Roland CX-500 Installation and operation manual
CX-500/400/300
Startup Manual
BE SURE TO READ THIS FIRST
Thank you very much for purchasing this product. This document describes the included
items and accessories, program installation and setup, and other important matters. Be sure
to read this manual before use.
Contents
Part 1 Getting Started ................................................................................ 1
1-1. Accessories .................................................................................................................................2
1-2. Examples of System Configuration Using the Included Programs...........................................3
1-3. Documentation for the Machine ................................................................................................4
1-4. Viewing Manuals in Electronic Format .....................................................................................5
Part 2 Windows Section ............................................................................ 7
2-1. System Requirements.................................................................................................................8
2-2. Using the CAMM-1 Driver with a Printer-cable Connection ...................................................9
2-3. Using the CAMM-1 Driver with a USB Connection ............................................................. 10
2-4. Installing and Setting Up Roland CutChoice ......................................................................... 13
Part 3 Macintosh Section ........................................................................ 15
3-1. System Requirements.............................................................................................................. 16
3-2. Installing and Setting Up Roland CutChoice ......................................................................... 17
Roland CutChoice™ is a trademark of Roland DG Corporation.
Windows®and Windows NT®are registered trademarks or trademarks of Microsoft®Corporation in the United States and/or other countries.
Macintosh and Mac OS are registered trademarks or trademarks of Apple Computer, Inc. in the USAand other countries.
PowerPC is a trademark of International Business Machines Corporation.
Adobe, Acrobat and Adobe Illustrator are trademarks of Adobe Systems Incorporated.
Corel and CorelDRAW are registered trademarks or trademarks of Corel Corporation or Corel Corporation Limited.
Other company names and product names are registered trademarks or trademarks of their respective holders.
Copyright © 2001 Roland DG Corporation http://www.rolanddg.com/
1
Part 1
Getting Started
1-1. Accessories............................................................................... 2
Checking the Accessories ...............................................................................................2
1-2. Examples of System Configuration
Using the Included Programs ......................................... 3
Configuration using Roland CutChoice (Windows/Macintosh)....................................3
Configuration using the CAMM-1 driver (Windows) ...................................................3
1-3. Documentation for the Machine .............................................. 4
Included Documents .......................................................................................................4
1-4. Viewing Manuals in Electronic Format................................... 5
CX-500/400/300 User's Manual (Windows/Macintosh)................................................5
Roland CutChoice User's Manual ..................................................................................5
Online Help for the CAMM-1 Driver ............................................................................6
2
1-1. Accessories
Checking the Accessories
Check the following to make sure that you received all the items that were shipped together with the machine.
Part 1 Getting Started
Power Cord Blade Holder (XD-CH3) Blade Alignment Tool
Startup Manual
(This manual)
Replacement Blade for
Separating Knife
To Ensure Safe Use
Cable Clamp
Pin
CD-ROM
Roland Software Package
/ CutChoice installer CD
( )
3
1-2. Examples of System Configuration Using the Included Programs
1-2. Examples of System Configuration
Using the Included Programs
Configuration using Roland CutChoice (Windows/Macintosh)
Roland CutChoice is a cutting-use plug-in that is compatible withAdobe Illustrator and CorelDRAW. It lets you perform high-quality
cutting for artwork designed using Adobe Illustrator or CorelDRAW. It is compatible with Adobe Illustrator and CorelDRAW for
Windows, and with Adobe Illustrator for the Macintosh.
Configuration using the CAMM-1 driver (Windows)
This configuration combines the included Windows-based driver (CAMM-1 driver) with a drawing-based graphic program or the
like. It lets you cut things of relatively small size with ease.
USB
USB
USB
or
Printer cable
Graphic program
4
1-3. Documentation for the Machine
Included Documents
Part 1 Getting Started
This document contains important notes for ensuring the safe use of this
product. Please be sure to read it before use.
This manual. Be sure to read this before use.
The user's manual for the CX-500/400/300 is in electronic format, and is on
the included CD-ROM. A printed version is not included. You can easily
view it on your computer running Windows or your Macintosh. You can
also print it out as required. For information on how to view the electronic
manual, see the following section.
Read this if you're using Roland CutChoice. It describes installation and
setup in detail, as well as operation. The manual is in electronic format, and
you can find it on the included CD-ROM.A printed version is not included.
This document describes the assembly and installation of the special stand.
It is included with the stand.
To Ensure Safe Use
Startup Manual
CX-500/400/300 User's Manual
(PDF format)
Roland CutChoice™ User's Manual
(PDF format)
PNS-502/402/302 Assembly Instructions
(shipped with the stand)
5
1-4. Viewing Manuals in Electronic Format
1-4. Viewing Manuals in Electronic Format
CX-500/400/300 User's Manual (Windows/Macintosh)
1.
Place the included CD-ROM in the CD-ROM drive. The menu screen
appears automatically.
2.
Click the [Click here] message, then choose the name of the model
you're using (CX-500, CX-400 or CX-300).
3.
Click the [Read User's Manual] button. Acrobat Reader starts and the
user's manual is displayed.
* When you click the button for the first time, the program for install-
ing and setting up Acrobat Reader may start. Follow the on-screen
instructions to proceed with installation and setup.
4.
You can use the left and right arrow keys on the computer keyboard to
advance to the next page or go back to the previous page. (You can
also do the same thing using the [ ] and [ ] buttons on screen.)
Roland CutChoice User's Manual (Windows/Macintosh)
1.
Place the included CD-ROM in the CD-ROM drive. The menu screen
appears automatically.
2.
Click the [Click here] message, then choose the name of the model
you're using (CX-500, CX-400 or CX-300).
3.
Click the [Read User's Manual] button. Acrobat Reader starts and the
user's manual is displayed.
* When you click the button for the first time, the program for install-
ing and setting up Acrobat Reader may start. Follow the on-screen
instructions to proceed with installation and setup.
4.
You can use the left and right arrow keys on the computer keyboard to
advance to the next page or go back to the previous page. (You can
also do the same thing using the [ ] and [ ] buttons on screen.)
* The screens show the version for Windows.
(1) Choose the model name. (2) Click the button.
* The screens show the version for Windows.
(1) Choose the model name. (2) Click the button.
6
Part 1 Getting Started
About Adobe Acrobat Reader
Acrobat Reader is a program required to view files in PDF format. Installing and setting upAcrobat Reader 4.0, found
on the included CD-ROM, lets you view the manual easily on any computer.Acrobat Reader 4.0 is available in versions
for Windows (Windows 95 or later) and for Macintosh (PowerPC, System 7.1.2 or later).
* Acrobat Reader is a product of Adobe Systems Incorporated. For detailed information on how to use it, go to the
Acrobat Reader menu and select [Help] to view the online help.
Online Help for the CAMM-1 Driver
For information about how to use the river, refer to "readme" and the online help. To view online help, install the driver, then follow
the steps below.
Windows 95/98/Me
1.
Click [Start] - [Settings] - [Printers].
2.
Right-click the printer icon for the CX-500/400/300, then click [Property].
3.
Click the [Size], [Tool], or [Options] tab.
4.
Click the [?] button at the top right of the window, then click the topic you want to know more about.
Windows 2000/XP
1.
Windows 2000 : Click [Start] - [Settings] - [Printers].
Windows XP : Click [Start] - [Control Panel]. Click [Printers and Other Hardwares]. Click [Printers and Faxes].
2.
Right-click the printer icon for the CX-500/400/300, then click [Printing Preferences].
3.
The [Layout] tab appears. Click the [Advanced] button.
4.
Click the [?] button at the top right of the window, then click the topic you want to know more about.
Windows NT4.0
1.
Click [Start] - [Settings] - [Printers].
2.
Right-click the printer icon for the CX-500/400/300, then click [Document Defaults].
3.
Click the [Advanced] tab.
4.
Click the [?] button at the top right of the window, then click the topic you want to know more about.
7
Part 2
Windows Section
This section describes how to install and set up the included programs (for Windows).
2-1. System Requirements .............................................................. 8
System Requirements for USB Connection ...................................................................8
System Requirements for Roland CutChoice (Windows) .............................................8
System Requirements for CAMM-1 Driver ...................................................................8
2-2. Using the CAMM-1 Driver with a Printer-cable
Connection (Windows 95/98/Me/NT4.0/2000/XP)........... 9
To Install..........................................................................................................................9
2-3. Using the CAMM-1 Driver with a USB Connection
(Windows 98/Me/2000/XP) ............................................. 10
Step 1 : Installing the USB Driver............................................................................... 10
Step 2 : Installing the CAMM-1 Driver ...................................................................... 12
Step 3 : Making the Setting for the CX-500/400/300 ................................................. 12
2-4. Installing and Setting Up Roland CutChoice ....................... 13
Step 1 : Install the Drivers ........................................................................................... 13
Step 2 : Install and Set Up Roland CutChoice ............................................................ 13
Step 3: Making the Settings for the CX and the Program .......................................... 13
8
2-1. System Requirements
System Requirements for USB Connection
Making a USB connection with Windows requires use of a computer that meets all of the following system requirements. Please note
that other configurations cannot be supported.
Part 2 Windows Section
Operating System
Computer Conditions
•The ability to make a USB connection depends on the specifications of the computer. To determine whether the computer you're using is capable
of correct USB operation, check with the manufacturer of the computer.
•Use a shielded USB cable having a length of 3 meters or less. Do not use a USB hub or the like.
SystemRequirementsforRolandCutChoice(Windows)
Processor
RAM
Install space
Working disk space
Operating System (*)
Video system
Other
Supported models
Compatible programs
Connection
Pentium II 233 MHz or higher
128 MB or more
100 MB
1 GB or more
Latest version of Windows 98/Me/2000
800 x 600 screen resolution with 16 bit color or more
4x CD-ROM drive or faster
CAMM-1 PRO CX-500/400/300
Adobe Illustrator 8/9/10, CorelDRAW 8/9/10
USB
* This software only supports computer that have these OS factory installed. Computers with user upgraded OS may not work properly.
System Requirements for CAMM-1 Driver
Operating System (*) Windows 95/98/Me, Windows NT4.0/2000/XP
Windows 98/Me or Windows 2000/XP
(Windows 95 and Windows NT 4.0 are not supported.)
1) Computers preinstalled with Windows 98/Me/2000/XP at the time of purchase
(This includes such computers later upgraded to Windows Me/2000/XP.)
2) Computers on which USB operation is assured by the manufacturer of computers
* Making a USB connection requires a computer that meets the system requirements for USB connection described above.
* There are two types of CAMM-1 driver: one for Windows 95/98/Me and one for Windows NT4.0/2000/XP. When you carry out the
installation procedure described later, the correct driver is selected automatically.
Other manuals for CX-500
1
This manual suits for next models
2
Table of contents
Other Roland Printer manuals
Roland
Roland EGX-400 User manual
Roland
Roland Soljet Pro III XJ-540 Operating and maintenance manual
Roland
Roland LEC-300 User manual
Roland
Roland XF-640 Operating manual
Roland
Roland CAMM-2 PNC-2300 Parts list manual
Roland
Roland SOLJET Pro III XC-540 User manual
Roland
Roland CammJet CJ-500 User manual
Roland
Roland VS-540i User manual
Roland
Roland VersaCamm SP-540V User manual
Roland
Roland VersaUV LEF2-200 Operating manual
Roland
Roland Soljet EJ-640 User manual
Roland
Roland SJ-740 User manual
Roland
Roland VersaUV LEF2-300 User manual
Roland
Roland VersaStudio BT-12 User manual
Roland
Roland VS-640 User manual
Roland
Roland TrueVIS SG2-640 Operating manual
Roland
Roland TrueVIS VG2-640 User manual
Roland
Roland VersaUV LEF2-300 User manual
Roland
Roland SOLJET PROIII XC-540 User manual
Roland
Roland Advanced Jet AJ-1000 Operating and maintenance manual
