Lenovo IdeaCentre B325 Guide User manual
Version 3.0
Machine type: 10069/7760
10074/3076
2011.06
Lenovo
IdeaCentre B3 Series
User Guide
31500119
Important Safety Information
Before using this manual, it is important that you read and understand all of the
related safety information for this product. Refer to the Safety and Warranty Guide
that you received with this product for the latest safety information. Reading and
understanding this safety information reduces the risk of personal injury or damage
to your product.
Danger: Be aware of extremely hazardous or lethal situations.
Attention: Be aware of possible damage to programs, devices, or data.
Note: Pay attention to this important information.
© Copyright Lenovo 2011.
1
Contents
Contents
Important Safety Information
Chapter 1 Using the Computer Hardware.............................. 1
1.1 Front view................................................................................2
1.2 Left and right view of the computer .........................................3
1.3 Rear view of the computer.......................................................4
1.4 Computer stand ......................................................................5
1.5 Connecting your computer ......................................................7
1.6 Important information about using the computer ...................10
1.7 Wired keyboard (Selected models only)................................11
1.8 Wireless keyboard and mouse (Selected models only) .........12
Chapter 2 Touch screen user instruction ............................. 17
2.1 Touch Screen Calibration.......................................................18
2.2 User Gesture Instructions for the Touch screen......................19
2.3 Attentions when using the Touch Screen ...............................27
Chapter 3 Using the Rescue System .................................... 29
3.1 OneKey Recovery..................................................................30
3.2 Driver and Application Installation ..........................................30
3.3 System Setup........................................................................31
3.4 System Backup .....................................................................32
3.5 System Recovery ..................................................................32
3.6 Create Recovery Disc ............................................................32
Chapter 4 Using the Computer Software ............................. 33
4.1 Lenovo Dynamic Brightness system ......................................34
4.2 Lenovo Eye Distance System ................................................35
2Contents
Chapter 5 Troubleshooting and Confirming Setup.............. 37
5.1 Troubleshooting Display Problems .........................................38
5.2 Troubleshooting Audio Problems ...........................................39
5.3 Troubleshooting Software Problems.......................................39
5.4 Troubleshooting Problems with Optical Drives and
Hard Disks.............................................................................40
5.5 Special considerations for troubleshooting Windows .............41
5.6 Performing Daily Maintenance Tasks......................................42
5.7 Wireless Keyboard and Mouse Connection Instructions and
Troubleshooting.....................................................................43
5.8 Troubleshooting wireless mouse and keyboard issues ...........45
1
2
3
4
5
Chapter
This chapter contains the following
topics:
ØComputer hardware introduction
ØInformation on computer connections
Note: The descriptions in this chapter might
vary from your computer, depending on
computer models and configurations.
User Guide 1
Using the Computer Hardware
2User Guide
1.1 Front view
Built-in microphone
Camera
TV indicator
Hard Disk Drive Indicator
Bluetooth status indicator
WIFI status indicator
Menu button
Direction button
Direction button
LCD On/Off
Power button
3
User Guide
1.2 Left and right view of the computer
Attention: Be sure not to block any air vents on the computer. Blocked
air vents may cause thermal problems.
Optical drive
TV buttons (Selected models only)
Refer to Quick Reference for detail instruction of Onekey TV buttons
Card reader
USB port
Headphone port
Microphone port
USB port
4User Guide
1.3 Rear view of the computer
Ethernet port
TV tuner port (Selected models only)
USB ports (5)
Bluetooth reset button (Only functional on models equipped with a Bluetooth
module)
AV-IN ports (Selected models only)
PS/2 keyboard port
Power connector
5
User Guide
1.4 Computer stand
Use the stand to position the display to your preference. It can be rotated between
15º and 40º from the vertical.
The stand provides stability to the computer; it is not a removable part.
Attention:
1. The computer stand must remain installed at all times to ensure
maximum system stability.
2. Make sure the angle of the computer is at least 15 degrees from the
vertical; otherwise the computer will be unstable and could fall over.
