Jackson 224W Maintenance and service guide
JACKSON TOOL • P. O. BOX 5701 • GREENVILLE, SC 29606
877-522-8995 or 864-721-4235 • FAX 864-721-4236 • www.jacksontoolinc.com
This manual is free of charge. All personnel who operate the Rolling Stand should have a copy
of this manual and read and understand its contents. To request a copy, call or write to the
address below. All information, specifications and product designs may change due to design
improvements or updates and are subject to change without notice. Jackson Tool does not
assume any liability for damages resulting from misuse or incorrect application of its products.
Read and understand this material before operating
or servicing the Threader Stand. Failure to
understand how to safely assemble and use this unit
may result in property damage, serious injury or death.
Assembly, Safety and Operating Manual
5/22
Jackson Tool Threader Stands
Model 224W – Rolling Stand with tray
Model 235W – Rolling Stand with storage box
Model 224W Model 235W
2
TABLE OF CONTENTS
Safety Alerts .............................................. 2
Safety Information ......................................... 3
Model Descriptions ........................................ 3
Maintenance .............................................. 3
Assembly Instructions ...................................... 4
Threader Mounting Positions ................................ 5
Exploded View ............................................ 6
Parts List ................................................. 7
SAFETY ALERTS
Safety Alert
Symbol
THIS SAFETY SYMBOL is used to call your attention to instructions
that concern your personal safety. It means: ATTENTION! BE
AWARE! THIS IS AN IMPORTANT SAFETY INSTRUCTION!
Read, understand and follow these safety instructions. Failure to
follow these safety instructions may result in injury or death.
DANGER
WARNING
CAUTION
Immediate hazards which, if not avoided, WILL result in serious personal
injury or death.
Hazards or unsafe practices which, if not avoided, COULD result in serious
personal injury or death.
Hazards or unsafe practices which, if not avoided, COULD result in minor
personal injury or property damage.
RETAIN SAFETY INFORMATION
3
ALWAYS roll the threader stand on a smooth, level, firm surface. Tipping
of the threader stand may occur if rolled over unlevel surfaces.
ALWAYS operate the threader stand on a level surface.
Threaders MUST be mounted to a stable, properly assembled stand
before operating or transporting. Follow all assembly instructions
provided.
Threader MUST be properly balanced on the stand.
ALWAYS check to ensure the threader you mount to the stand is
mounted to the correct holes in the stand. See page 5 for threader
mounting positions.
IMPORTANT SAFETY INFORMATION
Follow ALL safety information provided by the manufacturer.
WARNING
DANGER
CAUTION
This manual should be read and understood by all personnel who operate or service this
Threader Stand. Failure to understand how to safely assemble and use this unit could result
in injury or death. This unit should only be operated or serviced by qualified personnel.
WARNING
DANGER
CAUTION
WARNING
DANGER
CAUTION
WARNING
DANGER
CAUTION
MODEL DESCRIPTIONS
Model No. Description
Will fit RIGID®*
Model #
224W Rolling Stand with tray 535 – 2001 and newer
1224
235W Rolling Stand with storage box 535 – 2001 and newer
1224
*RIGID®is a registerered trademark of Emerson Electric, Inc.
MAINTENANCE
Grease the wheel bearings with a good gauge of M.P. grease as needed.
ASSEMBLY INSTRUCTIONS
1. Attach front and rear cross members (18,20) to side frames (21,22) with 3/8" - 16 × 1"
hex head cap screws and 3/8" - 16 hex nuts (6,24) as shown in Figure 1. Be sure
crossmembers are assembled as shown in Figure1.
2. Install 2 - axles (16) and secure with 1/2-13 hex nuts and 1/2" lock washer (4,5). Place
wheels onto axles, place 1 washer (2) on each axle (16) and secure with cotter pins (8).
3. Depending on the unit you have ordered, mount either the tray (19) or the storage box
(26) with the 1/4 - 20 × 1/2" slotted round head machine screws and 1/4" flat washers (7,8).
Attach the handle of the storage box (27) with M8 × 12 hex head screws and M8 lock
washers (28,29).
Figure 1
4
THREADER MOUNTING POSITIONS
Figure 2
5
NOTE: Front of 535/1224 is oil reservoir end of unit.
535-A/535
Manual-2001
and newer (Rear)
1224 (Rear)
1224 (Front)
535-A/535
Manual-2001 and newer
(Front)
EXPLODED VIEW – THREADER STANDS
6
PARTS LIST
7
ITEM # PART # DESCRIPTION QTY.
1224-6 WHEEL — 16" 2
2224-7 WASHER — FLAT 3/4" (SAE) 2
3224-8 PIN — COTTER 3/16" X 1-1/4" 2
4224-9 NUT — HEX (1/2"–13) 2
5224-10 WASHER — LOCK 1/2" ZINC 2
6224-11 3/8-16 X 1.0" HEX HEAD SCREW 8
7224-14 SCREW — HEX HEAD CAP (1/4-20 X 1/2") 4
8 224-14I WASHER — FLAT USS 1/4" ZINC 4
9224-21 PIN — CLEVIS (3/8" X 2.250") 2
10 224-23A CABLE — STRANDED 1/16" X 6" 2
11 224-24 PIN — COTTER (1/8" X 1") 2
12 224-25 PLUG — CAP 1.5" 4
13 224-26 ROLLER — RUBBER (2.5 DIA) 1
14 224-27 SCREW — SOC HEAD CAP (5/16-18 X 2.25") 1
15 224-28 NUT — HEX (5/16-18) NYLON INSERT 1
16 224-367 AXLE-224 2
17 224-407 HANDLE 2
18 224-415W CROSSMEMBER — WIDE 1
19 224-416 PAN-224 1
20 224-417W CROSSMEMBER — WIDE, (W/WHEEL BKT) 1
21 224-447LH FRAME — SIDE (LH) 1
22 224-447RH FRAME — SIDE (RH) 1
23 670-6 FERRULE — DOUBLE 4
24 2508-8 NUT — HEX (3/18-16) NYLON INSERT 8
25 9548-7 PIN — QUICK RELEASE 3/8 X 2-1/4" 2
26 2508-8 BOX 1
27 450-11 HANDLE 1
28 235-18 SCREW — HEX HEAD CAP (M8 X 2") 2
29 235-19 WASHER — LOCK M8 2
