PROAIM CINEMA Series User manual

Falcon Pro Stabilized Camera Rickshaw Support (RCSW-FLCN-01)

Assembly Manua l

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

Robust Plaorm Jockey Wheel

with 360° Rotaon

with Break

Telescopic Push/Pull

Top Handle Rod Mount

Handle Support Rod

Rod Dia 42mm Telescopic

Handle

2 x Ratchet knob

Seat Mount

Bracket

2 x Wheels

Seat & Seat Post

Rod Adaptor

5mm & 6mm

Allen key

2 x Bolts 19mm

Spanner

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

2 x Foot Rest 2.5mm Allen key

5/16mm

Allen key

FEATURES

Telescopic Push/Pull Handle

Easy of Movement

length range from 32”- 54” allows ease of handling

Seat Post

Easy to Adjust Posion

360-degree movement

Main Chassis

Adjustable Height Posion

Seat Bridge

Adjustable Seat Post Posion

Wheels Height Adjustment

3 height adjustment points for adjusng

ground clearance at 5” or 6” or 7”

Robust Plaorm

with Mounng Opons

Adapts Euro/Elemac Gear

& Cheese Plates

Camera Accessory

Mount

Holds 200 kg/440lb Payload

Seat Break

Adjust the Seat Posion

Adjustable Operator Seat

Comfort & Convenience

Jockey Wheel with 360° Rotaon

with Break

Easy Maneuvering & Stability

Adjustable Footrests

Comfortable Long

Hour Shoong

• The Rod adapter already has four bolts.

Loosen and remove them with the help

of an Ellen key.

• Align the threads of the rod adapter and

the robust plaorm together and secure

them with bolts.

• Insert the Castor wheel into the rod

adapter hole and securely ghten it with

a 5/16mm Allen key.

• Tighten the bolts using a 5/16 Allen key.

• Remove the bush from the bolt. Aach it

to any of the three holes present on the

side of the rickshaw plaorm.

Falcon Rickshaw Setup

• Insert the bolt into the center hole of the

wheel. Then bolt this wheel through 3

holes present on the side of the plaorm.

Repeat the same process on the other

side of the plaorm.

• Tighten the bolts using a 19mm spanner

to secure the wheels to the plaorm.

• Mulple threads are provided on the

robust plaorm. Adjust and mount your

seat adaptor anywhere on the plaorm

as per your needs and re-ghten the

bolts using a 5/16mm Allen key.

• To adjust the seat mount adaptor, loosen

the ratchet knob and remove the bolts

with the help of a 5/16mm Allen key.

• Insert the seat bridge into the seat

mount adaptor and secure them

together with the ratchet knob.

Seat Posion

• The seat pole has a height adjusng

feature so you can easily set your seat up

and down. Lock the seat to your desired

posion using the seat break.

• Using a 2.5mm Allen key, loosen the bolt

of the handle support rod and remove it.

Align the handle support rod thread with

the thread on the telescopic chassis rod.

Note: There is a thread opon on the

telescopic chassis rod for aaching the

support rod.

• Pull the red pull pin and insert the main

chassis into the adjustable end mounts.

• Then insert the bolt into the telescopic

rod and secure it with an Allen key.

• Secure the main chassis using the ratchet

knob. To extend the length of the main

chassis, Insert rods on both sides of the

chassis and secure them using a 6mm

Allen Key.

• Using a 5mm Allen key, loosen the

telescopic push/pull handle rod mount

and adjust the length as per your needs.

Then, secure it using the same Allen key.

YOUR PROAIM FALCON PRO STABILIZED CAMERA RICKSHAW SUPPORT

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

• Secure the top handle rod mount and the

adjustable end mount together using an

Allen key.

• Now, Insert a rod (Not-Included) into the

rod mount accessory and securely

ghten it with the ratchet knob.

• Insert the footrest by aligning it with the

rickshaw plaorm thread. Then, secure it

correctly with the footrest knob, as

shown in the picture.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

most support and care unl you use our product.
