Nortel BCM50 User manual

Part No. N0027160 01

08 April 2005

BCM50 Telephone Features

User Guide

Page 2

Telephone button icons

Use this guide as a quick reference for accessing the features of your telephone. More

application-specific feature information is available in the following documents:

• CallPilot Telephone Administration Guide for Voicemail features

• Call Center Telephone Administration Guide for Call Center features

• BCM50 System-wide Call Appearance (SWCA) Feature Card for SWCA features

• BCM50 Hospitality Feature Card for Hospitality features

Your system administrator can inform you if any of these features are not available on your

telephone.

The digital phone’s Feature button is the Services key or a small globe icon. Other

telephones have different icons, or they display Feature above a display key, when feature

selection is available.

This book uses FEATURE to indicate pressing the Feature key is required before entering

a feature code. The table below shows which buttons to use on the different types of Nortel

telephones. Refer to each user card for specific details about each type of telephone.

Button Function Legacy telephones IP telephones

Feature , Display key

Hold , ,

Release

On- or Off-hook ,

Answer call

Telephones with line buttons:

Press the active line button or Intercom key, and lift handset.

Telephones with no buttons: Lift handset.

Soft Keys

Telephones with displays have softkeys located directly under the display.

The softkey labels are be shown in the telephone display. The Softkey

labels and functions change depending on the telephone model and, the

operation being performed.

Page 3

Note: If your telephone does not have access to all the features listed in this guide, then either

your telephone does not support the feature, or the feature has not been enabled on your

telephone. Your system administrator can provide details.

Symbols used in this guide:

This guide uses the following labels to indicate each type of configuration button:

•FEATURE indicates pressing the Feature key

•HOLD indicates pressing the Hold key (or equivalent)

•RLS indicates pressing the Release key (or equivalent)

The following symbols are used to indicate different types of phones. Within the text, the

symbols indicate features that are not supported, or that require different actions than the

standard digital phones:

* indicates 7000 and 7100 Digital phones and the IP Phone 2001

Page 4

Telephone features

Background

Music

FEATURE 86 Cancel: FEATURE #86

Listen to music (provided by an external source or an IP source connected

to the system) through your telephone speaker when you are not on a call.

Button Inquiry FEATURE *0

Check what feature is programmed on any button. Use when labeling

buttons.

Variances

* (shows DN)

Call Duration

Timer

FEATURE 77

Briefly display the approximate length of your current or most recent call.

Call Forward FEATURE 4 Cancel: FEATURE #4

Send your calls to another telephone in your system.

Call park FEATURE 74

Put a call on hold to enable you to answer the call from any telephone in

your system. The display shows a three-digit retrieval code.

To retrieve a parked call: press an intercom button and dial the retrieval

code.

Variances

* (Lift the handset or go on- or off-hook, and dial the retrieval code.)

Call Pickup,

directed

FEATURE 76 and the telephone number

Answer any ringing telephone.

Call Pickup,

group

FEATURE 75

Answer a call ringing at another telephone in your pickup group. The

external call ringing longest is answered first.

Call Queuing FEATURE 801

Answer the next call. If more than one call is waiting, priority is given to

incoming external calls over callback, camped, or transferred calls.

Camp-on FEATURE 82 and the extension number of the receiving telephone

Re-route a call to another telephone even if all the telephones lines are

busy.

Page 5

Class of Service

password

FEATURE 68 plus COS password

Change the dialing filters on a line or telephone, or gain external access to

your system. Dialing filters determine which numbers you can dial.

The COS password is provided by your System Administrator to change

your Class of Service.

Conference FEATURE 3

Establish a conference call between yourself and two other parties.

1. Make or answer the first call.

2. Put the first call on hold.

3. Make or answer the second call.

4. After the second call is connected, press FEATURE 3.

5. Press the line or intercom button of the first held call.

6. Press RLS to end the conference call.

Variances

*(Step 5 not required)

To remove yourself from a conference permanently (unsupervised

conference):

Press FEATURE 70.

The other two callers remain connected. (Some external lines may not

support this feature.)

To put a conference on hold:

Press HOLD. The other two callers can still talk to each other.

To split a conference:

Press the line or intercom button of one caller to consult privately while the

other caller is on hold.

To re-establish the conference: Press FEATURE 3.

To disconnect one party:

1. Press the line or intercom button for the caller you want to disconnect.

2. Press RLS.

3. Press the line or intercom button to resume your conversation with the

other caller.

Telephone features

Page 6

To independently hold two calls:

1. Press the line or intercom button of the first caller.

2. Press HOLD. The second caller is automatically put on hold.

To re-establish the conference:

1. Retrieve one call from hold.

2. Press FEATURE 3.

3. Retrieve the second call from hold.

To send Hookswitch or DTMF during a conference call:

Either system telephone engaged in a three-way conference call over a

Network CLID or DS trunk can issue a hookswitch or DTMF dialing request

without leaving the conference, if the feature is enabled.

Note: This feature is not available for IP Phones 20xx.

– To hear DTMF tones on these telephones during dial, activate Long

Tones (FEATURE 808).

– To conference in another party through the trunk, use Link (FEATURE

71)

Contrast

adjustment

FEATURE *7 plus a number from 1 to 9 to adjust the display contrast.

Press HOLD to set your choice.

Dialing modes FEATURE *82

Use the following steps to choose one of three modes of dialing listed:

1. Press FEATURE *82.

2. Press # to select the mode.

3. Press HOLD to store the mode.

Standard Dial: Select a line, then dial the number. (Standard Dial is

always available, even when another dialing mode is selected.)

Automatic Dial: Dial the number without choosing a line button first. Your

prime line is selected automatically for the call.

Pre-Dial: Dial the number, then press a line button to place the call. Edit

the number by pressing the volume bar before placing the call.

Do Not Disturb FEATURE 85 Cancel: FEATURE #85

When you are not on a call, prevent all incoming calls, except priority calls,

from ringing at your telephone. When you are on a call, block an incoming

priority call.

Telephone features

Page 7

Group

Listening

FEATURE 802 Cancel: FEATURE #802

Use both the handset and speaker while you are on a call. To avoid elec-

tronic feedback, keep the handset away from the speaker during the call,

and press RLS to hang up.

Variances

* (not available)

Handsfree Handsfree/mute or Handsfree button

Press the key to transfer a call from the handset/headset to the telephone

speaker. If you lifted the handset, return it to the cradle.

Note: Handsfree speaker volume returns to the default volume set at the

telephone at the end of each call.

Variances

* (not available)

Hold Press HOLD

Temporarily suspend a call.

To retrieve a held call, press the line button for the held call.

Variances

* (Press HOLD to toggle between two calls.)

Hold -

Exclusive

FEATURE 79 or FEATURE/HOLD

Temporarily suspend a call and prevent other telephones from picking it

up.

Hold - Auto FEATURE 73 Cancel: FEATURE #73

Set your telephone to automatically put a call on Hold when you pick up a

second call, or prevent your telephone from doing so. Default is Yes

(feature is on).

Note: Telephones that have SWCA buttons must have this feature active

(set to Yes).

Language

choice

FEATURE *501: Select Primary Language for the telephone display.

FEATURE *502: Select Alternate Language for the telephone display.

FEATURE *503: Select Alternate Language 2 for the telephone display.

FEATURE *504: Select Alternate Language 3 for the telephone display.

Last Number

Redial

FEATURE 5

Automatically redial the last external telephone number that you dialed.

Telephone features

Page 8

Line pools FEATURE 64

With a line pool, telephones can share several lines for making calls.

1. Press FEATURE 64 or an intercom button.

2. Enter a line pool access code. (See your System Administrator for a list.)

Variances

* (no intercom buttons)

Line

redirection

FEATURE 84 Cancel: FEATURE #84

Send calls arriving on an external line to another telephone outside your

system. (Some external lines do not support this feature. See your System

Administrator.)

Variances

* (not available)

Link FEATURE 71

Generate a Link signal to access a PBX or other host exchange.

Long Tones FEATURE 808

Generate a tone for as long as you hold down a button. This is used to

communicate with devices such as fax or answering machines. Long tones

are only in effect for your current call.

Messages FEATURE 1 Cancel: FEATURE #1

Send a message to another telephone within your system.

To view and reply to your messages:

1. Press FEATURE 65.

2. Press * and # to view your message list.

3. Press 0 to call the person who left you the message.

To erase a message:

Press HOLD while viewing a message.

Telephone features

Page 9

Moving line

buttons

FEATURE *81

Change the position of your line or hunt group buttons.

1. Press FEATURE *81.

2. Press the line button that you want to move.

3. Press the button to which you want to move the line.

4. Press RLS. The two buttons are exchanged.

5. Update the button label strip on your telephone.

Line buttons cannot be exchanged with intercom, answer DN, or handsfree

buttons.

Variances

* (not available)

Mute Handsfree/mute or Mute button

Press this button when you do not want the caller to hear anything from

your side of a handsfree call. The display light beside the button blinks

when the call is muted. The mute button on the T-series and i-series

telephones mutes all types of calls.

Page announcement note: A call retrieved from hold after a page

announcement does not necessarily remain muted.

Variances

* (not available or set-based)

Name and

number block

FEATURE 819 Cancel: FEATURE #819

Block either outgoing name or number, or both, for a specific call.

Page FEATURE 60 and code (1 to 3) and zone (0 to 6)

Make a page announcement through either the internal (code 1) or

external (code 2) speakers, or both (code 3). Zone 0 pages all zones.

Page announcements are programmed to timeout after a pre-selected

amount of time, which is set by your System Administrator.

Variances

* (cannot receive pages)

Internal page

FEATURE 61 and zone (0 to 6)

Make a page announcement to all, or to a specific group of telephones,

through the telephone speakers. Zone 0 pages all zones.

Telephone features

Page 10

External page

FEATURE 62

Make a page announcement through an external loudspeaker system.

Internal and external page

FEATURE 63 and zone (0 to 6)

Make a page announcement through both your telephone speakers and an

external loudspeaker system. Zone 0 pages all zones.

Incoming page during active call:

The system can be set to either:

• Put an active call on hold, and broadcast the incoming page.

• Broadcast of an incoming page is muted for the duration of an active

call; broadcasting any remaining portion of the page after the call is

terminated.

This feature is set by your system administrator.

Note: Business Series Terminals: a call on mute when a page is

broadcast does not remain muted when it is released from hold after the

page.

Pause FEATURE 78

Program in an external autodial sequence to insert a 1.5-second delay.

For pulse dialing: * also inserts a 1.5-second delay.

Priority call FEATURE 69

Interrupt a person on a call.

A person on another call can press FEATURE 85 (Do Not Disturb) to block

priority calls.

Variances

*(ringing call)

Privacy FEATURE 83

Change the privacy setting for an external line. If a line normally has

privacy, this enables another telephone that shares the line to join your call

by selecting the line in use. If a line normally has privacy disabled, this

prevents another telephone that shares the line from joining your call by

selecting the line in use. The privacy setting is re-established once you end

your call, or when you enter the Privacy feature code again.

Telephone features

Other manuals for BCM50

Table of contents

Other Nortel Telephone System manuals

Nortel

Nortel Norstar Modular ICS Parts list manual

Nortel

Nortel BCM50 Operator's manual

Nortel

Nortel Business Communications Manager 2.5 Operating instructions

Nortel

Nortel Meridian 1 Option 11C User manual

Nortel

Nortel Meridian 1 Option 11C User manual

Nortel

Nortel BCM50 Operator's manual

Nortel

Nortel Norstar SMDR6 User manual

Nortel

Nortel P0857846 User guide

Nortel

Nortel Norstar Modular ICS Parts list manual

Nortel

Nortel BCM50 Product manual

Nortel

Nortel DMS-100 Series User manual

Nortel

Nortel Meridian Meridian 1 Parts list manual

Nortel

Nortel FastRad User manual

Nortel

Nortel DMS-10 User manual

Nortel

Nortel BCM50 2.0 Installation guide

Nortel

Nortel BCM1000 Product manual

Nortel

Nortel BCM50 User manual

Nortel

Nortel ICS 7.1 User manual

Nortel

Nortel BCM200 User manual

Nortel

Nortel DCT1900 User manual

Nortel

Nortel Meridian Meridian 1 Operating and installation instructions

Nortel

Nortel BCM50 Product manual

Nortel

Nortel Meridian Meridian 1 User manual

Nortel

Nortel BCM50 User manual

Popular Telephone System manuals by other brands

Teleco

Teleco Perfect Voice Tis 16 installation manual

AT&T

AT&T Network Adapter 25 user guide

AVE

AVE AF902R-CE manual

Tynetec

Tynetec Advent xt user guide

Ericsson

Ericsson DCT1800-S user guide

NEC

NEC Electra Elite 192 Hardware manual

Alcatel

Alcatel EASY REFLEXES 4200 Admin & user guide

Panasonic

Panasonic KX-TDA50 operating manual

Bticino

Bticino PABX 28D User instructions

NEC

NEC SL 2100 user guide

Sonifex

Sonifex Phone In 6 User handbook

TransTel Communications

TransTel Communications TD-824i Installation and programming manual

Panasonic

Panasonic KX-TS25B user guide

ASCOM

ASCOM TD 92375GB Information

Karel

Karel MS26S Easy to use owner's guide

EnGenius

EnGenius DuraFon PRO user manual

Teledat

Teledat X130 DSL Quick reference guide

SpectraLink

SpectraLink MOG400 install guide
