD INSTALLATION.
VERTICAL STABILIZER
INSTALLATION.
M3x15mm.
12mm.
9
Instruction Manual.
3mm.
Cut.
M3x15mm.
10
SEAGULL. Instruction Manual.
ATTACHMENT WING-FUSELAGE.
INSTALLING THE BATTERY. Receiver.
1) Plugthefiveservoleads and the switch
lead into the receiver. Plug the battery pack
lead into the switch also.
3) Route the antennain the antenna tube
insidethefuselageandsecure it to the bottom
of fuselage using a plastic tape.
2) Wrap the receiver and battery pack in
the protective foam rubber to protect them
from vibration.
Battery.
Speed control.
Cut.
C/Aglue.
INSTALLING THE RECEIVER.
