Intel D510MO Technical manual

Intel® Desktop Board

D510MO

Specification Update

October 2011

Part Number: E83697-007

The Intel®Desktop Board D510MO may contain design defects or errors known as errata, which may cause the product to deviate

from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board D510MO Specification Update

Revision History

Revision Revision History Date

-001 This document is the first Specification Update for the Intel®Desktop

Board D510MO December 2009

-002 Updated the General Information Section April 2010

-003 Updated the General Information Section May 2010

-004 Updated the General Information Section July 2010

-005 Updated the General Information Section November 2010

-006 Updated the Specification Changes Section April 2011

-007 Updated the General Information Section October 2011

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®Desktop Board D510MO may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Intel and the Intel logo are trademarks of Intel Corporation in the U.S. and/or other countries.

* Other names and brands may be claimed as the property of others.

Intel Desktop Board D510MO Specification Update 3

Contents

Specification Update for the Intel®Desktop Board D510MO

Terminology ............................................................................................ 5

General Information .................................................................................5

Summary of Changes ............................................................................... 6

Specification Changes...............................................................................6

4 Intel Desktop Board D510MO Specification Update

Specification Update for the

Intel®Desktop Board D510MO

This document is an update to the specifications contained in the Intel®Desktop Board

D510MO Technical Product Specification (Order Number: E74523). It is intended for

hardware system manufacturers and software developers of applications, operating

systems, or tools. It will contain Specification Changes, Errata, Specification

Clarifications, and Documentation Changes.

Refer to the Intel®Atom Processor D500 Series Specification Update (Order

Number: 434725) for specification updates concerning the Intel Atom D500 series

processors that may apply to the desktop board D510MO. Unless otherwise noted in

this document, it should be assumed that any Processor errata for a given stepping

are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the Intel®NM10 Express Chipset Specification Update (Order Number:

417137) for specification updates concerning the Intel®NM10 Express Chipset that

may apply to the desktop board D510MO. Unless otherwise noted in this document, it

should be assumed that any Platform Controller Hub errata for a given stepping are

applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Intel Desktop Board D510MO Specification Update 5

Terminology

Specification Changes are modifications to the current published specifications.

These changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop

board behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level

must assume that all errata documented for that AA and BIOS revision level are

present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further

highlight a specification’s impact to a complex design situation. These clarifications

will be incorporated in the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current

published specifications. These changes will be incorporated in the next release of the

specifications.

General Information

Basic Desktop Board D510MO Identification Information

AA Revision BIOS Revision Notes

E76523-302 MOPNV10J.86A.0115 1,2

E76523-400 MOPNV10J.86A.0148 1,2

E76523-401 MOPNV10J.86A.0154 1,2

E76523-402 MOPNV10J.86A.0175 1,2

E76523-403 MOPNV10J.86A.0175 1,2

E76523-404 MOPNV10J.86A.0400 1,2

E76525-301 MOPNV10J.86A.0115 1,2

E76525-400 MOPNV10J.86A.0148 1,2

E76525-401 MOPNV10J.86A.0154 1,2

E76525-402 MOPNV10J.86A.0175 1,2

E76525-403 MOPNV10J.86A.0175 1,2

E76525-404 MOPNV10J.86A.0400 1,2

E67982-303 MOPNV10J.86A.0115 1,2

E67982-400 MOPNV10J.86A.0148 1,2

E67982-401 MOPNV10J.86A.0154 1,2

E67982-402 MOPNV10J.86A.0175 1,2

E67982-403 MOPNV10J.86A.0175 1,2

E67982-404 MOPNV10J.86A.0400 1,2

Notes:

1. The AA number is found on a small label on the component side of the board.

2. The Intel®CG82NM10 Express Chipset used on this AA revision consists of the following component:

6 Intel Desktop Board D510MO Specification Update

Device Stepping S-Spec Numbers

CG82NM10 B0 SLGXX

Summary of Changes

The following table indicates the Specification Changes, Errata, Specification

Clarifications, or Documentation Changes that apply to the Intel®Desktop Board

D510MO. Intel intends to fix some of the errata in a future revision of the desktop

board, and to account for the other outstanding issues through documentation or

specification changes as noted.

The following notations are used in the table:

Doc: Document change or update that will be implemented.

Plan Fix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.

Fixed: This erratum has been previously fixed.

No Fix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the document.

No. Plans Documentation Changes

1 Doc Updated the drawing in Section 2.2.2 Component-side Connectors and Headers to

show Item H reverses pin 1 and pin 7.

No. Plans Errata

There are no characterized erratum for this product.

Specification Changes

The Specification Changes listed in this section apply to the Intel®Desktop Board

D510MO Technical Product Specification (Order Number E74523).

1. Updated the drawing in Section 2.2.2 Component-side Connectors and Headers to

show Item H reverses pin 1 and pin 7.
