Kohler K-6228 Assembly instructions
Installation and Care Guide
Wall-Mount Kitchen Sink Faucet
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de
Mcorresponden a México (Ej.
K-12345M)
Français, page “Français-1”
Español, página “Español-1”
K-6228
1095311-2-J
Tools and Materials
Before You Begin
CAUTION: Risk of property damage. Before finishing the
wall, make sure the supply lines are connected to the mixer
valve with the cold line plumbed on the left and the hot line
plumbed on the right.
IMPORTANT! Unless otherwise indicated, the illustrations in this
document show installation for a handle located to the right of the
spout. The valve is designed for handle installation on the right.
Special steps will need to be performed to position the handle to the
left of the valve.
NOTICE: For exterior wall installations, be sure proper wall
insulation is installed to prevent frozen pipes.
NOTE: For service parts information, visit your product page at
www.kohler.com/serviceparts.
Observe all local plumbing and building codes.
Shut off the water supply.
Carefully inspect supply tubing for any sign of damage.
The supplied plaster guard will also be used to assemble the
valve. The supplied spout tool will also be used for alignment of
the spout escutcheon.
2x4 Lumber
#10 Wood Screws
Plumbers Putty
Solder
Propane Torch
Tube Cutter
1-3/16" and 2-3/16"
Hole Saw
5/64"
3/32"
1095311-2-J 2 Kohler Co.
1. Prepare the Site
IMPORTANT! The illustration shows hole locations for a right side
handle. Reverse the holes for left side handle installation.
NOTE: The mixer valve requires special framing and support.
Construct framing for right side handle installation according to
the dimensions shown. Reverse the holes for left side handle
installation.
Verify the framing is level and will be parallel to the finished
wall. Adjust as needed.
Loosely attach the mixer valve to the framing with one or two
wood screws (not provided).
Using the flat portion of the mixer valve as a guide, level the
mixer valve.
Fully tighten the wood screw(s).
16"
(406 mm)
6"
(152 mm)
1-3/4"
(44 mm)
These
surfaces
to be flush.
1-1/2"
(38 mm)
Ø 2-3/16"
(56 mm)
Ø 1-3/16"
(30 mm)
3-1/2"
(89 mm)
Kohler Co. 3 1095311-2-J
2. Install the Supplies
CAUTION: Risk of property damage. When installing the
handle on either the right or the left side of the spout,
connect the supplies to the mixer valve with the cold supply
line plumbed on the left and the hot supply line plumbed on
the right. For left side handle installation, disregard the cold
label on the mixer valve.
IMPORTANT! The illustration shows a right side handle
installation. The supply can also be installed with the handle on the
left side.
Install 1/2″supply lines to the mixer valve with the cold supply
on the left and the hot supply on the right.
Temporarily remove and retain the plaster guard/tool and spout
plug.
Position a bucket in front of the spout shank, then turn on the
water supplies to the mixer valve.
Slowly open the valve stem. Allow hot and cold water to flow
from the water supplies for approximately 1 minute to remove
any debris.
Close the valve stem. Check all connections for leaks.
Reattach the plaster guard/tool and spout plug.
Cold Supply
Plaster
Guard/Tool
Spout Plug
Mixer Valve
Hot Supply
Valve Stem
Spout
Shank
1095311-2-J 4 Kohler Co.
3. Complete the Finished Wall
IMPORTANT! The illustration shows hole locations for a right side
handle. Reverse the holes for left side handle installation.
Measure and mark the hole centers 6″(152 mm) apart from each
other.
Using a hole saw, drill a 1-3/16″(30 mm) hole for the spout and
a 2-3/16″(58 mm) hole for the handle.
Complete the finished wall.
6" (152 mm)
Ø 1-3/16"
(30 mm)
Finished Wall
Ø 2-3/16"
(56 mm)
Kohler Co. 5 1095311-2-J
4. Install the Spout
NOTE: Anchors are required when installing to materials such as
glass, mirror, and ceramic tile. The anchors and fasteners are not
supplied. Select appropriate fasteners and anchors for the finished
wall material.
If Anchors Are Required
Position the wall flange over the spout plug (not shown) with the
three holes at the 2, 6, and 10 o’clock positions. Mark the hole
locations on the wall.
Drill holes at each of the marks, using the drill bit size and type
appropriate for the finished wall material.
All Installations
Confirm there are three setscrews pre-installed in the wall flange.
Make sure they do not protrude into the inside diameter of the
wall flange. Adjust as necessary using a 3/32″hex wrench.
Apply plumbers putty or other suitable sealant to the back of the
wall flange.
Slide the wall flange over the spout plug (not shown).
Position the three holes on the wall flange at the 2, 6, and 10
o’clock positions, then secure the flange with three wood screws
or other appropriate fasteners (not provided).
Remove the spout plug.
Temporarily place the escutcheon on the wall flange.
Setscrews Escutcheon
Apply sealant
to the back of
the flange.
Spout
Setscrew
Wood Screws
1095311-2-J 6 Kohler Co.
Install the Spout (cont.)
Thread the spout onto the mixer valve until the spout is fully
seated. If necessary, unthread the spout for alignment.
Slide the escutcheon away from the finished wall to access the
setscrew holes.
Using a 3/32″hex wrench, tighten the three setscrews in the wall
flange until the setscrews contact the spout. Fully tighten the
setscrews.
Slide the escutcheon back against the finished wall and onto the
wall flange.
With the escutcheon setscrew hole at the 6 o’clock position, use a
5/64″hex wrench to secure the escutcheon with a setscrew.
Kohler Co. 7 1095311-2-J
5. Adjust the Valve - Right Handle
CAUTION: Risk of property damage. The water supply
must be shut off before performing these steps.
CAUTION: Risk of property damage. At the maximum
valve body extension, a detent will be encountered. To avoid
leakage, do not extend the valve beyond this detent. If the
valve needs to be extended further, install deep rough-in kit
1107027. If the valve needs to be recessed further, install
shallow rough-in kit 1107026.
Shut off the water supply.
Remove the plaster guard/retaining ring tool.
Position a bucket at the spout outlet, then open the valve handle
to relieve water pressure. Leave the handle open.
Using the tool, loosen the threaded retaining ring until the valve
body disengages from the mixer valve.
Using a straight edge, adjust and hold the valve body flush with
the finished wall.
NOTE: A screwdriver inserted through the holes in the plaster
guard/retaining ring tool can serve as a handle.
With the valve body flush with the finished wall, retighten the
retaining ring with the tool.
Close the valve handle.
Turn on the water supply and check that the valve is functioning
properly.
Retaining Ring
Plaster Guard/
Retaining Ring Tool
1095311-2-J 8 Kohler Co.
6. Adjust the Valve - Left Handle
CAUTION: Risk of property damage. The water supply
must be shut off before performing these steps.
CAUTION: Risk of property damage. At the maximum
valve body extension, a detent will be encountered. To avoid
leakage, do not extend the valve beyond this detent. If the
valve needs to be extended further, install deep rough-in kit
1107027. If the valve needs to be recessed further, install
shallow rough-in kit 1107026.
IMPORTANT! Perform these steps when the handle will be located
on the left side of the spout.
Shut off the water supply.
Remove the plaster guard/retaining ring tool.
Position a bucket at the spout outlet, then open the valve handle
to relieve water pressure. Leave the handle open.
Using the tool, loosen the threaded retaining ring until the valve
body disengages from the mixer valve.
Retaining Ring
180˚
Plaster Guard/Tool
Valve Body
O-Rings
Spring Plunger
Kohler Co. 9 1095311-2-J
Adjust the Valve - Left Handle (cont.)
Pull out the valve body. The plaster guard/retaining ring tool can
be threaded onto the valve body to get a better grip when pulling
it out.
Rotate the valve body 180 degrees from the original position. This
allows the handle to move up when turning the water on.
Verify the o-rings on both the valve body and the mixer valve are
undamaged.
Verify the spring plunger is installed and is flush with the surface
of the valve body.
Reinstall the valve body into the mixer valve until fully seated.
Using a straight edge, adjust and hold the valve body flush with
the finished wall.
NOTE: A screwdriver inserted through the holes in the plaster
guard/retaining ring tool can serve as a handle.
With the valve body flush with the finished wall, retighten the
retaining ring with the tool.
Close the valve handle.
Turn on the water supply and check that the valve is functioning
properly.
1095311-2-J 10 Kohler Co.
