OfficeSource PL25071SH User manual

OFFICE FURNITURE

MODEL NO. PL25071SH

OFFICESOURCE.COM

Last Updated: 6/2022

ASSEMBLY INSTRUCTIONS

Remove all wrapping materials, including staples & packing straps before you start to assemble.

Check to be sure that you have all parts and hardware.

Keep all hardware parts out of reach of children.

Do not tighten all screws/bolts until all completely assembled.

IMPORTANT NOTE :

Z:\Office Furniture\ECONOWISE\OLD\Performance_logo.jpg

PAGE 1 OF 2

REV. 1

ASSEMBLY INSTRUCTION FOR OPEN HUTCH CABINET

COMPONENTS

HARDWARE

Place all wooden parts on a clean, smooth surface to prevent the parts from being scratched.

12 3

M4 x 65

Allen-Key

1 Pc

4 5 6

Klix Cam

8 Pcs

Cam Lock

8 Pcs

6 Hole

L-Bracket

4 Pcs

Screw

#6 x 58"

24 Pcs

KLIX CAM INSTRUCTIONS

Insert the cam with the arrow

pointing towards the hole in the

edge.

Line up Cam Lock,

turn clockwise.

1 2

Insert the Cam Lock into Klix

Cam. Turn Klix Cam to lock.

LEFT

RIGHT

PL 250XXSH_AI

Housing

Cap (Long)

8 Pcs

LEFT RIGHT

PL250OH

(Sold Separately)

Shelf Panel

2Pcs

Front Rail

2Pcs

ASSEMBLY INSTRUCTIONS

MODEL: PL25071SH

1 of 2.

Before assembly, please remove all parts from the carton, verifying that you have the correct quantities, and read all the instructions.

IN THE CARTON:

OFFICE FURNITURE

MODEL NO. PL25071SH

OFFICESOURCE.COM

Last Updated: 6/2022

ASSEMBLY INSTRUCTIONS

INSTRUCTIONS:

ASSEMBLY INSTRUCTIONS

MODEL: PL25071SH

2 of 2.

!ATTENTION !

Place all wooden parts on a clean, smooth surface to prevent them from being scratched.

Check to be sure that you have all parts and hardware. Remove all wrapping materials, including staples and packing straps before

you start to assemble. Do not tighten all screws/bolts until all completely assembled. Keep all hardware parts out of reach of children.

If any parts are missing, broken, damaged or worn, stop use of product until repairs have been made using factory authorized parts.

Failure to follow these warnings may result in injury.

Z:\Office Furniture\ECONOWISE\OLD\Performance_logo.jpg

PAGE 2 OF 2

REV. 1

Attach Shelf Panel (I) by using Cam Lock (1) and Klix Cam (2).

Attach L-Bracket (4) to Shelf Panel (A) & (B)

as shown. Tighten Screws (5) securely.

ASSEMBLY INSTRUCTION FOR OPEN HUTCH CABINET

PL 250XXSH_AI

LEFT

RIGHT

Peel Double Sided Foam

Tape and Mount it on

Table Top.
