Lorex DMC2161 User manual

DMC2161 Components

Getting Started: The DMC2161 Cameras come with the following components. The

components marked with a red slash are not needed for your connection to the DVR:

1 x Camera (with 6-PIN DIN Connection) 1 x Long DIN to RCA Cable

1 x Short DIN to RCA Cable

(optional)

1 x Camera Power Adaptor

1 x RCA to USB Adaptor Box Cable 1 x USB Adaptor Box & USB Cable

1. Connect the DIN end of the camera to the DIN end of the RCA-to-DIN Cable – you can choose to use

either the Long or Short RCA-to-DIN cable for this depending on the distance the camera will be from

your DVR.

2. Connect the AC Power Adaptor to the Power Port on the RCA-to-DIN Cable.

DMC2161 Components

Camera Connections:

Connecting the Camera to the DVR:

1. Connect a BNC-to-RCA Adaptor to CH1 on the back of the DVR.

2. Connect the RCA-to-DIN Cable into the BNC Adaptor (use the YELLOW VIDEO end of the cable.

NOTE: You do not need to connect the WHITE AUDIO cable to the DVR.

Repeat this process for the other cameras – connect cameras to Channels 1~4 (CH1~4) on the DVR.
