Lenovo Q100 User manual

Version 1.0 2009.8

User Guide

Lenovo

IdeaCentre Q100/Q110 Series

31039395

31039395_Q100_UG_FM_EN_V1.0.indd1 1 2009.8.3 2:26:38 PM

Important Safety Information

Before using this manual, it is important that you read and understand all of

the related safety information for this product. Refer to the Safety and Warranty

Guide you received with this product for the latest safety information. Reading

and understanding this safety information reduces the risk of personal injury and

damage to your product.

Danger: Beware of extremely hazardous or lethal situations.

Attention: Beware of possible damage to programs, devices, or data.

Note: Pay attention to this important information.

31039395_Q100&Q110_UG_EN_V1.0.in1 1 2009.8.6 8:51:28 PM

31039395_Q100&Q110_UG_EN_V1.0.in2 2 2009.8.6 8:51:28 PM

Contents

Important Safety Information

Chapter 1 Using the Computer Hardware.............................. 1

1.1 Front view................................................................................2

1.2 Rear view.................................................................................2

1.3 Computer mount instruction ....................................................3

1.4 Setting the display resolution ...................................................5

1.5 Connecting your computer .....................................................6

Chapter 2 Recovery Wizard ................................................... 11

Chapter 3 Using the Computer Software ............................. 17

3.1 CyberLink PowerDVD ............................................................19

3.2 Trend Micro Internet Security .................................................19

Chapter 4 System Maintenance and Recovery.................... 21

4.1 Restoring the system.............................................................22

4.2 Backup status and conﬁguration ...........................................22

4.3 Cleaning up the disk ..............................................................22

4.4 Checking for and correcting disk errors .................................23

4.5 Defragmenting the disk(s) ......................................................23

4.6 Performing daily maintenance tasks.......................................23

Chapter 5 Troubleshooting and Conﬁrming Setup.............. 25

5.1 Troubleshooting display problems..........................................26

5.2 Troubleshooting audio problems............................................27

5.3 Troubleshooting software problems .......................................28

5.4 Troubleshooting problems with Hard Disks ............................28

5.5 Special considerations for troubleshooting Windows .............29

31039395_Q100&Q110_UG_EN_V1.0.in1 1 2009.8.6 8:51:28 PM

31039395_Q100&Q110_UG_EN_V1.0.in2 2 2009.8.6 8:51:28 PM

Chapter

This chapter contains the following

topics:

ÿComputer hardware introduction

ÿInformation on computer connections

Note: The descriptions in this chapter may

vary from your computer setup, depending

on computer models and conﬁgurations.

User Guide 1

Using the Computer Hardware

31039395_Q100&Q110_UG_EN_V1.0.in1 1 2009.8.6 8:51:30 PM

2User Guide

1.1 Front view

Attention: Ensure that none of the air vents on the computer are blocked.

Blocked air vents can lead to overheating problems.

Power button and power indicator Microphone socket

USB2.0 ports (2) Base stand screw

Headphone socket

1.2 Rear view

31039395_Q100&Q110_UG_EN_V1.0.in2 2 2009.8.6 8:51:31 PM

User Guide

VGA port or HDMI port Power socket

USB2.0 ports (2) Audio line-out port

Ethernet port

1.3 Computer mount instruction

The computer chassis can be placed in a vertical position.

Installing the base stand

1. Attach the base stand to the unit.

2. Tighten the screw with your ﬁngers.

Note: Make sure to install the base stand before placing the chassis in a

vertical position.

31039395_Q100&Q110_UG_EN_V1.0.in3 3 2009.8.6 8:51:32 PM

4User Guide

The computer chassis also can be mounted behind your TV or

monitor.

1. First, screw the metal bracket to the rear of TV or monitor.

2. Slide the computer into this metal bracket and screw the computer ﬁrmly to the

Bracket.

31039395_Q100&Q110_UG_EN_V1.0.in4 4 2009.8.6 8:51:34 PM

User Guide

1.4 Setting the display resolution

1. When you connect the computer to your TV or monitor, adjust the display

resolution to the optimum setting according to the instructions in your TV or

monitor’s user manual or after consulting with the supplier.

2. Adjusting the OS desktop size (when the OS desktop size is larger than the

screen boundary):

• IdeaCentre Q110: After conﬁguring the display resolution of your TV or

monitor, right-click the desktop anywhere except over an icon, then select

NVIDIA control panel.

• IdeaCentre Q100: Adjust the display resolution on the TV to ﬁt the screen.

• IdeaCentre Q100 is not recommended to connect a TV as a display device.

Note: Use the Apply button to set the new resolution of your TV or monitor.

If your TV or monitor does not support this new resolution, system will

restore to the original resolution within 20 seconds.

Important:

IdeaCentre Q110:

• Set the refresh rate of your TV or monitor to less than 60 Hz to avoid damage to

your TV or monitor.

• If no image is displayed on the TV or monitor after setting a new refresh rate,

turn off your TV or monitor and wait for a moment before restarting.

• When connecting to a TV, please select the TV’s appropriate input channel.

IdeaCentre Q100:

• Lenovo recommends connecting the Q100 to a monitor using the VGA video

connector.

• It is possible to connect the Q100 to a TV using the VGA video connector, but

Lenovo is unable to guarantee that this will work effectively. After the Q100 is

connected and is operating normally, if a blank screen or no image is displayed

on the TV, this may be a problem with the TV settings. Please consult with your

TV supplier.

31039395_Q100&Q110_UG_EN_V1.0.in5 5 2009.8.6 8:51:34 PM
