Lenovo 3000 C200 User manual

Version 1.0

Machine type: 10040

2010.03

Lenovo

C2 Series

User Guide

31041970

Important Safety Information

Before using this manual, it is important that you read and understand all of the

related safety information for this product. Refer to the Safety and Warranty Guide

that you received with this product for the latest safety information. Reading and

understanding this safety information reduces the risk of personal injury or damage

to your product.

Danger: Be aware of extremely hazardous or lethal situations.

Attention: Be aware of possible damage to programs, devices, or data.

Note: Pay attention to this important information.

Contents

Important Safety Information

Chapter 1 Using the Computer Hardware.............................. 1

1.1 Front view of the computer......................................................2

1.2 Left and right view of the computer .........................................2

1.3 Rear view of the computer.......................................................3

1.4 Computer stand .....................................................................4

1.5 Connecting your computer ......................................................5

1.6 Important information about using the computer .....................9

1.7 Keyboard and Mouse (wired) .................................................10

Chapter 2 Using the Rescue System .................................... 11

2.1 Installing Drivers and Software Shipped with Your Computer .12

2.2 OneKey Recovery..................................................................13

2.3 File Management ...................................................................14

2.4 OneKey Antivirus ...................................................................16

Chapter 3 Using the Computer Software ............................. 19

3.1 Power2Go — Burning Discs .................................................20

3.2 WinDVD.................................................................................21

3.3 McAfee Security Center.........................................................22

Chapter 4 System Maintenance and Recovery.................... 23

4.1 Restoring the System ............................................................24

4.2 Backup status and conﬁguration ...........................................24

4.3 Cleaning Up the Disk .............................................................24

4.4 Checking For, and Correcting Disk Errors ..............................25

2Contents

4.5 Defragmenting the Disk(s)......................................................25

4.6 Performing Daily Maintenance Tasks......................................25

Chapter 5 Troubleshooting and Conﬁrming Setup.............. 27

5.1 Troubleshooting Display Problems .........................................28

5.2 Troubleshooting Audio Problems ...........................................29

5.3 Troubleshooting Software Problems.......................................29

5.4 Troubleshooting Problems with Optical Drives and

Hard Disks.............................................................................30

5.5 Special considerations for troubleshooting Windows .............31

Chapter

This chapter contains the following

topics:

ØComputer hardware introduction

ØInformation on computer connections

Note: The descriptions in this chapter might

vary from your computer, depending on

computer models and conﬁgurations.

User Guide 1

Using the Computer Hardware

2User Guide

1.1 Front view of the computer

6 7 8 93 4 5

Built-in microphone

Camera

Hard disk drive indicator

Wireless LAN card indicator

LCD ON/OFF indicator (When turning on the LCD, the indicator light will be

off; when turning off the LCD, the indicator light will be solid on.)

Brightness down

Brightness up

LCD ON/OFF

Power button

1.2 Left and right view of the computer

Attention: Be sure not to block any air vents on the computer. Blocked

air vents may cause thermal problems.

User Guide

Memory card reader Microphone connector

USB ports (2) Optical drive slot

Headphone connector

1.3 Rear view of the computer

USB ports (3) PS/2 keyboard connector

Ethernet connector Power connector

4User Guide

1.4 Computer stand

20°

5°

Use the stand to position the display to your preference.It can be adjusted from 5˚

forward to 20˚ backward.

The stand provides stability to the computer; it is not a removable part.

Attention: The computer stand must remain installed at all times to

ensure maximum system stability.

User Guide

1.5 Connecting your computer

Use the following information to connect your computer:

• Lookforthesmallconnectoriconsonthebackofyourcomputer.Matchthe

connectors to the icons.

Note: Your computer might not have all of the connectors that are

described in this section.

1.5.1 Check the voltage rating before you connect the

equipment to an electrical outlet to ensure that the

required voltage and frequency match the available

power source.

If your computer uses an AC adapter:

Note: Use only the Lenovo provided AC adapter approved for use with this

device. Use of another AC adapter may cause a ﬁre or explosion.

1.5.2 Connect the keyboard cable to the appropriate keyboard

connector (PS2 connector or USB connector).

1.5.3 Connect the mouse cable to the appropriate mouse

connector (USB connector).
