Norco BPC-7934 User manual
BPC-7934
Mini-ITX Motherboard
User's Manual V1.2
Disclaimer
With the exception of showing the accessories of product configuration,
this manual does not create any commitment of our company. We retained
the rights to change it without prior notice and will not be responsible for any
direct, indirect, intentional or unintentional damage or hidden dangers
caused by any improper installation or use.
Before buying products, please learn about the product performance
from the distributors to see if it is in line with your needs. NORCO is a
registered trademark of Shenzhen NORCO Intelligent Technology CO., LTD.
The ownership of other trademarks involved in this manual is owned by its
respective owners.
The contents of this manual are protected by copyright law. All rights
are strictly reserved. Any form of unauthorized reproduction is prohibited,
including but not limited to carbon copy, facsimile transmission and
electronic copy or email, etc.
Safety Instructions
1. Before using this product, please read this user’s manual carefully;
2. Any plate cards not ready to be installed shall be kept in the anti-static protective bags; 3.
Before taking out the plate cards from the anti-static protective bags, first place hands on the
grounding metal object for a while so as to release the static electricity from your body and
hands;
4. While fetching the plate cards, please wear static protective gloves and have the habit of
holding the cards by edge;
5. Before connecting the motherboard to the power supply, please check the power voltage
6. In order to prevent bodily electric shock or damage to products, first turn off the AC power or
unplug the power cord out of power sockets while inserting main boards or plate cards or do
reconfiguration;
7. Before moving the plate cards or the unit, please make sure to unplug the AC power cords
out of the sockets;
8. Before you connect or unplug any equipment, please make sure that all power cords are
unplugged in advance;
9. To prevent any unnecessary damage to the products due to frequent power on/off. Please
wait at least 30 seconds before you restart up the unit after the unit is shut down;
10. If anything unexpected happened during the operating, please seek help from professionals;
11.This is a Class A product, in a domestic environment, this product may cause radio
interference. In this case, the user may be required to take adequate measures.
Content
Chapter 1 Product Introduction..............................................................................................................1
1.1 Introduction.................................................................................................................................1
1.2 Product Specification................................................................................................................ 1
Chapter 2 Installation Specification.......................................................................................................4
2.1 Interface Location and Dimension Diagram..........................................................................4
2.2 Installation Steps....................................................................................................................... 5
2.3 Memory Installation...................................................................................................................5
2.4 Jumper Setting...........................................................................................................................5
2.4.1 CMOS Content Clearance /Keep Settings（JCC）................................................ 5
2.4.2 Hardware Switch for System Auto Boot upon Power On（JAT）..........................7
2.4.3 COM2 Jumper Setting（J5，J6，J8）..................................................................... 7
2.4.4 LCD Rated Voltage Selection Jumper（JP1，JP2）............................................. 8
2.5 Interface Specification.............................................................................................................. 9
2.5.1 SATA Port..................................................................................................................... 10
2.5.2 Serial Port（COM1-COM6）.....................................................................................10
2.5.3 Display Port（VGA，JVGA，LVDS，HDMI）....................................................... 12
2.5.4 USB Port（USB_LAN1，USB_LAN2，USB12）.................................................14
2.5.5 Ethernet Interface（LAN1，LAN2）........................................................................ 15
2.5.6 JGPIOKBMS Expansion Port.................................................................................... 16
2.5.7 Power Interface（PWR1）........................................................................................ 18
2.5.8 SATA Power Supply Voltage（JSATAPWR）......................................................... 19
2.5.9 Fan Interface（CPU_FAN）...................................................................................... 19
2.5.10 Audio Port（Audio、LINE_in）...............................................................................20
2.5.11 LVDS Power Supply Voltage（JLVDS PWR）.................................................... 22
2.5.12 Front Panel Interface（JFP）................................................................................. 23
2.5.13 MINI PCIe Interface（MINI_ PCIE1，MINI_ PCIE2，J3，J4）.......................24
2.6 ACP-315 Interface Specification...........................................................................................25
2.5.1 Mouse & Keyboard Interface（KBMS)....................................................................25
2.5.2 Power Interface（PWRBT、RSTBT、SWBT）.....................................................26
Chapter 3 BIOS Set up......................................................................................................................... 27
AMI BIOS Refresh......................................................................................................................... 27
AMI BIOS Description................................................................................................................... 27
BIOS Parameter Setting：........................................................................................................... 27
3.1 Main Menu...............................................................................................................................28
3.2 Advanced Menu......................................................................................................................28
3.2.1 ACPI Settings............................................................................................................... 29
3.2.2 APM Configuration......................................................................................................30
3.2.3 CPU Configuration......................................................................................................31
3.2.4 SATA Configuration.....................................................................................................32
3.2.5 USB Configuration...................................................................................................... 34
3.2.6 Supper IO Configuration............................................................................................ 35
3.2.7 H/W Monitor.................................................................................................................36
3.3 Chipset Menu..........................................................................................................................38
3.3.1 North Bridge.................................................................................................................40
3.3.2 South Bridge................................................................................................................ 41
3.4 Boot Menu............................................................................................................................... 43
3.5 Security Menu.........................................................................................................................43
3.6 Save & Exit Menu...................................................................................................................45
Appendix................................................................................................................................................. 46
Appendix 1：Watchdog Programming Guide........................................................................... 46
Appendix 2：Glossary.................................................................................................................. 47
Chapter
One
Product
Introdu
ction
BPC-7934 Mini-ITX Motherboard Based on Intel Cedar Trail Platform
1
Chapter One Product Introduction
1.1 Introduction
BPC-7934 is Mini-ITX motherboard，with Intel®NM10 chipset，Intel Cedarview CPU D2550
1.86GHz processor. 1x standard 7Pin SATA port，2x Gigabit Ethernet interface，provide VGA，
LVDS，HDMI display port，and 6 x standard DB9 serial port，6xUSB 2.0 ports，can be used for
data communication. Support Line-in audio function，provide 1x 2X10 2.54mm dual row pin
header expansion GPIO、mouse, keyboard, power key, reset key and restore key. Provide 2x
MINI PCIe slot and on board SIM card slot.
1.2 Product Specification
Structural Standard
●Standard Mini-ITX specification motherboard
Size
●170*145 mm
Processor
●Intel Cedarview CPU D2550 1.86GHz
Chipset
●Intel®NM10
Display
●Display chip：CPU integrated
●VGA：1x VGA port，support resolution: 1920x1200@60Hz；Standard DB15 port
●LVDS：1x LVDS port，single channel 24bit，maximum resolution: 1440x900@60Hz，default
resolution: 800X600@60Hz; DB44 port
●HDMI：1x HDMI port，support resolution:1920x1200 @ 60Hz；Standard HDMI port；Support
independent dual display
BPC-7934 Mini-ITX Motherboard Based on Intel Cedar Trail Platform
2
System Memory
●On board memory，support DDR3-800/1066 up to 2G Bytes
Storage
●1x standard 7 Pin SATA port
LAN Function
●Network controller：With RTL8111F-CGL network chip
●2 x standard RJ45 port
●Support Wake On LAN（WOL）
●Rate：10/100/1000Mbps
Audio Port
●With ALC662-VD0 audio control chip
●Audio port，Green for Line-out
●Built in audio expansion pin，1x 2×5Pin pin，provide 1x Line-in，1x Line-out，1x Mic-in
USB Port
●6x USB2.0 port；Provide ESD protection
FAN Interface
1x 4PIN Smart FAN
Key GPIOKBMS Expansion Port
Provide 1x 2X10 2.54mm dual row pin header expansion GPIO、mouse, keyboard, power key,
reset key and restore key
I/0 Functions
●With ITE 8783F I/O chip
●Provide 6 x standard DB9 port，COM1/3/4/5/6->RS232；COM2-> RS 232/RS 422/RS 485，
provide ESD protection
BPC-7934 Mini-ITX Motherboard Based on Intel Cedar Trail Platform
3
Expansion Port
●2x MINI PCIe slot, in which 1x MINIPCIE slot support Mini-PCIE WLAN /MSATA optional
●1x SIM card slot；Support 3G module
●1x LPC bus expansion interface (optional)
●1x front panel interface
Power Supply
●DC +12V single power supply
Watchdog
●Support hardware reset
BIOS
●1MB SPI BIOS
Operating Environment
●Operating Temperature：0~+60℃
●Storage Temperature：-40~+85℃
●Operating Humidity：5%~95%，non-condensing
●Storage Humidity：5%~95%，non-condensing
Chapter
Two
Install
ation
Specifi
cation
