PROAIM Kite-22 Ultimate Package User manual

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Kite-22 Crane Starter Package (KITE-22-STARTER)

Ass e mb l y M a n u a l

Proaim 24.5 Long Telescopic Camera Jib Crane

Proaim 150mm Bowl Jib Stand (LW-150)

D 33 Pro Camera Dolly

Proaim Customized Storage Cases for Camera Jib Arm , Jib Stand & Accessories

Complimentary Tools and Tool Pouch/Wrap

Packaging Material of Box 1 & 2: 7x Jib Secons

Packaging Material of Box 3: Accessories of Jib Crane

Hub Mounng

Head Plaorm with Bolt, Sha

Collars, Washers and Nut

6x Shank for Joining Arms

6x Locking Pins

Levelling Cable

Turnbuckle

Joysck Controller Bracket

First Box includes

Jib Secons

Second Box includes

Jib Secons

Third Box includes

Accessories of Jib Crane

Fourth Box includes

Jib Stand

Fih Box includes

Dolly Pack

NOTE: We send the Jib secons in two boxes. One box has the secons with pipe packing and the other

box (cardboard box) has the rest of the secons. We only send one pipe packing for the jib secons. We

send the Dolly in cardboard box.

Packaging Material of Box 4: LW-150 Jib Stand with (P-RB-SP) Spreader

LW-150 Jib Stand

(P-RB-SP) Spreader

Packaging Material of Box 5: Dolly

D-33 Pro Camera Dolly Dolly Foots

Safety Hints

ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT DAMAGE TO EQUIPMENT

& OPERATOR!

The crane may not be assembled or operated under inuence of alcohol, drugs or any other intoxicang

substances. Lack of aenon while connecng the components together can cause substanal damage

to equipment / operator.

The crane may only be operated on levelled horizontal posion. Make sure that the surface is stable.

To prevent any harm or injury, properly join all secons of the crane. It is suggested to use the support

stand while telescoping the complete length.

Always connect the steel cables properly to provide stability to the system.

They should not negavely impact the movements of crane in any way.

Aer setup of the crane, the pan-lt head / gimbal head shall be posioned under the central pivot

secon. In assembled state, when the pan-lt head / gimbal head is higher than central pivot secon,

there should be someone to look aer the crane system.

The complete panning & liing range around it must be kept free. Avoid anybody standing under the

crane. No loose objects may be stored or placed on it. Be very careful while using indoors.

Never operate the crane in the immediate vicinity of high-voltage power cables. It holds danger to life.

Parcular care is required when operang the crane in unfavourable weather condions. The crane

must be shut down in sucient me. When it is used in a rainy day, the pan-lt head / gimbal head and

controlling bar shall be protected against rain.

When you want to transport the crane, lock the Pan & Tilt Axis for safety. Make sure that the

components do not rub together and cause any material wear.

Before the counterweights are removed, ensure the remote head is resng on the support stand. Then

gradually remove the counterweights before remote head, camera or other parts.

In the interest of safe crane operaon, avoid abruptly swivelling or stopping the crane, otherwise it may

cause serious damage to equipment.

FOLLOWING THESE GUIDELINES WILL PROVIDE BETTER SHOTS AND TROUBLE FREE OPERATION.

SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS AVAILABLE ‘ONLINE’ BY

CONTACTING THE SALES REPRESENTATIVE.

Now take out the Tripod Stand from its case,

and stretch its legs on oor as per the

requirement. Then ghten the knob to

secure it.

Match holes of the boom leg secon with

the upper leg secon to secure tripod stand

with Steel locking Pins and ghten the knob.

Jib Stand Setup

NOTE: We have provided double locking

precauons on Jib Stand. Pin is rst and primary

locking knob is secondary locking so rst lock

the Pin to avoid slipping of stand.

Take out Spreader and spread it on oor and

open the legs (as per your requirement) of

spreader with the help of provided knob.

Put tripod stand on spreader & then lock it in

place with the rubber grips. (Note: Tighten

the ratchet knob of stand to secure it with

rubber grips.

Knob

Spreader Setup

NOTE: For seng up your desired package with spreader or with oor dolly follow the below steps:

To open the legs of Dolly remove the bolts &

fully spread it on oor.

Then insert the bolts with their washer and

ghten the bolts properly.

Dolly Setup

NOTE: To keep the dolly in stac posion, lock

the wheels by pushing down the lever.

Remove the allen bolts from tripod holders.

Match the hole of Tripod holder with dolly to

insert the long bolt & ghten it with the help

of allen key.

NOTE: This dolly has various holes for exible mounng of Tripod.

Once all the above menoned steps are

completed, you will see the stand and

spreader as shown here.

Then ghten the provided knob of tripod

holder.

Install the Hub Assembly by sliding from the

boom side into the stand’s Mount opening.

Hub Secon Setup

NOTE: The Hub Assembly has several mounng holes. You can mount LCD Monitor or Joysck box to

this assembly if you want.

Remove ratchet knobs of the stand, Insert

the tripod legs into the foots on the dolly.

NOTE: This is the Pan Fricon Knob. Never pan the Jib with this knob ghtened. If this knob turns while

panning, it is too ght. Only ghten while parking the jib!

Insert the provided washer & knob to secure

the jib properly.

Insert the bolts with washers and ghten

properly with the help of Wrench.

Insert rear tube secon (secon 1) into the

hub assembly, slide secon 2 into secon 1

and align holes of the Secon 1 and secon 2

with the central hole of hub assembly.

Already aached 1st or 2nd jib secons,

insert it onto the hub then insert the long

bolt and nut to Secure the secons properly.

Jib Secons Setup

Repeat this process for rest of the secons.

Aach them towards the other Secon 6 with

5 , 5 with 4, 4 with 3, 3 with 2 & 2 with 1. 321

Aer alignment of holes (Jib arms) insert

hank lock pin & ghten it from another side

with hank threaded cap. For double security

insert the locking pin from the top of jib arm.

NOTE: We have provided double locking precautions on Jib, Knob is first and primary and pin is

secondary locking so first lock the knob to avoid slipping of sections.

Remove the bolt from head secon then

aach with the jib.

Head Secon Setup

 Aach the provided bolt, sha collars,

washers and nut. Tighten all the Allen bolts

and nuts to secure properly as shown in the

image.

 Connect the one end of Head Plaorm

Levelling cable with the head plaorm by

hooking the turnbuckle ends.

 To mount Rear secon, of jib secon and

insert the bolt with washers through one end

of the secon to other. Slide the bolt

through and hand ghten

NOTE: Install the pan lts head (Not included).

Rear Frame Setup

 And other end aach with the hub assembly.

 Add weights (Not Included) to the rear

weight secon at both sides and ghten the

weight closer knobs to secure properly.

Adding Weights Setup

 As each secon is pulled from the previous

secon, you can store unused secons in the

tail as ballast weight and lighten your

counterweight demand.

Balancing the camera on the head is crical to smooth operaon.

 Find the horizontal balance point of your camera by using 2 ngers of one hand while holding handle.

 Mark this point on the side of the camera with chalk or tape.

 Turn the unit on and move the lt control unl the camera plate is vercal.

 Loosen the two screws holding lt motor. (DO NOT REMOVE)

 Grasp the motor and turn slightly to disengage gears.

 Mount the camera to the camera plate with the screw provided.

 Tighten by threading the nut up to the boom of the camera plate securely.

 Make sure your balance point previously marked with chalk or tape is in the middle of the plate.

 Loosen the knob below the camera plate and slide the camera and plate up or down unl the center

line of your camera is about in the middle of the large gear. Now ghten knob.

 If the camera is perfectly balanced it will stay in any posion while motor gear is sll unaached.

 Grasp the motor and turn it back unl the gears mesh.

 Gently ghten motor screws.

 Secure the camera.

NOTE: All reducon boxes have a small amount of backlash. The balancing of the camera will reduce the

backlash to a minimum making it felt at the top of the lt arc.

Balancing

 With the camera set up as previously described above, Power ON by pressing the RED Switch on the

top of the Joystick control box.

 For inverted use, disconnect the leads to the motors, rotate the control box 180 degrees and re-install.

NOTE: Remember practice makes perfect and always watch the cables for binding.

Opreaon

Counterweights

The Jib is setup with “plate weights” or bar bells” style weights. Plate weights come in several weights and

diameters. They get smaller as the weights get lighter. The largest (25lbs) is about 11 inches in diameter.

The mounng hole is 1” in diameter for all weights. The jib has a varying weight rao depending on the

length you have chosen. The 24.5 arm itself balances at about 121.5 lbs. Just mulply the weight, of the

addional items you will put on the end of the arm, by 5 and you will know how much weight to buy. Buy

a few extras in case you add other accessories.

The lighter weights will allow you to “ne tune” once you’re ready to go.
