PROAIM CINEMA Series User manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

SuperX Professional Electronic Camera Stabilizer (ST-SPRX)

Assembly Manual

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

Proaim Super-X Stabilizer

Inbuilt Cables:

6 pin lemo to 6 pin lemo connector main cable

SDI Video Cable

Docking Bracket with Tighten knob

Camera Screw

2x 1/4"-20

2x 3/8"-16

1 x 2 pin lemo to 4pin female

XLR Connector

1 x 2 pin lemo to DC Connector 2x BNC male to BNC male connector

1 x 3 pin lemo to 4pin female

XLR Connector

1 x 3 pin lemo to DC

Connector (4mm ,3/16mm) Allen Key

Funcons

Camera plaorm

Front Rods (Dia:15mm)

Easy micro adjustments on X-Y axis.

Precision Gimbal for 4th-axis grip

All-aluminum CNC machined

construcon

Monitor Mount Baery rotates

180° to suit user Preference

Monitor Mount Bracket rotates

360° & Height Adjustable

Extended length Post

Handle is adjustable for

more convenience.

Video cable

Power cable

Both side baery

mount opon

Baery plate Rotate 180°

Baery Plate only 1 side

opon

2 Wire inbuilt in stabilizer

1. Main cable

2. SDI Output Cable

Micro balancing adjustment

knobs

Uses of Head Connector (upto 3Amps current holding capacity)

Main: As per your voltage needs, aach the lower main output

cable to the top main cable.

Dual 8V/15V OR 12/24 Volt LEMO Connector

BNC: High denion video connectors

Uses of Boom Connector of Single baery (12v/15v)

Main wire to camera plate:

Output: 12v/15v

Switch On/o Buon

Main wire to camera plate

Output: 8v/12v

BNC Video Connector

Power LED Signal

Dual D-Tap Ports

12v connectors for LCD & Other

Related Accessories

Uses of Boom Connector of Double Baery (15v/24v) (upto 3Amps current holding capacity)

Main wire to camera plate

Output: 15v/24v

15v Power Connectors for LCD &

Other Related Accessories

BNC Video Connector

Power LED Signal

Dual D-Tap Ports

Switch On/o Buon

On connecng the 15v power

cable, a signal will be shown in

Power LED.

24v connector for LCD & Other

Related Accessories

2. Aach the Stabilizer post to the u-shape frame

on the docking bracket. Push back the bracket

pin, securing the stabilizer in the bracket.

 Loosen the knob of the docking bracket, put

the bracket on the stand and re-ghten the

knob to lock the docking bracket in place.

Use sandbags to stabilize the stand for security

purpose.

Stand and Docking Bracket Setup

 To increase the telescopic length of the

stabilizer, loosen Allen bolts on the central

post accordingly.

1. Rotate the rod, insert it thoroughly into the

bracket and lock it so that the front pin of the

docking bracket faces upwards, as shown in the

image.

There are 2 methods to mount your super-x stabilizer onto the docking bracket.

 Mount the stabilizer handle (gimbal mount) on

the front pin.

 Note: Aer the stabilizer handle mounng on

the pin, there will be a gap between the

stabilizer and the c-stand.

 Each knob has a twin on either side of the stage

to adjust the stabilizer's balance from either

side. The knobs turn clockwise on one side and

counter clockwise on the other side for the

same stage movement.

 Now aach Ball Head to the LCD mount

bracket on the stabilizer and lock it with the

bolt. Fix LCD monitor (Not Included) onto Ball

Head.

 Loosen the side knob to lt your LCD Monitor

up to 180°, as per your requirement.

Micro Adjustments on X-Y Axis

Maximum Rigidity and mounng opon in

Dovetail plate

 You can directly aach your camera with the

Dovetail plate.

 Slide in your camera onto the Stabilizer and

ghten both side knobs to secure your camera

correctly.

 With the balancing done and the camera

locked in place, ne balancing can be nished

with the drives.

 Baery Plates can be rotated 180°. Loosen the

allen bolts and adjust the posion as per your

requirement.

 Slide the camera plate onto the stabilizer and

lock it with the side knob. Then insert your

compable camera.

 You can also aach the camera plate to the

dovetail plate. This plate has safety stops on

the ends and several holes for mounng

screws.

Assembly of cables

 Aach the power cable to the main output

connector as per your camera requirements.

 Main Connector consists of two types of Power:

Single side power 8/12

Double side power 15/24v

 Switch on the buon, and you will see a power

LED light signal.

On/o

LED Signal

 Similarly, aach the upper inbuilt main cable to

the camera plate.

 2nd inbuilt top cable can be used for video

output.

 Supply power to your camera by aaching one

end of the 3 pin lemo to 4 pin female xlr

connector cable to the camera plate and 2nd

end to the camera.

 Note: there are two types of power points on

the camera plate. Aach the cable to the

respecve connector as per your camera needs.

 Supply power to your LCD by connecng 2 pin

lemo to DC Connector to the stabilizer’s

power-point and aaching it to the LCD. Check

the power point and use it as per your LCD

power requirements.

 Aach 2nd lower inbuilt cable to the LCD.

BNC male to BNC male connector

We have provided 2 types of LCD cables

1. 2 pin lemo to DC Connector 2. BNC male to BNC male connector

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.

YOUR PROAIM SUPERX VIDEO CAMERA

STABILIZER

ALL DRESSED UP AND READY TO GO!
