PROAIM SR-SBP-02 User manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Assembly Manua l

Base Plate 2 x Handles

Quantum Magnec Shoulder Rig w VCT

Base Plate (SR-SBP-02)

2 x 15mm Dia, Length

200mm Long Female Rods

2 x 15mm Dia, Length

300mm Long Female Rods

• Loosen the knob on the other side of the base

plate and insert the 300mm long rod.

• Then insert the second 200mm long rod and

ghten it properly with the knob, as shown in

the image.

NOTE: It has dual slots that allows quick

posioning of your camera & camera

accessories.

• Now aach the handle and ghten the ratchet

knob properly.

• Loosen the knob of the base plate and insert a

200mm long rod.

• Then insert the second 300mm long rod and

ghten the knob properly, as shown in the

image.

NOTE: There are 15mm (dia) rods on the front

and back to accommodate more camera

accessories.

Quantum Magnec Shoulder Rig Setup

NOTE: It allows your camera set up to sit

comfortably on your shoulders by eliminang

the discomfort caused by the camera's weight

on your shoulder during shoong.

• By pressing the adjustment knob, the angle of

the handle can be changed according to your

requirement, as shown in the image.

• Mount the camera (Not Included) on the

shoulder pad and ghten it properly with the

help of a screwdriver.

NOTE: The shoulder plate has 1/4"-20 and

3/8"-16 threaded holes for storing addional

screws. It has a 3.5" long slot that allows quick

posioning of your camera & accessories to

evenly distribute the weight of your camera.

• Then aach the second handle and ghten it

properly.

• Open the shoulder pad, as shown in the

image.

NOTE: It has a magnet mount system that allows

easy access to the camera screws just by ipping

the camera base plate.

YOUR PROAIM QUANTUM SHOULDER RIG W VCT MOUNT

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

NOTE: Shoulder base plate also supports RED

(DSMC2), Arri (Amira and Alexa Mini), Sony

(Venice, FS7, FS7M2, F5, F55, EX1, EX3), Canon

(C200, C300, C300M2, C700), Panasonic (EVA1,

Cinema Varicam LT 4k S35), Blackmagic (Ursa

Mini), and many other camera models with

interchangeable lenses.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.
