PROAIM VI-GLDE-01 User manual
1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Assembly Manua l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Glide 4-Dimensional Vibraon Isolator (VI-GLDE-01)
Proaim Glide Vibraon Isolator
Castle Nut Wrench
2 x T– Type Allen Key
(3/16mm, 3mm)
Hard Case
2
Loosen the Castle ring of the Glide Vibraon
Isolator with a Castle nut wrench and remove
it.
Glide Vibraon Isolator Setup
Then, aach the Glide Vibraon Isolator to the
arm.
Tighten the castle ring properly with the help
of a castle nut wrench.
Aach the uid head (Not Included) properly
by inserng it to the boom part of the
vibraon isolator.
The Vibraon Isolator is now properly
aached to the arm.
3
Then, remove the Mitchell Plate bolts with
the help of an Allen key.
Loosen and remove the castle ring from the
Gimbal Mitchell plate (Not Included).
Insert the bolt to properly aach the
Mitchell Plate and Freey Movi
(Not Included) Boom Mounng Part, then
ghten the bolt with the help of Allen Key.
Match the threads of the Mitchell Plate to
The Castle Nut and aach them together,
then insert the bolt. Tighten it properly using
the Allen key.
Mitchell plate and Freey Movi
(Not Included) boom mounng part have
been properly aached to each other.
Separate the Mitchell plate from the Castle
nut and aach it to the Freey Movi boom
mounng.
Gimbal Mitchell Plate with Castle Lock / Mount For Freey Movi
4
Aer aaching the Mitchell Plate and the
boom part of the Freey Movi
(Not Included), match the center hole of the
Glide Vibraon Isolator and then insert it, as
shown in the image.
Aach the Gimbal Mitchell Plate
(Not Included) to the Vibraon Isolator and
then manually aach the Castle Nut.
Properly ghten the Castle Ring with the
Castle Nut Wrench and then aach the
Gimbal to the Vibraon Isolator.
Aer aaching the Gimbal (Not included),
properly ghten it with the Gimbal Knob, as
shown in the image.
Mount For Freey Movi interchange
Gimbel
Gimbal Mitchell
Plate Freey Movi
5
Vibraon Isolator Setup
Remove the bolt of the Vibraon Isolator
using the 3/16mm Allen Key.
Then aach the Wire Brackets to the
Mitchell Mounng Plate and secure it using
the 3mm Allen Key.
NOTE: You can adjust the quanty of Wire
Brackets according to your setup payload.
Gimbal (Not Included) has been properly
aached to the Vibraon Isolator.
Then remove the Vibraon Isolator with the
help of a 3mm Allen key.
Aer removing the bolts, remove the Wire
Brackets.
Remove all the Wire Brackets by following
the same process, as shown in the image.
6
Follow the above process for aach all the
wire brackets.
Aach the Mitchell Mounng Plate to the
Vibraon Isolator and properly ghten it
using 3/16mm Allen Key.
NOTE: The Proaim Glide Shock Absorbing
System oers a 5-50 kg / 11-110 heavy payload
capacity.
CHANGEABLE WIRE BRACKETS
NOTE: It has two strategically congured Wire Brackets to support the gimbal & absorb
ineral movements. These Wire Brackets are removable, and any of them can be used in the
center when the camera setup weight is lighter. And the numerous universal threads 3/8"-16 &
1/4"-20 over it used for underslung and over-slung mounng of your gear.
7
YOUR PROAIM GLIDE 4-DIMENSIONAL VIBRATION ISOLATOR
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
