Philips BTD5210 User manual

www.philips.com/support

BTD5210

User manual

Always there to help you

Question?

Contact

Philips

1EN

Contents

1 Important 2

Safety 2

2 Your micro system 3

Introduction 3

What's in the box 3

Overview of the main unit 4

Overview of the remote control 5

3 Connect 7

Place the unit 7

Connect speakers 7

Connect FM antenna 7

Connect video/audio cables 8

Connect an external audio device 8

Connect power 9

4 Get started 10

Prepare the remote control 10

Set clock 10

Activate demonstration mode 10

Turn on 11

Find the correct viewing channel 11

Select the correct TV system 11

Change system menu language 11

5 Play 12

Play from disc 12

Play from USB or recored discs 13

Play a slideshow with background music 13

Resume video play from last stopped

point 13

Control play 14

Play options 14

Change the audio channel 14

6 Enjoy karaoke 15

Adjust Karaoke settings 15

7 Listen to the radio 16

Tune to a radio station 16

Program radio stations automatically 16

Program radio stations manually 16

Select a preset radio station 16

8 Play from Bluetooth-enabled

devices 17

9 Other features 18

Set the alarm timer 18

Set the sleep timer 18

Listen to an external device 18

10 Adjust settings 19

General setup 19

Video setup 19

Audio setup 20

Preferences 20

11 Product information 22

Specications 22

Supported disc formats 23

USB playability information 23

12 Troubleshooting 24

13 Notice 26

Declaration of conformity 26

2EN

1 Important

Safety

• Make sure that there is enough free space

around the product for ventilation.

• Only use attachments or accessories

speciedbythemanufacturer.

• Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

product:

• Install the battery correctly, + and - as

marked on the product.

• Remove the battery when the product

is not used for a long time.

• The battery shall not be exposed to

excessiveheatsuchassunshine,reor

the like.

• The product shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

product(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

• Never remove the casing of this device.

• Never lubricate any part of this device.

• Never place this device on other electrical equipment.

• Keep this device away from direct sunlight, naked

amesorheat.

• Never look into the laser beam inside this device.

• Ensure that you always have easy access to the power

cord, plug, or adaptor to disconnect this device from

the power.

3EN

2 Your micro

system

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this unit, you can:

• Watch video from DVD/VCD/SVCD, or

USB storage devices;

• enjoy audio from discs, Bluetooth-enabled

devices, USB storage devices, or other

external devices;

• enjoy Karaoke by connecting a microphone.

• view pictures from discs or USB storage

devices;

• listen to FM radio stations.

You can enrich sound output with below

sound effect:

• Digital Sound Control (DSC)

• DSC 1: Balanced

• DSC 2: Clear

• DSC 3: Powerful

• DSC 4:Warm

• DSC 5: Bright

The unit supports these media formats:

DVD region code Countries

Europe

What's in the box

Check and identify the contents of your

package:

• Main unit

• 2 x speakers

• 1 x power cord

• 1 x composite video cable (yellow)

• 1 x FM antenna

• Remote control (with two AAA batteries)

• Short User Manual

• Safety&Notice Sheet

4EN

Overview of the main unit

• Turn the unit on or off.

• Switch to standby mode or Eco

standby mode.

b Display panel

• Show the current status.

• Socket for a USB storage device.

d /PAIRING

• Start, pause, or resume play.

• In the Bluetooth source, press and hold

to enter pairing mode.

e MIC IN

• Connect a microphone.

f Disc compartment

• Stop play.

• Erase a programed radio station.

• Activate/deactivate demonstration

mode.

MIC IN

h /

• Skip to the previous/next track, title or

chapter.

• (Press and hold) Fast backward/

forward within a track/disc/USB.

• Tune to a radio station.

• (Press and hold) search for radio

stations automatically.

• Open/close the disc compartment.

j SRC

• Select a source: DISC, USB, FM, AUX

IN, BT.

k VOLUME

• Adjust volume.

• Adjust time during alarm/sleep timer

setting.

5EN

Overview of the remote

control

a /STANDBY

• Turn the unit on or off.

• Switch to standby mode or Eco

standby mode.

• Access the system menu.

c DISPLAY

• View playback information.

d / ( / )

• Navigate through the menu.

• Search within a track/disc/USB.

• Tune to a radio station.

e SUBTITLE/PRESET + ( ) /

AUDIO/PRESET -( )

• Navigate through the menu.

• Skip to the previous/next album.

• SUBTITLE ( ): Select a preset radio

station.

• AUDIO ( ): Set the subtitle language.

• Set time.

STANDBYEJECT

• Return to the previous display menu.

g +/-

• Adjust volume.

h /

• Skip to the previous or next title,

chapter,track,orle.

i Numeric buttons

• Select a title/chapter/track to play.

• Select a preset number.

j MENU

• Access DISC/USB/iPod/iPhone/iPad

menu.

k OPTION

• In DISC/USB play mode, press to

select preferred play options.

l PROG/CLOCK SET

• Program radio stations.

• Set the clock.

• View clock information.

m TIME/SLEEP

• Set the alarm timer.

• Set the sleep timer.

n RDS

• For selected FM radio stations, display

information of Radio Data System

(RDS).

o /PAIRING

• Start, pause, or resume play.

• In the Bluetooth source, press and hold

to enter pairing mode.

• Stop play.

• Mute or restore volume.

r SOUND

• Enrich sound effect with Digital Sound

Control (DSC).

s OK

• Conrmaselection.

6EN

t SOURCE

• Select a source: dock, BT (Bluetooth),

DISC, USB, FM, AUX.

u EJECT

• Press to open or close the disc

compartment.

7EN

3 Connect

Place the unit

1 Place the unit near the TV.

2 Place the left and right speakers at equal

distance from the TV and at an angle

of approximately 45 degrees from the

listening position.

Note

• To avoid magnetic interference or unwanted noise,

never place this apparatus and speakers too close to

any radiation devices.

• Place this unit on top of a table.

• Never place this unit in an enclosed cabinet.

• Install this unit near the AC outlet where the AC power

plug can be easily reached.

Connect speakers

Note

• For optimal sound, use the supplied speakers only.

• Connect only speakers with impedance that is the

same or higher than the supplied speakers. Refer to the

Specicationssectionofthismanual.

1 Holddownthesocketap.

2 Insert the stripped part of the wire

completely.

• Insert the right speaker wires to "R",

left speaker wires to "L".

• Insert the red wires to "+", black wires

to "-".

3 Releasethesocketap.

Connect FM antenna

Tip

• For optimal reception, fully extend and adjust the

position of the antenna.

• For better FM stereo reception, connect an outdoor

FM antenna to the FM AERIAL socket.

• The device does not support MW radio reception.

• Connect the supplied FM antenna to the

FM AERIAL socket on the back of the

device.

VIDEO OUT

VIDEO

DIGITAL OUT

AERIAL

SUBWOOFER

OUT

AUX IN

LR FM

AC IN ~

SPEAKER OUT

8EN

Connect video/audio cables

Select the best video connection that the TV

can support.

• Option 1: Connect to the HDMI socket

(for an HDMI, DVI or HDCP-compliant

TV).

• Option 2: Connect to the composite

video socket (for a standardTV).

Option 1: Connect to the HDMI

socket

• Connect an HDMI cable (not supplied) to:

• the HDMI (DIGITAL OUT) socket on

this unit.

• the HDMI input socket on the TV.

Tip

• If the TV has a DVI connector only, connect via an

HDMI/DVI adaptor. Connect an audio cable for sound

output.

• If this unit connects to a TV compatible with 1080p

or 1080p/24Hz, Philips recommends HDMI category

2 cable, also known as High Speed HDMI cable, for

optimal video and audio output.

• This type of connection provides the best picture

quality.

Option 2: Connect to the composite

video socket

• Connect a composite video cable to:

• the VIDEO (VIDEO OUT) jack on

this unit.

• the VIDEO input socket on the TV.

Tip

• The video input jack on the TV might be labeled as A/V

IN,VIDEO IN, COMPOSITE or BASEBAND.

Connect an external audio

device

You can route audio from an external audio

device to this unit.

If the external audio device has analog audio

output sockets (such as your TV):

• Connect audio cables (red/white - not

supplied) to:

• the AUDIO-IN(Land R) sockets on

the back of the unit.

• the audio output sockets on the

external audio device.
