Philips FWD790 Instruction manual

Use this simple and quick way to

watch your favourite DVD movie

and enjoy your Home Cinema

experience!

Helpful Hints

You only need to make one video connection to your TV in

order to view the DVD playback.

If yourTV has S-Video or Component

(Pr PbY) video jacks, use one of these

video connections instead for higher

picture quality.

If yourTV has only a single Antenna In jack,

you will need an accessory RF modulator. The RF

modulator converts the video from the DVD system

so it can play through theTV’s Antenna connector.

Refer to your owner’s manual for proper

connection.

When listening to TV programs, press AUX/GAME

button on the remote to set the DVD system to AUX mode

in order for the sound to be heard.

FWD790

Rear of TV

(example only)

Speaker

(right)

Speaker

(left)

Game console

(example only)

SPEAKER 8

•

AV IN

Detailed playback features and additional functions are described in the

accompanying owner’s manual

Make sure your DVD system and TV are connected and turned on!

Plug & Play

1Turn on the system.

“AUTO INSTALL - PRESS PLAY” will be displayed.

2Press PLAY 2; on the system to start installation.

Playing a disc

3Press DISC1/2/3 on the remote control.

You can also select the DISC (DISC10203) on the front panel.

4Turn on the TV and select the correct Video In mode.

You should see the blue Philips DVD background screen on theTV (If no disc in the DVD system).

5Press OPEN0CLOSE 0on the front of the DVD system and load discs, then press

the corresponding OPEN0CLOSE 0again to close the disc tray.

Make sure the disc label is facing up. For double-sided discs, load the side you want to play face

down.

6Playback will start automatically.

If a disc menu appears, use 1/¡/5/4buttons on the remote to make the necessary selection,

then press OK to confirm. Or, use the numeric keypad on the remote to select features. Follow

the instructions given in the disc menu.

7To stop playback, press STOP 9.

Playing Game

8Press AUX/GAME to select GAMEPORT mode.

9Turn on the TV and select the correct Video In mode.

10 Press MIX-IT to mix the game sound to your desired music source.

11 Start playing your favorite game.

Region Codes

DVDs must be labeled for ALL regions or Region 3,

in order to play on this DVD system.

ALL

You should find the below accessories in the packaging box.

Audio cables

(white, red)

component video

cables (red, blue,

green)

MW loop

antenna

Composite video cable

(yellow)

AA size

batteries

AC power cable

FM wire antenna
