Philips MCM398D/12 User manual

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

FM antenna Remote Control

Quick Start Guide

User manual

MCM398D

Pull out the plastic

protective sheet

before use.

1 Dock & 8 Dock

Adapters for iPod

MCM398D QUGG_Eng 2007.4.17, 13:231

Connect the speaker cables.

Connect the FM antenna.

Connect the AC power cord of the system.

Tip

See the User Manual for how to connect other

equipment to this system.

FM wire antenna

AC power cord

Speaker

(left)

Speaker

(right)

DOCK IN

MCM398D QUGG_Eng 2007.4.17, 13:232

Enjoy

Playing a disc

Press OPEN/CLOSEçto open the disc tray and load in a disc, then press the same

button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Press ÉÅ to start playback.

To stop playback, press 9.

Setting the clock

IMPORTANT!

– To set clock in the Eco Power mode, press and hold ECO POWER/

STANDBY-ON

on the set for 3 seconds or more to switch to normal

standby mode first before proceeding with the procedures below.

In standby mode, press and hold CLOCK/RDS on the remote control.

➜ SET CLOCK is displayed briefly.Then, the clock digits for the hours flash.

Press 9on the remote control to select clock mode.

➜"12 TO 24 HOUR" or "24 TO 12 HOUR" scrolls once.Then, the clock

digits for the hours continue to flash.

Adjust VOLUME -/+ (or press VOL +/- on the remote control) to set the

hours.

Press CLOCK/RDS again.

➜The clock digits for the minutes flash.

Adjust VOLUME -/+ (or press VOL +/- on the remote control) to set the

minutes.

Press CLOCK/RDS to confirm the time.

MCM398D QUGG_Eng 2007.4.17, 13:233

Enjoy

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more (or USB/AUX on the remote control) to select USB.

Play the USB’s audio files as you do with the albums/tracks on a CD.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

Programming and tuning to

radio stations

Press SOURCE on the front panel repeatedly (or FM on the remote

control) to select the FM source.

Press PROG for more than two seconds to program all available stations.

Press ALBUM/PRESET 4or 3until the desired preset station is displayed.

MCM398D QUGG_Eng 2007.4.17, 13:234

Portable player

Dock

Speaker

(left)

Speaker

(right)

DOCK IN

Playing iPod using the dock

1Select the correct dock adaptor supplied, then snap the adaptor into the dock connector (iPod) to provide a snug

fit for the player.

● The indication on the adaptor’s back fits specific iPod player.

2Correctly place your player in the dock connector.

3Connect the cables of the dock to DOCK IN jacks on the main set correspondingly.

4Press SOURCE on the set repeatedly (or iPod on the remote control) to select iPod source.

● The connected player will play automatically.

● The iPod battery will be charged in either normal standby mode or power-on mode.The charging will not be available in

the Eco power standby mode.

Tip

Refer to the user manual supplied for detailed descriptions of “Compatible portable

player”, “Selecting the correct dock adaptor”,“Installing the dock adaptor”, and the

important notes for dock operation.

Dock cable

Enjoy

CRoyal Philips Electronics N.V. 2007

PDCC-SY/ZC-0714 GB

MCM398D QUGG_Eng 2007.4.17, 13:235
