Lenovo S660 User manual
Read this guide carefully before using your device.
Quick Start Guide v1.0
Lenovo S660
Type: CMOS
Pixels: 8 MP (back) + 0.3 MP (front)
Height: 137 mm (5.39
inches
) Width: 68.8 mm (2.7
inches
)
Depth: 9.95 mm (0.39
inches
) Weight: 151 g
CPU: MTK 6582m 1.3 GHz Quad Core
Size: 4.7 inches (diagonal) Screen: Multi-Touch display
Resolution: 960 x 540 LCD type: IPS
Model: Lenovo S660 System: Android 4.2
*Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS
Battery: 3000 mAh
Model and System
Actual product may differ.
*Launch with Android 4.2 which only supports BT 4.0 PXP profile.
Display
Battery
CPU
Size and Weight
Camera
Wireless Communication
Technical specifications
Back camera
On/Off button
Flashlight
Receiver Microphone
Volume key
Speaker
Earphone jackMicro USB port 5
10
Front camera2
6
3
789
4
1
10
9
43
25 3
6
7
8
1
First glance
You need to insert the SIM card provided by your carrier to use
cellular services. Install your phone as shown.
DO NOT insert or remove the SIM cards while your phone is turned on.
Doing so may permanently damage your SIM cards or your phone.
SIM2
SIM1
SIM2
SIM1
b
a
SIM2
SIM1
SIM1
SIM2
SIM2
SIM1
SIM1
SIM2
SIM2
SIM1
SIM2
SIM1
Step 1. Open the back cover.
TIP 1: Use your finger or a plastic
opening tool to pry the back
cover.
TIP 2:
Do not apply force when
opening the back cover to
avoid breakage.
TIP 3:
Make sure to align the hooks
with the designated holes on
your phone. Be careful not to
bend the hooks on the back
cover.
Preparing your phone
Step 2. Insert the SIM cards and
the memory card.
TIP: Insert the SIM1 (USIM) card
into SIM1 slot and SIM2 card
into SIM2 slot.
Step 3. Install th
e battery.
Align the battery
connectors on the battery
with the pins in the
battery
compartment. Then push
the battery down into
place.
Step 4. Install the back cover.
Method 1. Connect your phone to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
Your device has a rechargeable battery. For more information about
battery safety, see “Rechargeable battery notice” in the Important
Product Information Guide.
2
1
Charge the battery as shown.
Charging the battery
8306VV3810W
Printed in China
First Edition (February 2014) © Copyright Lenovo 2014.
Learn more
Legal notices
Lenovo, the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be
trademarks or service marks of others.
For more information about Lenovo Mobile Phone functions，
Regulatory Notices and other useful manuals, go to
http://support.lenovo.com/.
Getting support
For support on network service and billing, please contact
your wireless network operator. For instructions on how to use
your device, go to
http://support.lenovo.com/.
