Gigabyte 6BXC User manual
R-19-01-081126
6BXC
USER'S MANUAL
1. System power on by PS/2 Mouse: First, enable this function
in CMOS Setup, then you can power on the system by double
clicking the right or left button of your PS/2 Mouse.
2. System power on by Keyboard: If your ATX power supply
supports larger than 100~300 mA 5V Stand-By current
(dependent on the specification of keyboards), you can
power on your system by entering password from the
keyboard after setting the “Keyboard power on”password in
CMOS Setup.
3. Supports 3 steps ACPI LED.
4. Modem Ring-On. (COM A , B).
5. Wake-Up on LAN. (on JP7) (The ATX power supply supports
larger than 720 mA 5V Stand-By current)
*
System/Power Fan, Clear CMOS, Internal Ring Pwr on and
Power connector function only for PCB Rev:1.9 use, please
reference page 10, 16~18.
For Intel Pentium
II / CeleronTM Processor MAINBOARD
REV. 1.9 First Edition
6BXC
1
The author assumes no responsibility for any errors or omissions which may
appear in this document nor does it make a commitment to update the
information contained herein.
Third-party brands and names are the property of their respective owners.
Sound Blaster is a registered trademark of Creative Technology Ltd in the
United States and certain other countries. Sound Blaster-LINK and SB-LINK are
trademarks of Creative Technology Ltd.
November 26, 1998 Taipei, Taiwan
I. Quick Installation Guide :
Quick Installation Guide
2
CPU SPEED SETUP
The system bus speed is selectable between 66 / 100 MHz. The user can select
the system bus speed (SW1) and change the DIP SWITCH (SW2) selection to
set up the CPU speed for 233 - 633MHz processor.
Set System Bus Speed
SW1:
CPU AGP 1 23 4
100 MHz
66 MHz OFF OFF OFF OFF
133 MHz
89 MHz OFF OFF ON OFF
112 MHz
75 MHz OFF ON OFF OFF
66 MHz 66 MHz ON OFF OFF ON
75 MHz 75 MHz ON ON OFF ON
83 MHz 83 MHz ON OFF ON ON
The CPU speed MUST match with the frequency RATIO. It will cause
system hanging up if the frequency RATIO is higher than that of CPU.
SW2:
CLK RATIO 1 23 4
X3 ON OFF ON ON
X3.5 OFF OFF ON ON
X4 ON ON OFF ON
X4.5 OFF ON OFF ON
X5 ON OFF OFF ON
X5.5 OFF OFF OFF ON
X6 ON ON ON OFF
X6.5 OFF ON ON OFF
«
Note: We don’t recommend you to setup your system speed to 75, 83,
112 or 133MHz because these frequencies are not the standard
specifications for CPU, Chipset and most of the peripherals.
Whether your system can run under 75, 83, 112 or 133MHz
properly will depend on your hardware configurations: CPU,
SDRAM, Cards, etc.
6BXC
3
1. PentiumII /Celeron 233 / 66 MHz FSB
CPU
Intel
440BX
PIIX4
6BXC
ON
OFF
SW 2
1234
ON
OFF
SW 1
1234
2. PentiumII /Celeron 266 / 66 MHz FSB
3. PentiumII /Celeron 300/Celeron 300A / 66 MHz FSB
4. PentiumII /Celeron 333 / 66 MHz FSB
SW2 ON
4 3 2 1 OFF
SW1 ON
4 3 2 1 OFF
SW2 ON
4 3 2 1
OFF
SW1 ON
4 3 2 1
OFF
SW2 ON
4 3 2 1 OFF
SW1 ON
4 3 2 1 OFF
Quick Installation Guide
4
5. PentiumII /Celeron 366 / 66MHz FSB
6. PentiumII /Celeron 400 / 66MHz FSB
7. PentiumII /Celeron 433 / 66MHz FSB
8. PentiumII 350 / 100 MHz FSB
9. PentiumII 400 / 100 MHz FSB
10. PentiumII 450 / 100 MHz FSB
SW2 ON
4 3 2 1
OFF
SW1 ON
4 3 2 1
OFF
SW2 ON
4 3 2 1 OFF
SW1 ON
4 3 2 1 OFF
SW2 ON
4 3 2 1 OFF
SW1 ON
4 3 2 1 OFF
SW2 ON
4 3 2 1
OFF
SW1 ON
4 3 2 1
OFF
SW2 ON
4 3 2 1
OFF
SW2 ON
4 3 2 1
OFF
SW1 ON
4 3 2 1 OFF
SW1 ON
4 3 2 1
OFF
6BXC
5
11. PentiumII 500 / 100 MHz FSB
12. PentiumII 550 / 100 MHz FSB
13. PentiumII 600 / 100 MHz FSB
14. PentiumII 650 / 100 MHz FSB
SW2 ON
4 3 2 1
OFF
SW1 ON
4 3 2 1
OFF
SW2 ON
4 3 2 1
OFF
SW1 ON
4 3 2 1
OFF
SW2 ON
4 3 2 1 OFF
SW2 ON
4 3 2 1 OFF
SW1 ON
4 3 2 1
OFF
SW1 ON
4 3 2 1 OFF
Quick Installation Guide
6
II. Jumper setting :
SPK : Speaker Connector
1
CPU
Intel
440BX
PIIX4
6BXC
1
Pin No. Function
1
2
VCC
NC
3NC
4Data
++
RST : Reset Switch
CPU
Intel
440BX
PIIX4
6BXC
Open:
Normal
operation
Short:
For Hardware
Reset System
6BXC
7
PW LED : Power LED Connector
CPU
Intel
440BX
PIIX4
6BXC
11
Pin
No.
Function
1
2
LED
anode (+)
LED
cathode (-)
3LED
cathode (-)
HD : IDE Hard Disk Active LED
CPU
Intel
440BX
PIIX4
6BXC
1
1
Pin
No.
Function
1
2
LED
anode (+)
LED
cathode (-)
3
LED
cathode (-)
4LED
anode (+)
Pin
No.
Function
1
2
LED
anode (+)
LED
cathode (-)
Quick Installation Guide
8
IR : Infrared Connector (Optional)
CPU
Intel
440BX
PIIX4
6BXC
1
Pin
No.
1
2
3
4
5
IR Data
Output
GND
IR Data
Input
NC
POWER (+)
Function
GN : Green Function Switch
CPU
Intel
440BX
PIIX4
6BXC
Open:
Normal
operation
Short:
Entering
Green Mode.
