Samsung DV50F9A8GVP Manual

FEATURES

• Steam Drying technology

• 7.4 capacity (cu. ft./DOE)

• Vent Blockage Sensor

• Smart Care

• Moisture Sensor

• Stainless steel drum

• 3-way venting (4-way in electric dryer)

• 15 preset dry cycles and 9 options

• Heating element: 5300W/

22,000 BTU/hr

• LED display: Ice Blue

CONVENIENCE

• Reversible see-through door

• Dryer drum light

• Drying rack

• Child lock

• Lint ﬁlter indicator

• 5 dry levels

• 5 temperature settings

• 5 timed settings

• 2 signal level settings

DV50F9A8GVP

Samsung Top Load Gas Dryer

Ranked “Highest in Customer

Satisfaction with Clothes Dryers”

by J.D. Power and Associates.*

(5 Consecutive Years) * Samsung received the highest numerical score for clothes dryers in the proprietary J.D. Power and Associates 2008-2012 Laundry Appliance Studies.

SM 2012 study

based on 9,339 total responses measuring 12 brands and measures opinions of consumers about their dryer obtained new in the past 24 months. Proprietary study

results are based on experiences and perceptions of consumers surveyed in January–February 2012. Your experiences may vary. Visit jdpower.com.

Steam Drying technology

Steam Refresh helps remove odors and freshens clothes. Steam Wrinkle Away relaxes wrinkles

to reduce ironing.

Smart Care

Diagnoses error codes without a manual or phone call.

Vent Blockage Sensor

Your Samsung dryer is equipped with a Vent Sensor which detects and notiﬁes you when it is time

to clean the ducts. Keep your dryer safe and efﬁcient!

Peace of mind with NSF®-certified steam sanitize cycle

Samsung’s NSF®-certiﬁed dryers eliminate 99.9% of household bacteria from laundry.

SIGNATURE FEATURES

Available colors

Stainless Platinum Neat White

7.4 capacity (cu. ft./DOE)

Stainless steel drum

3-way venting (4-way in electric dryer)

15 preset dry cycles:

Refresh, Steam Sanitize, Wrinkle Away, Normal, Heavy

Duty, Towels, Permanent Press, Bedding, Delicates,

Jeans, Sanitize, Time Dry, Air Fluff, Quick Dry, Rack Dry

9 options:

Mixed Load Bell, Wrinkle Prevent, Adjust Time,

My Cycle, Child Lock, Signal On/Off, Anti Static,

Small Load Care, Drum Light

5 dry levels:

Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry

5 temperature settings:

High, Medium, Medium Low, Low, Extra Low

5 timed settings:

60 min., 50 min., 40 min., 30 min., 20 min.

2 signal level settings: On/Off

Warranty

One (1) Year Parts and Labor

Two (2) Years Control Board

Product dimensions & weight (WxHxD)

Dimensions: 27" x 44 3/4" x 30"

Weight: 128.2 lbs

Shipping dimensions & weight (WxHxD)

Dimensions: 291/2" x 47" x 31 1/8"

Weight: 139.6 lbs

Electric Model # UPC Code

Stainless Platinum DV50F9A8EVP 887276018461

Neat White DV50F9A8EVW 887276018003

Gas Model # UPC Code

Stainless Platinum DV50F9A8GVP 887276018713

Neat White DV50F9A8GVW 887276018010

Matching Washer

Stainless Platinum WA50F9A8DSP 887276018140

Neat White WA50F9A8DSW 887276017860

DV50F9A8GVP

Samsung Top Load Gas Dryer

Actual color may vary. Design, speciﬁcations, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.

2" 5"

17"

29-3/8"

Dimensions:

* Required spacing.

(External exhaust elbow

requires additional space)

Minimum clearances for closets and alcoves:

Sides – 1"

Top – 17"

Rear – 5"

Closet front – 2"

If the washer and dryer are

installed together, the closet

front must have at least a

72 in (465 cm) unobstructed air

opening. Your washer alone does

not require a speciﬁc air opening.

Alcove or closet installation

INSTALLING YOUR DRYER

1" 1"

27"

Recessed area Side-view conﬁned Closet or door

48"*

24"*

44-3/4" 44-3/4"

29-3/8"

30"

27"
