Philips FWM592/BK User manual

Quick start guide

FWM592

MP3 link cable

What’s in the Box?

You should find these items upon opening the box.

AM antenna Remote Control

Quick Start Guide

User Manual

Quick Start Gulde

User Manual AC power cord

FM antenna

FWM592_BK_QSG_Eng 5/8/08, 10:311

SetupSetup

Setting the clock

Connect the speaker cables.

Connect the AM and FM antennas.

Connect the power cable of the system.

Tip

See the User Manual on how to

connect other equipment to this

system.

In standby or view clock mode, press PROG/CLOCK (or CLOCK on the

remote control) once.

Press ALBUM/PRESET +/- (or ALBUM +/- (à/ á) on the remote

control) to select clock mode.

Press PROG/CLOCK (or CLOCK on the remote control) again to

activate and adjust clock time.

Press ALBUM/PRESET +/- (or ALBUM +/- (à/ á) on the remote

control) repeatedly to set the hour.

Press S/ T(or TITLE - / + (í/ë) on the remote control)

repeatedly to set the minute.

Press PROG/CLOCK (or CLOCK on the remote control) again to store

the setting.

AC power cord

Speaker

(right)

Speaker

(left)

FM antenna AM antenna

FWM592_BK_QSG_Eng 5/8/08, 10:312

Enjoy

Playing a disc

Press OPEN•CLOSE to open the disc tray and load up to two

discs on the individual disc trays.To load the third disc, press DISC

CHANGE.

➜Make sure the label side of each loaded disc is facing up.

Press OPEN•CLOSE again to close the disc tray.

Use DISC 1/2/3 (or CD 1/2/3 on the remote control) to select a

disc for playback.

To stop playback, press 9.

Programming and tuning to radio

stations

Press TUNER repeatedly to select the tuner source.

Press PROG/CLOCK (or PROGRAM on the remote control) for

more than two seconds to program all available stations in order of

waveband.

Press ALBUM/PRESET +/- (or TITLE - / + (í/ë) on the

remote control) until the desired preset station is displayed.

FWM592_BK_QSG_Eng 5/8/08, 10:313

PDCC-ZYL-0818

Insert the USB device’s USB plug into the socket on the set.

Press USB to select the USB source.

Play the USB’s audio files as you do with the albums/tracks on a CD,

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

CRoyal Philips Electronics N.V. 2008

http://www.philips.com

Ripping function

Insert a USB mass device with sufficient free space to the USB DIRECT socket on

the set.

Prepare the source to record from.

Press USB RECORD to start ripping.

At any moment, simply press 9to stop ripping.

Enjoy

FWM592_BK_QSG_Eng 5/8/08, 10:314
