Oneway Bowl Steady User manual
Date Pur hased:
Manufa tured parts on this ONEWAY produ t are ba ked by a warranty period
of 5 years from the date of pur hase.
The Wheels and Bearings are not overed under this Warranty.
ONEWAY hereby agrees to repair or repla e, any defe ts due to faulty material
or workmanship, provided that:
1. The warranty period has not elapsed. Proof of pur hase date (sales re eipt
et .) is required prior to any repair taking pla e.
2. The produ t has not been altered or modified in any way.
3. The produ t has not been subje ted to misuse, abuse, negligen e, or was
not used stri tly in a ordan e with these instru tions.
4. Transportation osts in urred in returning the produ t to ONEWAY
Manufa turing is pre-paid by the ustomer.
This warranty does not over any osts or damages arising dire tly or indire tly
from the operation of this produ t.
No other guarantee, written or verbal, is authorized by ONEWAY
Manufa turing.
Our polic is one of continuous improvement. We therefore reserve the
right to change the specification and/or design without notice.
Bowl Steady
Instructions
•Tension Arm Assembly •
•Wheels (2) •
•1¼ Post •
•Base •
•Hardware Package •
•Clamp Block (lathe specific) •
Note: Clamp Block may be packaged separately
Contents O Package
Part No. 3248
1-8 0 0 -56 5 - 7288
Quality products, designed by Woodturners or Woodturners!
www.oneway.ca
291 Griffit Road Unit 1, Stratford, ON,
N5A 6S4, Canada
P one: 1-519-271-7611
Fax: 1-519-271-8892
E-Mail: postbox@oneway.ca
Interested in turning Spindles?
Manu acturers Warranty
An a essory head is available to turn your
Bowl Steady Rest into a Spindle Steady
Rest!
This head uses a s issor-like a tion to
lamp around the spindle, and is very easy
to setup and use. Simply move the Post
forward, atta h the head, and start turning.
Redu ing the vibration along a spindle
means a ni er finish to the pie e (i.e. less
time spent sanding) and a safer, more
pleasurable turning experien e. Spindle Stead Head Part No. 3308
Version 3.2 December 2010
Step 1.
Assemble the wheels (Fig. 2, No. 1) to the tensioning arms (Fig 1., No. 3) as
shown in the above diagram. Make sure you use the So ket Head Cap S rews
(Fig. 2, No. 3) whi h are in luded in the Hardware Pa kage.
Note: Scre (Fig. 2, No. 3) should be snug, hereas, the Nut (Fig. 2, No. 4) should
be tight.
Step 2.
Assemble the Tube (Fig 1, No. 2) to the Base Plate (Fig. 1, No. 1) using four
¼”- 20tpi x ¾” long So ket Head Cap S rews (Fig. 1, No. 4) whi h are in lud-
ed in the Hardware Pa kage
Step 3.
Atta h the Tensioning Bar Assembly (Fig. 1, No. 3) to the Post (Fig. 1, No. 2)
and tighten to the desired height.
Assembly Instructions
Figure 1.
How to use the Bowl Steady
Position the Bowl Steady to the front of the bowl. Next, bring the two wheels
up lose and perpendi ular to the rim of the bowl (or platter) you are turn-
ing. On e the Bowl Steady is in pla e, tighten down the lo king bolt to se ure
the Base to the lathe bed. Loosen off the nut and give the tensioning arms a
squeeze. When they are firm against the rim, tighten the nut and you are ready
to go.
Notes
1. Experiment ith different locations bet een the foot and rim of the bo l (or platter)
for best results.
2. The thinner the bo l is, the more the bo l rest ill help.
Hardware List Qty Location
Wheels 2 Fig. 2, No. 1
¼” SAE washer 4 Fig. 2, No. 2
¼” - 28 x 1½” socket head cap screws 2 Fig. 2, No. 3
¼” - 28 hex ut 2 Fig. 2, No. 4
3/16 short arm hex key 1
Base 1 Fig. 1, No. 1
Post 1 Fig. 1, No. 2
Te sio Arm Assembly 1 Fig. 1, No. 3
¼” - 20 x ¾” socket head cap screws 4 Fig. 1, No. 4
1
2
1
2
2
2
3
3
4
4
Figure 2.
