Jung HOME BTS1B2U User manual
Table of contents
1 Safety instructions.............................................................................................................3
2 Device components...........................................................................................................4
3 Intended use .....................................................................................................................4
4 Product characteristics......................................................................................................5
5 Operation ..........................................................................................................................6
6 Mounting and electrical connection...................................................................................8
7 Commissioning via app ...................................................................................................11
8 Resetting the device to the factory setting ......................................................................13
9 Technical data.................................................................................................................14
10 List of functions and parameters .....................................................................................16
11 Accessories.....................................................................................................................21
12 Conformity.......................................................................................................................22
13 Warranty..........................................................................................................................22
2 / 22
82405803 23.02.2023
J0082405803
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
1 Safety instructions
To avoid possible damage, read and follow the following instructions:
Installation only by persons with appropriate knowledge and experience in the
following areas:
– 5 safety regulations and standards for the installation of electrical systems
– Selection of suitable tools, measuring devices, installation materials and, if ne-
cessary, personal protective equipment
– Installation of the installation material
– Connection of devices to the building installation under consideration of local
connection conditions
Improper installation endangers your own life and the lives of users of the electrical
system and there is a risk of serious damage to property, e.g. through fire. You are at
risk of personal liability for personal injury and damage to property.
Contact an electrical fitter!
The device must not be used in connection with consumers that could lead to danger
to life or limb or damage to property, e.g. heaters or electrical machines.
Danger of electric shock. Device is not suitable for disconnection from supply voltage
because mains potential even is applied on the load when the device is switched off.
Before carrying out work on the device or load, switch off all associated circuit break-
ers.
The device must not be used for applications from the area of safety engineering,
such as emergency stop, emergency call, smoke extraction.
Read the instructions in full, observe them and keep them for future reference.
You can find more information on JUNG HOME at www.jung.de/JUNGHOME
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
3 / 22
82405803 23.02.2023
J0082405803
2 Device components
Image1: Device components
(1) Prog. button
(2) Status LED
(3) Terminals
LED display during operation
Green* Load is switched on
Orange* Load is switched off
Red Disabling function active, e.g. continuously on/off
Flashing green/red Device update is being carried out
Blue, triple flashing Time has not been set, e.g. due to extended power failure
*Colour adjustable
3 Intended use
– Manual and automatic switching of lighting elements and common household
devices
– Control via binary inputs of the JUNG HOME actuator, JUNG HOME push-but-
ton, JUNG HOME sensors and JUNG HOME app
– Polling of conventional switching contacts and push-button contacts for report-
ing states, triggering scenes, operating loads, etc.
– Wireless connection to devices from the JUNG HOME system
– Mounting in appliance box with dimensions according to DIN 49073
– Mounting in false ceilings in the built-in housing (accessory)
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
4 / 22
82405803 23.02.2023
J0082405803
4 Product characteristics
– Commissioning and operation using JUNG HOME app on mobile end device
(smartphone or tablet) via Bluetooth
– Free linking of the 2 binary inputs with JUNG HOME actuators (local or wire-
less)
– Independent use of actuator function and binary inputs
– Multi-coloured status display and Prog button for commissioning
– Disabling of the Prog button
– Integration of the load into areas (groups), main functions and scenes
– Up to 16 time programs
– Staircase lighting function (automatic switch-off) with switch-off warning
– Run-on time, switch-on delay, switch-off delay
– Activating/deactivating automatic functions with the JUNG HOME app
– Automatic date and time update when connecting with smartphone
– Bluetooth SIG Mesh for fully encrypted wireless communication and repeater
function
– Updating via JUNG HOME app
Available by update in the future:
– Time programs with sunrise and sunset (astro timer)
– Time programs with random time
– Disabling function and restraint: continuously ON/OFF or ON/OFF for fixed
time
– Wind alarm by connecting conventional weather sensors to binary inputs
– Triggering disabling functions via binary inputs, e.g. lock-out protection for
awnings, shutters and venetian blinds, restraint guidance, etc.
You can find information on updates and dates at www.jung.de/JUNGHOME.
Behaviour after a mains voltage failure
All settings and time programs are retained. Any missed switching times are not ap-
plied later. The load output is switched off, provided the parameter "Switching state
after the mains voltage returns" is set to its default setting.
If the device was not previously added to a Bluetooth Mesh network (project) by
means of the JUNG HOME app, it will switch to pairing mode for two minutes when
the mains voltage returns and the status LED will flash slowly at a regular interval in
blue.
Power failure shorter than power reserve (min. 4 hours)
– Time and date are up to date
– The following time are executed normally again
Power failure longer than power reserve (min. 4 hours)
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
5 / 22
82405803 23.02.2023
J0082405803
– The LED flashes blue three times repeatedly until the time is automatically up-
dated when connected to the app
– The time programs are not executed as long as the time has not been set
5 Operation
All settings and operations of the device can be configured individually using the
JUNG HOME app.
The binary inputs and the switch actuator of the device can be used independently of
one another. For example, a Multi push-button connected to the binary inputs can op-
erate a venetian blind insert (combined with a JUNG HOME push-button), whereas
the switch actuator is controlled only by means of the app and time programs.
Operation via binary inputs
If a push-button (e.g. 531 U or 505 TU) is connected to a binary input, its operation
will trigger different functions, depending on the duration of operation (see table).
Configuration in the JUNG HOME app: The push-button is connected either to input
E1 or E2 to control a device, area or scene. The second input can then be used with
another push-button for a different device or area or another scene. The link must be
deactivated in the configuration view of the app for this purpose.
Type of operation Brief press Long press
Switching1 (default setting) Alternately ON/OFF Alternately ON/OFF
Dimming1Alternately ON/OFF Alternately dim brighter /
dim darker
Moving the Venetian blind2Stop or adjust the slats Alternately move upwards/
downwards
Operating the scene1Calling up scene 1 Calling up scene 1
1 brief push-button action < 0.4 s < long push-button action
2 brief push-button action < 1 s < long push-button action
If a Multi push-button (e.g. 531-41 U) is connected to both binary inputs, operation of
the upper or lower button area will trigger different functions, depending on the dura-
tion of operation (see table).
Configuration in the JUNG HOME app: The two buttons of the Multi push-button are
connected to input E1 and E2 to control a device, area or scene together. The link
must be activated in the configuration view of the app for this purpose. If two different
scenes 1 and 2 are called up via E1 and E2 with a Multi push-button, the link must be
deactivated.
Type of operation Brief press Long press
Switching1Top ON / bottom OFF Top ON / bottom OFF
Dimming1Top ON / bottom OFF Top: dim brighter / bottom:
dim darker
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
6 / 22
82405803 23.02.2023
J0082405803
Type of operation Brief press Long press
Moving the Venetian blind2Stop at the top or adjust the
slat position forwards / Stop
at the bottom or adjust the
slat position backwards
Top: move up / bottom:
move down
Operating the scene1Top: recall scene 1 / bot-
tom: recall scene 1
Top: recall scene 1 / bot-
tom: recall scene 1
Heating1Increase the target temper-
ature by 0.5 °C at the top /
Decrease the target tem-
perature by 0.5 °C at the
bottom
-
Operating an area (group)
1/2 Depending on the unit, as
described for switching,
dimming, Venetian blinds
and heating
Depending on the unit, as
described for switching,
dimming, Venetian blinds
and heating
Disabling function (lock-out
protection, restraint guid-
ance) 1
- Top: activate / bottom: de-
activate
If a Venetian blind push-button (505 TU without locking recommended, for example,
since mutual locking of the buttons is not necessary with binary inputs) is connected
to both binary inputs, operating the left or right button will trigger different functions
(see table).
Configuration in the JUNG HOME app: The two buttons of the Venetian blind push-
button are connected to input E1 and E2 to control a device or area together. The link
must be activated in the configuration view of the app for this purpose.
Type of operation Brief press Long press
Moving the Venetian blind2Stop on the left or adjust
the slat position forwards /
Stop on the right or adjust
the slat position backwards
Move up on the left / move
down on the right
Operating an area (group) 2Stop on the left or adjust
the slat position forwards /
Stop on the right or adjust
the slat position backwards
Move up on the left / move
down on the right
1 brief push-button action < 0.4 s < long push-button action
2 brief push-button action < 1 s < long push-button action
Wireless operation
Wireless operation is done with linked JUNG HOME devices or via the JUNG HOME
App, which is also used to link the JUNG HOME devices (see 'Commissioning via
App').
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
7 / 22
82405803 23.02.2023
J0082405803
6 Mounting and electrical connection
Communication between the JUNG HOME devices and linked mobile end devices is
performed wirelessly within the range of the Bluetooth Mesh network.
The range of wireless signals can be affected by:
– Number, thickness, position of ceilings, walls and other objects
– Material type of these objects
– High-frequency interfering signals
Observe the following fitting instructions to maximise the range:
– Plan the number of JUNG HOME devices and their positions to keep the num-
ber of ceilings and walls between two devices as low as possible
– If JUNG HOME devices are installed on both sides of a solid wall, they should
be positioned as close as possible to each other on the opposite sides of the
wall. This keeps the attenuation of the wireless signal through the wall as low
as possible.
– When planning, make sure that there are as few building materials and objects
as possible that strongly attenuate the wireless signal (e.g. concrete, glass,
metal, insulated walls, water tanks, pipes, mirrors, book cabinets, storage
rooms and refrigerators) on the connection line between JUNG HOME devices
– Keep a distance of at least 1 m from devices that emit high-frequency signals
(e.g. microwave, motors) or use wireless signals at 2.4 GHz (e.g. WLAN
router, baby monitor, IP cameras, wireless loudspeakers etc.)
DANGER!
Electric shock when live parts are touched.
Electric shocks can be fatal.
Always disconnect before carrying out work on the device or load. For this, switch off
all corresponding circuit breakers, secure against being switched on again and check
that there is no voltage. Cover up adjacent live parts.
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
8 / 22
82405803 23.02.2023
J0082405803
Image2: Connection example with 2 push-buttons (5)
Image3: Connection example with Multi push-button (6)
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
9 / 22
82405803 23.02.2023
J0082405803
Image4: Connection example with power socket (7)
Image5: Connection example with Venetian blind push-button (8)
JUNG HOME switch actuator 1-gang mini with 2 binary inputs
10 / 22
82405803 23.02.2023
J0082405803
Table of contents
Other Jung Controllers manuals
Jung
Jung KNX 360061SR User manual
Jung
Jung KNX 2131.16 UP User manual
Jung
Jung Smart Pilot 10 User manual
Jung
Jung Smart Control IP Guide
Jung
Jung FM ST 50 UP User manual
Jung
Jung 230061SR User manual
Jung
Jung eNet FMAS10UP User manual
Jung
Jung FST 1240 REG User manual
Jung
Jung 2424 REG HE User manual
Jung
Jung 1741DSTE User manual
Jung
Jung 3210 UP User manual
Jung
Jung KNX 519 KRMTSD Series User manual
Jung
Jung KNX 2095 LUX User manual
Jung
Jung LB management User manual
Jung
Jung KNX 390011 SU User manual
Jung
Jung KNX 2095 LUX User manual
Jung
Jung 230 ME User manual
Jung
Jung FMST50UP User manual
Jung
Jung Instabus 2134.16 REG User manual
Jung
Jung FST 1240 EB User manual
Popular Controllers manuals by other brands
Digiplex
Digiplex DGP-848 Programming guide
YASKAWA
YASKAWA SGM series user manual
Sinope
Sinope Calypso RM3500ZB installation guide
Isimet
Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions
LSIS
LSIS sv-ip5a user manual
Rockwell Automation
Rockwell Automation 1769-L31 installation instructions
