NetComm AM5066 User manual

Rave III USB Modem

AM5066 – V.92 Data/Fax Modem

Now with V.92 and auto fallback for full compatibility

Bus Powered – no external power supply needed

USB hot swappable Plug & Play for easy installation

Automatic detection between data and fax calls

Auto Dial and Auto Answer

Auto Speed/Mode Selection

USBPlug & PlayV.92

NetComm’s Rave III USB Modem lets you jump online at full speed.

And because it’s USB, just Plug & Play and you’re away. The Rave III delivers full V.92* 56K speed which gives you up

to a blistering 230,000 bps throughput.

NetComm’s Rave III Modem lets you whizz through your downloads so you can hear those MP3s sooner, play games

and enjoy shopping, banking or just surﬁng the Net. The Rave III is also equipped with TAM (Telephone Answering

Machine) support.

To complete your small business ofﬁce, the Rave III can send and receive faxes directly from your PC with the

minimum of fuss.

* Your Internet Service Provider must support the V.92 standard. If a V.92 connection is not available, this modem automatically reverts to the 56K V.90 mode.

NETCOMM LIMITED ABN 85 002 490 486 PO Box 1200, Lane Cove NSW 2066 Australia

P: 02 9424 2070 F: 02 9424 2010 E: [email protected] W: www.netcomm.com.au

Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Speciﬁcations are

subject to change without notice. Images shown may vary slightly from the actual product.

Your NetComm dealer:

Rave III USB Modem

AM5066 – V.92 Data/Fax Modem

Now with V.92 and auto fallback

for full compatibility

Bus Powered – no external power

supply needed

USB hot swappable Plug & Play for

easy installation

Automatic detection between data

and fax calls

Auto Dial and Auto Answer

Auto Speed/Mode Selection

KEY FEATURES

TECHNICAL SPECIFICATIONS

USB INTERFACE

•Complies with USB 1.1 speciﬁcation at 12Mbs full speed

•Hot Plug & Play support for easy installation

DATA MODE

•Data Mode: data throughput up to 230Kbps

•V.92, V.90, V.34, V.32bis, V.32, V.22bis, V.22, V.23, V.21,

Bell 212A and 103.

•Error correction: MNP 2-4 and V.42, LPAM

•Data compression: MNP 5 and V.42bis

FAX MODE

•ITU-T V.17, V29, V.27ter and V.21 channel 2

•TIA/EIA 578 Class 1 fax send and receive speeds 14,400,

12,000, 9600, 7200, 4800 and 2400 bps

SYSTEM REQUIREMENTS

• PC with 1GHz Processor with 256Mbytes system

memory or better.

•USB port

•Windows 98se, ME, 2000 or XP

•50Mbytes of free disk space for driver installation

•CD-ROM Drive

PACKAGE CONTENTS

• NetComm Rave III USB V.92 modem

•Telephone cable

•USB cable

•Installation documentation

•NetComm CD-Rom

THREE YEAR WARRANTY*

One year warranty out of the box. Extra two years free

with online registration at www.netcomm.com.au

*Conditional upon online registration

Line Port

USB Port

Internet

Telephone

Wall Socket

Computer with

USB Port

AM5066 Rave III USB Modem

RJ-11 Cable USB Cable
