JVC VN-X35UL - Network Camera Guide

Lens Settings of VN-X35U

Lens type option and lens adjustment are added to VN-X35U from Version 2.02.

In factory settings, TAMRON lens is chosen and lens control is adjusted to TAMRON lens.

To use FUJINON lens, please change lens settings as following.

Lens settings on Internet Explorer

Lens settings are available on Basic Setting2 page or Maintenance page.

See INSTRUCTIONS(Settings) to open those pages.

Basic Setting2 page

Maintenance page

Choosing Lens Type

Basic Setting2 page: Choose lens type and click OK button.

Maintenance page: Choose lens type and click Apply button.

Lens Type 1(TAMRON) : Choose the item to use TAMRON lens.

2(FUJINON) : Choose the item to use FUJINON lens.

Adjusting Lens Control

Shoot bright and white object. Click Execute button and wait a while. (It takes about 10-15

seconds for the adjustment.)

When the adjustment is completed, following message is displayed.

"Lens adjustment is completed."

If error message, "Please shoot bright object, and try it again." is displayed, shot object is too

dark.

Please shoot brighter and whiter object and click Execute button again.

To reset the adjustment to factory setting, click Initialize button of Lens Adjustment.

ⓒ2010 Victor Company of Japan, Limited LST1114-001A
