PN 9001100

Rev. C

1

SATO M84Pro Printer Parts List

M84Pro Printer

Parts List

SATO M84Pro Printer Parts List

PN 9001100

Rev. C

2

SATO America, Inc.

10350A Nations Ford Road

Charlotte, NC 28273

Main Phone: (704)644-1650

Tech Support Hotline: (704)644-1660

Tech Support Fax: (707)644-1661

E-Mail: satosales@satoamerica.com

www.satoamerica.com

© Copyright 2003

SATO America, Inc.

All rights reserved. No part of this document may be reproduced or issued to third parties in any form whatsoever

without the express permission of SATO America, Inc. The materials in this document is provided for general

information and is subject to change without notice. SATO America, Inc. assumes no responsibilities for any errors

that may appear.

PN 9001100

Rev. C

3

SATO M84Pro Printer Parts List

M84Pro

Parts List Page

Base Cover Assembly........................................................................... 3

Frame Assembly ................................................................................. 12

Head Assembly ................................................................................... 18

Ribbon Assembly ................................................................................ 21

Feed Roller Assembly ......................................................................... 24

Cutter Unit (Option) ............................................................................. 26

Dispenser Unit (Option)....................................................................... 32

Table of Contents

NOTE:

The parts information in this document is

accurate at the time of publication and is subject

to change without notice.

SATO M84Pro Printer Parts List

PN 9001100

Rev. C

4

Base Cover Assembly

PN 9001100

Rev. C

5

SATO M84Pro Printer Parts List

Base Cover Assembly

SATO M84Pro Printer Parts List

PN 9001100

Rev. C

6

Base Cover Assembly

PN 9001100

Rev. C

7

SATO M84Pro Printer Parts List

Base Cover Assembly

SATO M84Pro Printer Parts List

PN 9001100

Rev. C

8

Base Cover Assembly

125

PN 9001100

Rev. C

9

SATO M84Pro Printer Parts List

Base Cover Assembly

ITEM NO. PART NO. DESCRIPTION QTY

1P02513010 BASE FRAME 1

2PT6680100 CASE LEG 4

3PA3741000 FRAME BRACKET 1

4MD4301022 PAN HEAD SCREW 3

5PA3742500 FRAME BRACKET 1

6MD4301022 PAN HEAD SCREW 2

7PT9689000 MAGNET CATCHER 1

8MD4301022 PAN HEAD SCREW 2

9R00900020 COVER(FRONT) 1

10 MD4401022 PAN HEAD SCREW 4

11 PE1680200 PROTECTOR 1

12 PE6740300 DIP SW COVER 1

13 P02515000 CENTER FRAME 1

14 MD4401022 PAN HEAD SCREW 3

15 PA1775400 CIRCUIT BOARD BRACKET 2

16 MD4300622 PAN HEAD SCREW 7

17 P02516000 CENTER FRAME SUB(A) 1

18 MD4300622 PAN HEAD SCREW 2

19 R00901010 COVER(REAR)SET 1

20 MD4300622 PAN HEAD SCREW 7

22 P02517000 LID 1

23 PT9520100 NYLON RIVET 2

24 P02518010 COVER(LH) 1

25 MD4300822 PAN HEAD SCREW 2

26 P02519000 COVER(RH) 1

27 PT3681200 HINGE 2

28 MD4300822 PAN HEAD SCREW 8

29 PH2680000 WINDOW 1

30 NA1030022 FLAT WASHER 2

SATO M84Pro Printer Parts List

PN 9001100

Rev. C

10

Base Cover Assembly

ITEM NO. PART NO. DESCRIPTION QTY

31 MT1300522 HEX NUT 2

32 PE1680300 HANDLE 1

33 MH0300821 PAN HEAD P-TAP SCREW 2

34 P02520000 COVER(TOP) 1

35 MD4300822 PAN HEAD SCREW 2

36 R01106000 COVER(TOP SUB) 1

37 PT9689000 MAGNET 1

38 NA1030022 PLAIN WASHER 2

39 NB0030022 SPRING WASHER 2

40 MT1300522 HEX NUT 2

41 NA1030022 PLAIN WASHER 2

42 NB0030022 SPRING WASHER 2

43 MT1300522 HEX NUT 2

44 P02522000 COVER(FRONT) 1

45 PH1741000 COVER(FRONT)SUB 1

46 NA1030022 PLAIN WASHER 2

47 NB0030022 SPRING WASHER 2

48 MT1300522 HEX NUT 2

49 MD4401022 PAN HEAD SCREW 1

50 PB0740701 SHAFT(UNWIND) 1

51 MD4301422 PAN HEAD SCREW 1

52 MJ1400524 HEX W-POINT SCREW 1

53 PB2680700 SPACER 1

54 PA2680100 LABEL GUIDE PLATE 1

55 PE2680200 SPACER 1

56 PV3680000 PAPER GUIDE 1

57 MH0302021 PAN HEAD P-TAP SCREW 3

58 PE4080100 PAPER GUIDE 2

59 PT2016010 DRY METAL 4

60 PE4210100 GUIDE CORE 1
