Progress Lighting AirPro P2572 User manual

P2572

93089919_A

Limited Lifetime Warranty

Date Purchased

Store Purchased

UL Model No.

Serial No.

Vendor No.

UPC

111017

P2572

Progress Lighting fan motors are warranted to the original purchaser to be free of electrical and/or mechanical

defects for so long as the original purchaser owns the fan. Pull chain switches, reverse switches, capacitors and

metal nishes are warranted to be free from defects in materials or workmanship for a period of 1 year from

the date of purchase. Warping of wooden or plastic blades is not covered by this warranty nor is corrosion and/

or deterioration of any nishes for fans installed within ten miles of any sea coast. Extended warranties for

ENERGY STAR® qualied products may apply.

Progress Lighting ceiling fans with built-in LED light sources, when properly installed and under normal

conditions of use, are warranted to be free from defects in material and workmanship which cause the light

sources to fail to operate in accordance with the specications for (i) ve (5) years from the date of purchase

on the LED Light modules and electrical components for fans used in single family residences, and (ii) three

(3) years from the date of purchase on the LED Light modules and electrical components for fans used in

multi-family or commercial applications. LED bulbs supplied by Progress Lighting carry no warranty other

than manufacturer’s warranty. Non-LED bulbs carry no warranty.

With proof of purchase, the original purchaser may return the defective fan to the place of purchase during the

rst 30 days for replacement. After 30 days, the original purchaser MUST contact Progress Lighting at (864)

678-1000 for repair or replacement which shall be determined in Progress Lighting’s sole discretion and shall

be purchaser’s sole and exclusive remedy.

Labor and Shipping Excluded. This warranty does not cover any costs or fees associated with the labor

(including, but not limited to, electrician’s fees) required to install, remove, or replace a fan or any fan parts.

This warranty shall not apply to any loss or damage resulting from (i) normal wear and tear or alteration,

misuse, abuse or neglect, or (ii) improper installation, operation, repair or maintenance by original purchaser

or a third party, including without limitation improper voltage supply or power surge, use of improper parts or

accessories, unauthorized repair (made or attempted) or failure to provide maintenance to the fan.

THE FOREGOING WARRANTIES STATE PROGRESS LIGHTING’S ENTIRE WARRANTY OBLIGATION

AND ORIGINAL PURCHASER’S SOLE AND EXCLUSIVE REMEDY RELATED TO SUCH PRODUCTS.

PROGRESS LIGHTING IS NOT RESPONSIBLE FOR DAMAGES (INCLUDING INDIRECT, SPECIAL,

INCIDENTIAL OR CONSEQUENTIAL), DUE TO PRODUCT FAILURE, WHETHER ARISING OUT OF

BREACH OF WARRANTY, BREACH OF CONTRACT, OR OTHERWISE. THIS WARRANTY IS GIVEN

IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED, INCLUDING THOSE

OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT.

Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitations

of incidental or consequential damages, so the above limitations and exclusions may not apply to you. This

warranty gives you specic rights and you may have other rights which vary from state to state.

Safety Rules

Unpacking Your Fan

Installing Your Fan

Setting the Codes on Remote Control and Receiver

Making the Electrical Connections

Finishing the Fan Installation

Operating Your Fan

Care of Your Fan

Troubleshooting

Specications

Table of Contents

1. To reduce the risk of electric shock, insure electricity

has been turned off at the circuit breaker or fuse box

before beginning.

2. All wiring must be in accordance with the National

Electrical Code ANSI/NFPA 70-1999 and local electrical codes.

Electrical installation should be performed by a

qualied licensed electrician.

3. CAUTION: To reduce the risk of personal injury, use only

the screws provided with the electrical box.

4. The outlet box and support structure must be securely

mounted and capable of reliably supporting 35 lbs. (15.9

kg). Use only UL Listed outlet boxes marked “Acceptable

for Fan Support of 35 lbs. (15.9 kg) or less.”

5. CAUTION: The fan must be mounted with a minimum of

7 feet clearance from the trailing edge of the blades to the

oor.

6. Do not wait for the fan to stop before pressing the reverse

button. The fan will not reverse direction if the fan is not

moving.

7. Avoid placing objects in path of the blades.

8. To avoid personal injury or damage to the fan and other

items, be cautious when working around or

cleaning the fan.

9. Do not use water or detergents when cleaning the fan or fan

blades. A dry dust cloth or lightly dampened cloth will be

suitable for most cleaning.

10. After making electrical connections, spliced conductors

should be turned upward and pushed carefully up into

electrical box. The wires should be spread apart with the

grounded conductor and the equipment-grounding

conductor on one side of the electrical box and ungrounded

conductor on the other side of the electrical box.

11. Electrical diagrams are for reference only. Light kits that

are not packed with the fan must be UL Listed and marked

suitable for use with the model fan you are installing.

Switches must be UL General Use Switches. Refer to the

instructions packaged with the light kits and switches for

proper assembly.

12. All set screws must be checked and retightened where

necessary before installation.

13. WARNING: To reduce the risk of re or electric shock,

do not use this fan with any solid-state speed control device.

Use with speed controller UC7067RYE, manufactured

1. Safety Rules

READ AND SAVE THESE INSTRUCTIONS

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL

INJURY, MOUNT TO OUTLET BOX MARKED “ACCEPTABLE FOR FAN

SUPPORT OF 35 LBS. (15.9 KG) OR LESS”, AND USE SCREWS PRO-

VIDED WITH THE OUTLET BOX.

TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE

BLADE BRACKETS (ALSO REFERRED TO AS (“FLANGES”) DURING

ASSEMBLY OR AFTER INSTALLATION. DO NOT INSERT OBJECTS IN

THE PATH OF THE BLADES.

TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED

WITH AN ISOLATION CONTROL/SWITCH.

by Rhine Electronic Co., Ltd only.

14.

a. Blade attachment hardware

(16 Screws)

b. Electrical hardware and Balancing kit

(3 plastic wire connectors, blade balancing

kit)

5. Light Kit Fitter Assembly

6. Transmitter

7. Blade (5)

1. Mounting Plate (inside canopy)

2. Fan Motor Assembly

3. Light Kit Pan

4. Glass Shade

2. Unpacking Your Fan

Unpack your fan and check the contents. You should have the following items:

c. Extra mounting screws #10-32 for outlet box

(1 Screws)

3. Installing Your Fan

Tools Required

Phillips screw driver or straight slotted screw

driver, adjustable wrench, step ladder, and

wire cutters.

Mounting Options

If there isn’t an existing electrical box, then

read the following instructions. Disconnect

the power by removing fuses or turning off

circuit breakers.

Secure the electrical box directly to the building

structure. Use appropriate fasteners and

building materials. The electrical box and

its support must be able to fully support the

moving weight of the fan (at least 35 lbs.).

Do not use plastic electrical boxes.

Figures 1 and 2 are examples of different ways

to mount the electrical box.

To hang your fan where there is an existing

xture but no ceiling joist, you may need an

installation hanger bar as shown in Figure 3.

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR PERSONAL INJURY, MOUNT

TO OUTLET BOX MARKED “ACCEPTABLE

FOR FAN SUPPORT OF 35 LBS. (15.9 KG) OR

LESS”, AND USE SCREWS PROVIDED WITH

THE OUTLET BOX. ELECTRICAL BOXES

COMMONLY USED FOR THE SUPPORT OF

LIGHTING FIXTURES MAY NOT BE ACCEPT-

ABLE FOR FAN SUPPORT AND MAY NEED TO

BE REPLACED. CONSULT A QUALIFIED ELEC-

TRICIAN IF IN DOUBT.

Figure 1

Figure 2

Figure 3

Hanging the Fan

REMEMBER to turn off the power. Follow

the steps below to hang your fan properly.

NOTE: For better fan performance, make

sure the mounting plate is level. Additional

washers (not included) may be needed

to insert between the outlet box and the

mounting plate.

1. Securely attach the mounting plate to the

outlet box using the two screws supplied

with the outlet box. Pull the 120-volt

supply wires (the black, white and ground

wires) out of the outlet box and through

the hole in the mounting plate and lay

them to the side. (Figure 4)

2. Carefully lift the fan-motor assembly and

engage the slot in the motor bracket on

the top of the fan-motor assembly with

the hook on the mounting plate so that it

is securely suspended. (Figure 5)

3. Connect the wiring to your fan according

to “6. Making the electrical connection”.

4. Once the wiring is completed, proceed the

fan installation.

5. Remove two of the four screws (located

diagonally from each other) from the top of

the mounting plate and loosen the other two

screws.

Mounting Plate

Screws (2)

Figure 4

Figure 5

6. Align the two key slots in the top of the

motor housing with the two loosened screws

on the mounting plate. Push the motor

housing up and turn it clockwise to lock in

the mounting plate. Tighten the two screws.

7. Install the two screws that were removed

in step 5 into the remaining two holes and

tighten the four screws rmly.

Figure 6

Screws (2)

Connecting the Safety

Cable

Turn the wood screw (not provided) into the

ceiling.

Place the looped end of the safety cable onto

the wood screw and then tighten the screw firmly,

or connect the safety cable directly to the outer joist.

5. Setting the Codes

Setting the Codes

This unit has 16 different code combinations

to prevent possible interference from other

remote units such as garage door openers, car

alarms or security systems.

To set the codes, perform the following steps:

1. Setting the code on the transmitter:

A. Remove the battery cover from the

battery compartment in the back side of

the transmitter.

B. Slide code switches to your choice of

up or down position (factory setting is

up).

C. Replace the battery cover on the battery

compartment of the transmitter.

2. Setting the code on the receiver:

A. Slide code switches to the same

position as set on your transmitter.

Model:UC7085T

FCC ID:CHQ7085T

IC:2968A-7085T

Complies with Canada

RSS-210

MADE IN CHINA

AirproR

1 2 3 4

NECE

12V

1 2 3 4

ON DIP

1 2 3 4

ON DIP

1 2 3 4

NECE

Dip Switches

Transmitter

Receiver

The reverse button

Figure 7

Making the Electrical Connections

EACH WIRE NUT (WIRE CONNECTOR) SUPPLIED

WITH THIS FAN IS DESIGNED TO ACCEPT UP TO

ONE 12 GAUGE HOUSE WIRE AND TWO WIRES

FROM THIS FAN. IF YOU HAVE LARGER THAN

12 GAUGE HOUSE WIRING OR MORE THAN

ONE HOUSE WIRE TO CONNECT TO THE FAN

WIRING, CONSULT AN ELECTRICIAN FOR THE

PROPER SIZE WIRE NUTS TO USE.

USE THE PLASTIC WIRE CONNECTORS

SUPPLIED WITH YOUR FAN. SECURE THE

CONNECTORS WITH ELECTRICAL TAPE AND

ENSURE THERE ARE NO LOOSE STRANDS OR

CONNECTIONS.

BLACK

WHITE

GREEN

Outlet Box

BLACK

BLUE WHITE

WHITE

Figure 8

REMEMBER to disconnect the power. If

you feel you do not have enough electrical

wiring knowledge or experience, have your fan

installed by a licensed electrician. Do not use

solid state fans, electrical wires must meet all

local and national electrical code requirements.

Electrical source and fans must be 115/120

Volt, 60Hz.

Remote control model: UC7067RYE

IF OTHER FAN OR SUPPLY WIRES ARE

DIFFERENT, PLEASE HAVE THIS UNIT

INSTALLED BY A LICENSED ELECTRICIAN.

Follow the steps below to connect the fan to

your household wiring. (Figure 8)

Connect the GROUND conductor of the

120-volt supply to the GREEN wire from the

mounting plate using a wire nut (Figure 8).

Connect the receiver BLACK wire to the

BLACK household supply wire using a wire

nut (Figure 8).

Connect the receiver WHITE wire to the

WHITE neutral household wire using a wire

nut (Figure 8).

Attaching the Fan

Blades

1. Insert the blade through the slot cut-off in

the center ywheel, align the three screw

holes in the blade with the screw holes in

the ywheel and secure with the screws

provided. (Figure 9)

2. Repeat for the remaining blades.

Figure 9

Figure 10

Blade Balancing

All blades are grouped by weight. Because

natural woods vary in density, the fan may

wobble even though the blades are weight

matched.

The following procedure should correct most

fan wobble. Check after each step.

1. Check that all blade screws are secure.

2. Most fan wobble problems are caused

when blade levels are unequal. Check this

level by selecting a point on the ceiling

above the tip of one of the blades. Measure

from a point on the center of each blade

to the point on the ceiling. Measure this

distance as shown in Figure 10. Rotate

the fan until the next blade is positioned

for measurement. Repeat for each blade.

Measurements deviation should be within

1/8”. Run the fan for 10 minutes.

Touching

Ceiling

3. Make sure that motor bracket is tightened

securely to ceiling mounting plate and that

the ceiling mounting plate is tightened

securely to the electrical box.

4. Interchanging two adjacent blades can

redistribute the weight and possibly result

in the smoother operation.

5. Use the enclosed Blade Balancing Kit if the

blade wobble is still noticeable.

Screws (16)

Blade

Flywheel

7. Finishing the Fan Installation

Table of contents

Other Progress Lighting Fan manuals

Progress Lighting

Progress Lighting AirPro P250072 User manual

Progress Lighting

Progress Lighting AirPro P250034 User manual

Progress Lighting

Progress Lighting AirPro P2584 User manual

Progress Lighting

Progress Lighting CALERA User manual

Progress Lighting

Progress Lighting AirPro P250040 User manual

Progress Lighting

Progress Lighting AirPro P250075 User manual

Progress Lighting

Progress Lighting AirPro P250065 User manual

Progress Lighting

Progress Lighting AirPro P250016 User manual

Progress Lighting

Progress Lighting AirPro Royer P250010 User manual

Progress Lighting

Progress Lighting AirPro CALERA User manual

Progress Lighting

Progress Lighting AirPro P250003 User manual

Progress Lighting

Progress Lighting AirPro P2588 User manual

Progress Lighting

Progress Lighting AirPro P2574 User manual

Progress Lighting

Progress Lighting AirPro P2540 User manual

Progress Lighting

Progress Lighting AirPro Trevina II P2555 User manual

Progress Lighting

Progress Lighting AirPro P250102 User manual

Progress Lighting

Progress Lighting AirPro P250082 User manual

Progress Lighting

Progress Lighting AirPro P2548 User manual

Progress Lighting

Progress Lighting P2550 User manual

Progress Lighting

Progress Lighting P2529 User manual

Progress Lighting

Progress Lighting AirPro P250110 User manual

Progress Lighting

Progress Lighting AirPro P2539 User manual

Progress Lighting

Progress Lighting AirPro P2554 User manual

Progress Lighting

Progress Lighting Air Pro P2525 User manual

Popular Fan manuals by other brands

ELTA FANS

ELTA FANS H03VV-F installation guide

Hunter

Hunter 20714 Owner's guide and installation manual

Emerson

Emerson CARRERA VERANDA CF542ORB00 owner's manual

Hunter

Hunter Caraway Owner's guide and installation manual

Panasonic

Panasonic FV-15NLFS1 Service manual

Kompernass

Kompernass KH 1150 operating instructions

VES

VES FALA100/12V/TR Original instructions

Vertiv

Vertiv Liebert DCD user manual

Westinghouse

Westinghouse GFP Series owner's manual

Venmar

Venmar KUBIX HRV PLUS Series user guide

Maico

Maico ECR 31 installation instructions

Sonnenkonig

Sonnenkonig Dinky instruction manual

S&P

S&P ECOWATT HXBR manual

Wider

Wider IMP03369BH instruction manual

Panasonic

Panasonic F-60DHN Operating and installation instructions

Hinkley

Hinkley HIGHLAND instruction manual

Broan

Broan 766BN installation guide

Premium

Premium PFS16022 Use manual
