Linksys WGA11B Operation manual

Model No.

WET54G

Product Data

Model No. WGA11B

Lag-free head-to-head or Inter-

net gaming, without stringing

Lag-free head-to-

head or Internet

gaming at up to

11Mbps, without

stringing wires

Wireless

Exclusive Channel

Selector Button

makes network setup

a snap

Converts wired-Ether-

net-ready game

consoles to Wireless-

B network connectiv-

ity

Works without drivers

on PlayStation®2,

Xbox™, and

GameCube™

The Wireless-B Game Adapter gives any wired-Ethernet-equipped

game console wireless connection capabilities. The Game Adapter

can be used in two different ways. If you have an existing home

wireless network with a cable or DSL Internet connection, the Game

Adapter lets your PlayStation®2, Xbox™ or GameCube™ attach to

the network so you can get into online games without running wires

to the game room. Or, use a pair of Game Adapters to form a

"cable-less cable" between two game consoles for head-to-head

gaming -- in the same room, or all the way across the house.

It's completely driver-free, so there's no software-installation hassle,

and it works on any platform. And the innovative Channel Selector

Button with LED display makes wireless network configuration into

child's play. If you're using two Game Adapters, just press their Chan-

nel Selector Buttons until the channel numbers match, and you're

connected. To connect to an existing wireless network, press the But-

ton to select Infrastructure mode. If your setup's a little different,

there's an easy-to-use PC-based Setup Wizard to guide you through.

Then just plug the Adapter into your game box, and go.

The Wireless-B Gaming Adapter provides lag-free gaming with com-

munication speeds up to 11Mbps. So spend your time gaming, not

stringing wires, with the Linksys Wireless-B Gaming Adapter.

Game Adapter

Wireless-B

Model Number

Product Data

Model No.

Features

• Easy-to-use Channel Selector

button for instant wireless con-

figuration

•Compatible with popular

802.11b devices for high-

speed wireless gaming

•Compact size allows easy

placement and maximum

portability

•Compatible with most network-

ready game consoles

•One Year Limited Warranty

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at www.linksys.com.

WET54G

Package Contents

• Wireless-B Game Adapter

•Setup Wizard CD-ROM with User Guide

•Power Supply

•One Pair of Adapter Stands

•Network Cable

•Quick Installation

•Registration Card

Game Adapter

Wireless-B

Minimum Requirements

• Network-ready Game Console

• PC with CD-ROM (For Advanced

Setup Only)

• Wireless Access Point

-or-

• Additional Wireless-B Game Adapter

• Internet access required for online

gaming

Specifications

Model Number WGA11B

Standards 802.11b

Ports Power, Ethernet

Buttons Channel Selector, Reset

Cabling Type Cat 5 UTP

LEDs LAN, Wireless, Wireless Channel

Transmit Power 15 dBM

Security Features WEP

WEP key bits 64-bit, 128-bit

Environmental

Dimensions 2.86" x 5.31" x 1.10" L x W x H

(72 mm x 135 mm x 28 mm)

Unit Weight 4.2 oz. (0.12 kg)

Power 5V, 1.0A

Certifications FCC

Operating Temp. 32ºF to 140F (0ºC to 40ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)

Operating Humidity 10% to 85% Non-Condensing

Storage Humidity 5% to 90% Non-Condensing

Specifications are subject to change without notice. Linksys and Instant Wireless are registered trademarks of Cisco Systems, Inc. Other brands and product names are trademarks or registered trade-

WGA11B-DS-306202NC-KL
