QNAP QSW-M2106PR User manual
QSW-M2106
QSW-M2106PR
User Guide
Document Version: 2
30/11/2022
Contents
1. Product Overview
About the QSW-M2106PR......................................................................................................................................... 3
Hardware Specications............................................................................................................................................3
Package Contents...................................................................................................................................................... 4
Components............................................................................................................................................................... 4
Front Panel.............................................................................................................................................................5
Front Panel LEDs................................................................................................................................................... 5
Safety Information.....................................................................................................................................................6
2. Installation and Access
Installation Requirements........................................................................................................................................ 8
Setting Up the Switch................................................................................................................................................ 8
Attaching Rubber Feet...............................................................................................................................................8
Installing Handles....................................................................................................................................................10
Connecting the Switch to a Computer or Network..............................................................................................11
Connecting the Switch to a Computer..............................................................................................................11
Connecting the Switch to a Network................................................................................................................ 12
Switch Access............................................................................................................................................................13
Accessing the Switch Using a Browser.............................................................................................................13
Accessing the Switch Using Qnder Pro.......................................................................................................... 14
3. Basic Operations
LEDs...........................................................................................................................................................................15
Reset Button.............................................................................................................................................................16
4. QSS
About QSS.................................................................................................................................................................17
Getting Started.........................................................................................................................................................17
Network Management............................................................................................................................................ 17
Conguring Port Settings.................................................................................................................................. 17
Managing PoE Settings...................................................................................................................................... 18
Adding a VLAN.....................................................................................................................................................19
Adding a Link Aggregation Group (LAG).......................................................................................................... 19
Managing Rapid Spanning Tree Protocol (RSTP) Settings..............................................................................20
Conguring the LLDP Settings.......................................................................................................................... 21
Adding a Static MAC Address.............................................................................................................................21
Conguring IGMP Snooping..............................................................................................................................22
Conguring QoS Settings...................................................................................................................................22
Managing Access Control List (ACL) Entries.....................................................................................................24
Deleting a Network Setting................................................................................................................................25
Monitoring Network Settings............................................................................................................................ 25
System Management.............................................................................................................................................. 26
System Settings...................................................................................................................................................26
Firmware Update................................................................................................................................................ 31
5. Support and Other Resources
6. Glossary
myQNAPcloud.......................................................................................................................................................... 35
Qnder Pro............................................................................................................................................................... 35
QSW-M2106PR User Guide
1
QSS.............................................................................................................................................................................35
QuNetSwitch.............................................................................................................................................................35
7. Notices
Limited Warranty..................................................................................................................................................... 36
Disclaimer................................................................................................................................................................. 36
GNU Public License..................................................................................................................................................36
CE Notice...................................................................................................................................................................44
FCC Notice.................................................................................................................................................................44
VCCI Notice............................................................................................................................................................... 45
BSMI Notice.............................................................................................................................................................. 45
SJ/T 11364-2006........................................................................................................................................................45
EU Directive 2002/96/EC Waste Electronic and Electrical Equipment (WEEE)...................................................46
EU RoHS Statement................................................................................................................................................. 46
Laser Compliance Notice........................................................................................................................................ 46
UKCA Notice..............................................................................................................................................................47
2
1. Product Overview
This chapter provides basic information about the QNAP device.
About the QSW-M2106PR
The QSW-M2106PR is a multi-gigabit Ethernet switch that provides Layer 2 network management. The
switch is equipped with six 2.5 GbE RJ45 ports, two 10 GbE RJ45 ports, and two 10 GbE SFP+ combo ports
for enhanced network scalability and operational productivity. The switch can be accessed using the RJ45
console port for ecient device management and switch operations.
The QSW-M2106PR features 2.5 GbE and 10 GbE ports with up to 90-watt Power over Ethernet (PoE) output.
Hardware Specications
Warning
If your QNAP product has hardware defects, return the product to QNAP or a QNAP-
authorized service center for maintenance or replacement. Any attempt to repair or
perform maintenance procedures on the product by you or an unauthorized third party
invalidates the warranty.
QNAP is not responsible for any damage or data loss caused by unauthorized
modications and installation of unsupported third-party applications.
For details, see the QNAP Warranty Terms and Conditions.
Tip
Model specications are subject to change without prior notice. To see the latest
specications, go to https://www.qnap.com.
Ordering P/N CPU Memory
QSW-M2106PR-2S2T Marvell® Prestera® 98DX2528 1 GB
Component QSW-M2106PR-2S2T
Processor
CPU Marvell ® Prestera® 98DX2528
Frequency Dual-core
Architecture ARM 32-bit
Chipset Marvell ® Prestera® 98DX2528
Network interfaces • 6 x 100M/1G/2.5G RJ45 ports
• 2 x 100M/1G/2.5G/5G/10G GbE RJ45 ports
• 2 x 1G/10G SFP+ combo ports
Management interfaces 1 x RJ45 console port
PoE support
802.3bt (PoE++) Ports 1 to 8
Note
The ports support IEEE 802.3bt-2018 PoE standard and
provide up to 90W of DC power.
PoE max power port Ports 1 to 8: Up to 90W
Total PoE power budget 310W
QSW-M2106PR User Guide
Product Overview 3
Component QSW-M2106PR-2S2T
Total power consumption 350W
Interface
Buttons Switch reset
LEDs
System • Status
• PoE
• Fan
Ports • Speed
• Activity
Dimensions
Form factor Compact
Dimensions (H x W x D) 43.3 x 207 x 248.8 mm
(1.70 x 8.14 x 9.79 in)
Net weight 1.73kg (3.81 lbs)
Others
Power supply unit 100-240V, 50/60 Hz
Fans System: 2 x VAPO bearing fan
Operating temperature 0˚C to 40˚C (32˚F to 104˚F)
Relative humidity • Non-condensing relative humidity: 5% to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
Package Contents
Item Quantity
QSW-M2106PR 1
Power cord 1
Rail brackets 2
Screws for rail brackets 6
Rubber feet 4
Quick Installation Guide (QIG) 1
Components
QSW-M2106PR User Guide
Product Overview 4
Front Panel
No. Component No. Component
1 RJ45 console port 4 10 GbE SFP+ ports
2 2.5 GbE RJ45 ports 5 Switch reset button
3 10 GbE RJ45 ports - -
Front Panel LEDs
No. Component No. Component
1 Switch status LED 6 10GbE RJ45 speed LED
2 PoE LED 7 10GbE RJ45 PoE LED
QSW-M2106PR User Guide
Product Overview 5
No. Component No. Component
3 Fan LED 8 10GbE SFP+ (10G speed) LED
4 2.5 GbE RJ45 speed LED 9 10GbE SFP+ (1G speed) LED
5 2.5 GbE RJ45 PoE LED - -
Safety Information
The following instructions help ensure personal safety and environmental safety. Read these instructions
carefully before performing any operation.
General Instructions
• The device should be stored in a secure location with restricted access, controlled through the use of a
tool, lock and key, or any means of security.
• Only qualied, skilled, and authorized persons with knowledge of all restrictions, safety precautions,
and installation and maintenance procedures should have physical access to the device.
• To avoid potential injury or damage to components, ensure that the drives and other internal system
components have cooled before touching them.
• Observe electrostatic discharge (ESD) procedures to avoid potential injury or damage to components.
Power
• To reduce the risk of re or electric shock, ensure that you only connect the power cord to a properly
grounded electrical outlet.
• To avoid serious injuries, a trained service technician must disconnect all PSU cords from the device
before installing or replacing system components.
System Battery
• This product contains a button battery.
• If swallowed, a lithium button battery can cause severe or fatal injuries within 2 hours.
• Keep batteries out of reach of children.
• If you think batteries may have been swallowed or placed inside any part of the body, seek immediate
medical attention.
• To avoid potential battery explosion, causing injury or damage to components, ensure that you replace
the existing battery with a battery of the same type.
• Dispose of used batteries properly according to local regulations or the instructions of the battery
manufacturer.
Moving Parts
•
Moving fan blades: Keep your body parts away from moving fan blades while the device is connected
to a power source.
QSW-M2106PR User Guide
Product Overview 6
•
Moving components: Keep your body parts away from other moving components.
• The device is not suitable for use in locations where children are likely to be present.
QSW-M2106PR User Guide
Product Overview 7
2. Installation and Access
This chapter provides specic hardware installation and switch access steps.
Installation Requirements
Category Item
Environment • Room temperature: 0˚C to 40˚C (32˚F to 104˚F)
• Non-condensing relative humidity: 5% to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
• Flat, anti-static surface without exposure to direct sunlight, liquids,
or chemicals
• Free from objects that may obstruct the switch ventilation or apply
pressure to the switch or power cord.
Hardware and peripherals • Computer or NAS
• Network cable
Tools • Phillips #1 or #2 screwdriver
• Flat head screwdriver
• Anti-static wrist strap
Setting Up the Switch
1. Place your switch in an environment that meets the requirements.
For details, see Installation Requirements.
2. Power on the switch.
3. Connect the switch to a computer or network.
For details, see Connecting the Switch to a Computer.
4. Log in to QSS.
Attaching Rubber Feet
1. Power o the device.
2. Disconnect the power cord from the electrical outlet.
3. Disconnect all cables and external attachments.
4. Turn the device upside down.
QSW-M2106PR User Guide
Installation and Access 8
5. Attach the rubber feet.
a. Remove the protective lm from the rubber feet.
b. Attach the rubber feet.
c. Place the device in its normal upright position.
QSW-M2106PR User Guide
Installation and Access 9
This manual suits for next models
1
