Lenovo K900 User manual

Lenovo K900

Quick Start Guide v1.0

For Android 4.2 Software.

Read this guide carefully before using your phone.

Microphone

Flashlight

Micro USB

Speaker

Front camera Power on/off

Volume up

Back camera

Earphone jackSIM card slot 5

Receiver2

29 6

310

Volume down 12

First glance

Type: CMOS

Pixels: 13Mega (back)+ 2Mega (front)

GPS

Height: 157mm Width: 78mm Depth: 6.9mm

Weight: 162g

CPU: Intel dual-core Clover Trail+ (2.0 GHz)

Capacity: 16GB

Size: 5.5-inch (diagonal) Screen: Multi-Touch display

Resolution: FullHD 1080X1920 LCD type: IPS

Model: Lenovo K900 System: Android 4.2

②Bluetooth 3.0 WLAN 802.11a/b/g/n WCDMA, GSM

①Based on actual measurements.

②You must be within about 30 feet (10 meters) of a Bluetooth device

for it to be connected to the phone.

① Standby time: maximum 290 hours

Battery: 2500mAh (Built-in rechargeable lithium-ion battery)

Wireless Communication

Display

Model and System

Power and Battery

CPU and Capacity

① Size and Weight

Camera

Technical speciﬁcations

Step 1. Insert the SIM eject tool into the hole on the SIM card tray.

Step 2. Pull out the SIM card tray and place the SIM card in the tray.

Step 3. Carefully replace the tray.

Height: 157mm Width: 78mm Depth: 6.9mm

Weight: 162g

A SIM card provided by your carrier is required in order to use cellular

services. Install the SIM card as shown.

Only Micro SIM cards work with your phone.

DO NOT insert or remove the SIM card while your phone is turned on.

Doing so may permanently damage your SIM card or phone.

Installing the SIM card

Method 1. Connect your phone to a power outlet using the included

cable and USB power adapter. or

Method 2. Charge the battery using a computer.

Low battery Fully charged Charging

For more information about battery safety, see the Important Product

Information Guide.

Charge the battery as shown.

Charging the battery

Screen lock/unlock

Lock: Press the Power on/off button.

Unlock: Press the Power on/off button, then:

•drag the slider to unlock.

•drag the slider to open Super Camera.

•drag the slider to make calls.

•drag the slider to send and receive

messages.

Power on/off

Power on: Press and hold the Power on/off

button until the Lenovo logo appears.

Power off, Restart and swich mode: Press and

hold the Power on/off button for a few seconds,

then tap the Power off, Restart or other mode.

When you’re not using the phone you can lock it to turn off the display

and save battery power.

Turning the phone on and off

Step 1. Connect the phone to a USB 2.0 or 3.0 port on your computer.

Then the screen shows the USB Access Mode.

Step 2. Set USB Access Mode options：

• Select MTP.

• Select Mass Storage, tap Turn on USB storage.

•Select USB debug mode.

Step 3. Transfer ﬁles between the phone and the computer.

Step 4. Manage the ﬁles by touching FileBrowser.

Sync your phone with the computer as shown.

Syncing the phone

•

Rearrange Apps

•

Organize Apps in folders

•

Change the Wallpaper

•

Create a new Home screen

•

Move an App to another screen

Folders

Home Back

APP Menu

App (Browser)

App (Dialer)

Apps

Widgets

App (Messaging)

App (Contacts)

Wallpaper

Status bar

You can customize the layout of your Apps and Widgets on the Home

screen.

Customizing the phone

Backup information to SD card

Touch > Backup&Restore > Backup User Data

Restore information from SD card

Touch > Backup&Restore >

BACKED UP RECORD LIST

Calling

Contacts

Make calls

Touch > Dialer.

Speed Dial

Touch > Dialer > InfoCenter > Speed Dail

Manage contacts

Touch > Contacts.

Import/Export contacts

Touch > Contacts > InfoCenter > Contacts Manage

Messaging

Send

Send/Receive messages

Touch > Messaging.

Import/Export messages

Touch > Messaging > InfoCenter > SMS Settings

Backup and restore

This function requires support from your wireless carrier.

Communicating with people

Share your phone’s 3G internet connection to your

computer and other devices by enabling this

function.

Personal hotspot

Setting wireless network

Webpages

Touch > Personal hotspot.

Make sure the wireless network is available.

Touch > Settings > ALL SETTINGS >

WLAN, Data connection

Touch > Email.

•Set an account: Before you use it the ﬁrst time,

you need to set an account.

•Search email: Tap , enter the keywords, then

tap .

•Send email: Tap , enter To, Subject and the

email body, then tap .

Touch > Browser.

•View a webpage: Tap the address ﬁeld, enter the

URL, then tap Go.

•Close a webpage: Tap , then tap by the

page.

•Save bookmark:Tap , then tap OK.

Surﬁng on the Internet
