Replacing the Base Unit

Use this checklist to verify all parts from the original system have been moved to the replacement base unit.

NOTE Be sure to copy PRODUCT NUMBER, SERIAL NUMBER and UUID values onto the blank

labels and apply them to the system product information label on the base unit.

Figure 1 Location of Components of Base Unit

PCI I/O Backplane

Assembly

DIMMs

CPU(s)

CPU Power Pod(s)

Management Processor card

Power Supply Fans

Power Supply

DVD filler if no DVD

Hard Disk

Drive (HDD)

Display Panel

DVD or

CD-RW/DVD

Chassis Fans

Management

Processor Filler

(on rear panel)

HDD filler if no HDD

CPU Airflow guide

(single CPU config.)

System

Product

Information

Label

2

Step 1. Remove the following components from your existing base unit. Refer to sections of the Operation

and Maintenance Guide, included on the hp Server Documentation CD-ROM for component

removal instructions.

Step 2. Install the previously removed components into the new base unit. Refer to sections of the

Operation and Maintenance Guide, included on the hp Server Documentation CD-ROM for

component replacement instructions.

Step 3. You will have to reconfigure the system boot settings at EFI.

Step 4. Follow the instructions that accompany the new base unit to return the hardware to

Hewlett-Packard.

Table 1 List of Components to be Removed

• Power Supply Fans • Chassis Fans

• Power Supply • PCI I/O Backplane Assembly

• CPU airflow guide (single CPU systems only) • CPU(s) and associated Power Pods

• Memory DIMMs • DVD or CD-ROM (if present)

• DVD Filler (present when a DVD or CD-ROM

is not installed)

•Disk(s)

• Disk Filler(s) (present on disk-less systems) • Display Panel

• Management Processor card (optional card,

may be present)

• Management Processor Blank (present when

Management Processor not installed)

Table 2 List of Components to be Replaced

• Power Supply Fans • Chassis Fans

• Power Supply • PCI I/O Backplane Assembly

• CPU airflow guide (single CPU systems only) • CPU(s) and associated Power Pods

• Memory DIMMs • DVD or CD-ROM (if present)

• DVD Filler (present when a DVD or CD-ROM

is not installed)

•Disk(s)

• Disk Filler(s) (present on disk-less systems) • Display Panel

• Management Processor card (optional card,

may be present)

• Management Processor Blank (present when

Management Processor not installed)
