Salus Controls plc

Enterprise Park, Bala

Gwynedd, LL23 7NL

Regional offices, England & Scotland.

Web: www.salus-tech.com

Email: sales

@salus-tech.com

Sales +44 (0) 8700 766900

Technical +44 (0) 8700 766902

Customer Services +44 (0) 8700 766902

Maintaining a policy of continual product development Salus Controls

plc. reserve the right to change specification, design and materials of

products listed in this brochure without prior notice.

Manual Issue No. IM-CT100-002

Cylinder/Pipe THERMOSTAT

for Model No. CT100

Instruction Manual

The CT100 is apractical surface mounted mechanical thermostat.

This thermostat will allow the user tocontrol the temperature of

Domestic Hot Water Cylinders (uninsulated and foam lagged).

This unit comes complete with awire strap which enables the CT100 to

be used alsoas apipe thermostat.

This unit can be used toswitch acirculating pump, boiler or most

common motorised zone valves.

Wiring

Diagram

Specification

Dimension (mm)

A B C

105 50 45

Voltage Rating : 230 AC 50Hz

Switch Rating : 16Aresistive

: 4A inductive

Switch Type : Single pole, double throw (SPDT)

Temperature Setting Range : 40 to80oC

Ambient Temperature : 0 to 55oC

Agency Approval : CE

FIXINGS FOR BOTH CYLINDER/PIPE THERMOSTAT ARE INCLUDED WITHIN THE BOX.

Internal

Diagram

A

B

C

Once the CT100 has been

situated in the correct location

and connected, simply turn

the dial tothe desired setting

making sure the temperature

required lines up with the

arrow on the main body of the

CT100. Fixings for both

Cylinder/Pipe Thermostat are

included within the box.

Setting The

Temperature

Thank you for purchasing this Salus product -if installing for someone

else, please ensure that the instructions are handed to the householder.

Warning- Please read this manual prior toinstallation or use.

ShockHazard

This unit must be installed by acompetent person, in accordance with

BS 7671 (the IEE Wiring Regulations), or other relevant national

regulations and codes of good practise.

Alwaysisolate the AC Mains supply before removing the unit

from the Industry Standard Back Plate.

Terminals C and 1 make

on temperature rise.

Terminals C and 2 make

on temperature fail.

CT100

THERMOSTAT

C 21

+C

º
