Parkside PVL 1 A1 User manual

DOUBLE PAD SUCTION LIFTER / DOPPELSAUGHEBER /

VENTOUSE DE LEVAGE DOUBLE PVL 1 A1

IAN 405827_2201

DOPPELSAUGHEBER

Bedienungsanleitung

VENTOUSE DE LEVAGE DOUBLE

Mode d’emploi

DOUBLE PAD SUCTION LIFTER

Operating instructions

DUBBELE ZUIGNAPDRAGER

Gebruiksaanwijzing

DVOJITÝ SACÍ ZVEDÁK

Návod k obsluze

PODNOŚNIK Z DWOMA

PRZYSSAWKAMI

Instrukcja obsługi

SOLLEVATORE A VENTOSA

DOPPIO

Istruzioni per l’uso

ZDVÍHADLO S DVOMI

PRÍSAVKAMI

Návod na obsluhu

DUPLA TAPADÓKORONGOS

EMELŐ

Használati utasítás

LØFTER MED DOBBELT

SUGEKOP

Betjeningsvejledning

VENTOSA DOBLE

Instrucciones de uso

DVOJNI PRIPOMOČEK ZA

DVIGANJE S PRISESKI

Navodila za uporabo

GB / IE Operating instructions Page 1

DE / AT / CH Bedienungsanleitung Seite 9

FR / BE Mode d’emploi Page 17

NL / BE Gebruiksaanwijzing Pagina 25

CZ Návod k obsluze Strana 33

PL Instrukcja obsługi Strona 41

SK Návod na obsluhu Strana 49

ES Instrucciones de uso Página 57

DK Betjeningsvejledning Side 65

IT Istruzioni per l‘uso Pagina 73

HU Használati utasítás Oldal 81

SI Navodila za uporabo Stran 89

max. 45

max.

PVL 1 A1 GB│IE │ 1 ■

Contents

Introduction......................................2

Intended use .....................................2

Safety ..........................................2

Package contents .................................4

Technical speciﬁcations.............................4

Use .............................................5

Cleaning and storage..............................6

Disposal.........................................6

Service ..........................................7

Importer ........................................7

IB_405827_PVL1A1_LB8.indb 1 25.07.2022 15:54:39

PVL 1 A1

■ 2 │ GB│IE

Introduction

Congratulations!

You have purchased a high-quality product. Familiarise yourself

with the product before using it for the ﬁrst time. To do this, read

the following operating instructions thoroughly. Use the product only as

described and for the speciﬁed range of applications. Keep these

operating instructions in a safe place. Please also pass these operating

instructions on to any future owner.

Intended use

This product is designed exclusively for lifting, carrying and holding

objects with a ﬂat and non-porous surface, such as glass, metal, plastic

or polished stone. The horizontal load capacity is max. 60kg and the

vertical load capacity is max. 45kg.

Commercial or industrial use is not permitted. No liability will be assumed

in cases of improper use. No liability will be assumed for damage caused

by misuse or improper handling, the use of force or unauthorised modiﬁ-

cation. The risk is borne solely by the user.

Safety

■ Do not allow children to play with the packaging material! Keep all

packaging materials away from children.

■ Do not allow children to use the product unless they are being super-

vised. Children are not always able to correctly recognise potential

dangers.

This product is not a toy.

IB_405827_PVL1A1_LB8.indb 2 25.07.2022 15:54:39

PVL 1 A1 GB│IE │ 3 ■

■ This product is not intended for use by individuals (including children)

with reduced physical, sensory, or mental capacities. It may also not

be used by individuals who lack experience and/or knowledge unless

they are supervised by a person responsible for their safety or have

received instructions on how to use the product from such a person.

■ For your own safety, always wear protective gloves and

safety shoes when working with the product.

■ Check the product before every use to make sure it is in perfect condi-

tion. Even slight damage to the surface of the suction cups can have a

signiﬁcant impact on the suction power. Do not use the product if it is

damaged in any way.

■ Use the suction cups to attach the product only to a smooth, grease-

free, dry and clean surface. Otherwise there is a risk that the suction

cups will not adhere suﬃciently.

■

max.

Do not exceed the product's maximum loading

capacity. The horizontal load capacity is max. 60kg

and the vertical load capacity is max. 45kg.

■ Check the suction power of the suction cups after each application

of the product to an object.

■ The product should not be used in combination with

a crane and is not suitable for machine-operated use.

The product is suitable for hand-operated use only.

■ Lifting objects over people is prohibited.

■ Using the product as a safety device or as a handhold is prohibited.

■ This product is intended solely for short-term use.

Permanent use, e.g. as a handhold, is prohibited.

IB_405827_PVL1A1_LB8.indb 3 25.07.2022 15:54:40

PVL 1 A1

■ 4 │ GB│IE

■ Items must be put down safely before releasing the suction cups.

■ Do not use sharp objects to detach the suction cups from the surface.

■ The load must be distributed evenly between both suction cups.

■ Ensure an unobstructed view during transport.

Package contents

▯ Double Pad Suction Lifter

▯ These operating instructions

Note: Check the package for completeness and signs of visible

damage. If the delivery is incomplete or damage has occurred as a

result of defective packaging or during transport, contact the service

hotline (see section Service).

Technical speciﬁcations

Horizontal load capacity max. 60kg

Vertical load capacity max. 45kg

Operating temperature −10°C to 40°C

Diameter of the suction cups 120 mm

IB_405827_PVL1A1_LB8.indb 4 25.07.2022 15:54:40

PVL 1 A1 GB│IE │ 5 ■

Use

♦ Check that the surface of the item you want to use with the product is

suitable (see ﬁg. A).

ATTENTION! Property damage! The surface must be smooth, free

of grease and clean. Porous or uneven surfaces are not suitable.

♦ Clean the surface of the item. Do not use corrosive, abrasive or

solvent-based cleaning agents. Dry the item (see ﬁg. B).

♦ Clean the suction cups with water. Dry the suction cups with a lint-free

cloth (see ﬁg. B).

ATTENTION! Property damage! Do not exceed the product's

maximum loading capacity. The horizontal load capacity is max.

60kg and the vertical load capacity is max. 45kg (see ﬁg. C).

♦ Position the suction cups on the item. The quick-release levers must

be open.

♦ Press the product gently against the item and ﬂip the quick-release

levers (see ﬁg. D).

♦ Be sure to check the suction power of the suction cups (see ﬁg. E).

♦ Once you have checked the suction power, you can lift, carry or

hold the item.

CAUTION! When opening the quick release lever, there is a risk

of trapping your ﬁngers. Make sure that none of your ﬁngers are

between the quick-release lever and the handle.

♦ To dismantle the product, fold down the quick-release levers and

remove the product from the item (see ﬁg. F).

IB_405827_PVL1A1_LB8.indb 5 25.07.2022 15:54:40

PVL 1 A1

■ 6 │ GB│IE

Cleaning and storage

ATTENTION! Do not use aggressive or abrasive cleaning agents,

as they can damage the surfaces of the product.

♦ Clean the surfaces of the product with a soft, dry cloth.

♦ Clean the suction cups with water. Dry the suction cups with a lint-free

cloth.

♦ Store the product in a clean, dry location out of direct sunlight.

Disposal

Dispose of the product via an approved waste disposal

company or your municipal waste disposal facility. Please

comply with all applicable regulations. Please contact your

waste disposal facility if you are in any doubt.

Your local community or municipal authorities can provide

information on how to dispose of the worn-out product.

The product and its packaging

are recyclable. They are

subject to an extended

manufacturer responsibility and

will be collected separately.

Dispose of the packaging in an environmentally friendly

manner. Note the labelling on the packaging and separate

the packaging material components for disposal, if necessary.

The packaging material is labelled with abbreviations (a)

and numbers (b) with the following meanings: 1–7: plastics,

20–22: paper and cardboard, 80–98: composites.

IB_405827_PVL1A1_LB8.indb 6 25.07.2022 15:54:42

PVL 1 A1 GB│IE │ 7 ■

Service

Service Great Britain

Tel.: 0800 404 7657

E-Mail: [email protected]

Service Ireland

Tel.: 1800 101010

E-Mail: [email protected]

IAN 405827_2201

Importer

Please note that the following address is not the service address.

Please use the service address provided in the operating instructions.

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

IB_405827_PVL1A1_LB8.indb 7 25.07.2022 15:54:42
