GE Silent Alert 45137 User manual

45137

Choice

ALERT

Choice

ALERT

™

Control all Sensors

& accessories from

one location

™

Wireless Alarm System

Silent Alert™

User’s Manual

Important Safeguards 4

Introduction 4

Adding a Silent Alert to the system 5-6

Testing the Silent Alert or your system 6

Installation 7

Low battery indicator 9

Battery warnings 9

FCC Warning 8

Table of Contents

Before connecting or operating the Silent Alert,

please read these instructions carefully and save

this manual for future reference.

Congratulations

The GE Choice Alert™Wireless Alarm System is one

of the most affordable and expandable wireless

alarm systems available. You’ll discover the system

offers many features typically found in custom

installed Alarm systems.

The Choice Alert system is reliable and easy-to-use.

With Choice Alert you can select from a line of Sensors

and Accessories; start small and expand as you

need, or create a system that meets all your needs.

The Choice Alert System is protected by Priority

Code Selection technology which provides increased

security and trouble-free wireless connections. It

also guarantees the Control Center will only respond

to signals from your Sensors in and around your home,

and prevents anyone from tampering with

your system.

The user manual explains in simple steps how to

install, use and care for your new Choice Alert

Silent Alert.

If you have any questions or would like

additional information please visit our web site

www.jascoproducts.com, or contact our

Customer Service Group at 1-800-654-8483.

Important safeguards

PreCautions

1. Do not attempt to disassemble the Silent Alert,

unless described in the user’s manual. There are no

user serviceable parts.

2. Handle with Care – Avoid striking or shaking.

Improper use or storage could damage the Silent

Alert. Modifying or tampering the device or its internal

components can cause a malfunction and void the

Silent Alert’s warranty.

3. If you feel the Silent Alert or any part of the Choice

Alert system is not operating correctly or as described,

please contact Customer Service for assistance

(1-800-654-8483).

Introduction

The Silent Alert is an excellent addition the Choice

Alert Alarm system. It can provide an extra level of

awareness for alarm activity as well as keep you and

your family informed about the status of the wireless

alarm. There is no limit to the number of Silent Alerts

that can be added to the system. Suggested discrete

places to position the Silent Alert may be above the

Garage door, above the interior garage door leading

into the house, over or along side a window, under

the eve of a roof line… generally any area that is easy

to notice but secluded enough so only you and your

family know where to look.

The Silent Alert will only activate once an alarm is

actually sounded. It will not activate during the entry

and exit delay times. It cannot be turned-off unless

it receives a disarm code from the Control Center it

is linked with, or the batteries have been removed.

Once activated it will continue to blink for several days.

It cannot be disarmed even if the Control Center is

unplugged or destroyed.

Parts Check List

Identify all the parts before proceeding.

The Silent Alert is designed to provide a visual

warning BEFORE entering the home if an alarm has

Silent Alert

2 - Screws

2 - Plastic anchors

2 - Rubber gromets

Double sided tape

been triggered.

You can add any number of Silent Alert LED indicators

to the Choice Alert System. To add a Silent Alert to the

system, you will need to link it with the Control Center.

Adding a Silent Alert™

In order to link the Silent Alert to the Crontrol Center,

you will need to have the Silent Alert and Control

Center near each other.

Step 1 - Open the Silent Alert by gently inserting a

small blade screwdriver into the tab slot on one end

and gently pry upwards. This action releases the

cover from the base. This procedure can be easily

completed once the Silent Alert is mounted as well.

Install two (2) new “AA” batteries according to the

polarity markings in the battery compartment.

Step 2 - Press and hold the Learn button inside the

Silent Alert. One of the LED indicators on the front of

the Silent Alert will begin to ﬂash.

Step 3 - While continuing to press the Learn button

in the Silent Alert, press and hold the Mute button

on the side of the Control Center for

Learn button

three seconds.

Step 4 - Release all buttons.

The Control Center will sound two beeps

and ﬂash the green power indicator, this

indicates a test signal was sent to the Silent

Alert. When the Silent Alert receives the test

Signal, the LED indicator will stop ﬂashing,

indicating it has been linked with your

Control Center. Reattach the Silent Alert to

the base.

Anytime the alarm is triggered (in Armed HOME or

AWAY), and the siren sounds, the Control Center will

send a signal to the Silent Alert to begin alternately

ﬂashing its LED indicators. The Silent Alert will continue

to ﬂash the LED indicators until the Control Center

sends a disarm signal.

Note: Even if the Control Center is disconnected from power

or destroyed, the Silent Alert will continue to ﬂash LED

indicators.

Installation

You will need to determine if the surface to mount the

Silent Alert is smooth or rough/porous. If smooth you

can use the included double sided tape. When using

doublesided tape apply to clean dry surface. Remove

one side of the tape and attach it to the back side of

the Silent Alert. Once the mounting surface is ready,

remove the other side of the double side tape and

press into position.

Alert

Chime

Off

Mute

Learn

Input DC 12V

If the mounting surface is rough or porous, you will need

to use the rubber gromments and screws (included).

Secure the plate to the desired location with the screws.

Test the Silent Alert

Step 1 - After the Silent Alert has been successfully

linked with the Control Center, press and hold the

Mute button on the Control Center for three

seconds. This action sends a test signal.

Step 2 - When the Silent Alert receives the test

signal from the Control Center, one LED indicator on

the Silent Alert will begin to ﬂash once a second. It

will continue to ﬂash for 30 seconds.

Erasing the Silent Alert from the system

Step 1 - Remove the batteries from the Silent Alert.

Step 2 - With the batteries removed, press and hold

the Learn button.

Smooth surface Porus uneven surface

Model # Description Battery Type Battery Life*

45129 Control Center (4) “AAA” 24 months

45137 Silent Alert (2) “AA” 18 months

*maximum potential life based upon usage and location

Step 3 - While pressing the Learn button, re-install

the batteries. The LEDs will ﬂash rapidly and then

stop. This indicates the Silent Alert has been

removed from the system.

Step 4 - Release all buttons

Low Battery Indicator

When the voltage level of batteries reach low levels,

one LED will begin to ﬂash once every 5 seconds. This

indicates that the batteries need to be replaced.

WARNING!

Risk of personal injury

- Prolonged exposure to alarm

siren may cause permanent

hearing loss

Battery Warning!

- Remove batteries before storing

the Alarm or Sensor for extended periods

- Batteries may leak harmful liquids or

ignitable materials or explode causing injury

and product damage

- Do not mix old and new or other battery types

- Replace all batteries at the same time

- Replace fully discharged batteries immediately

FCC Warning

Any unauthorized changes or modiﬁcations to the equipment

would void the user’s warranty and may conﬂict with both

state and federal laws. The Choice Alert system complies with

part 15 of the FCC rules. Operation is subject to the following

conditions:

1) The Choice Alert system may not cause

harmful interference.

2) The Choice Alert system may accept any interference

received including interference that may cause

undesired operation.

NOTE: This equipment has been tested and found to

comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more

of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment

and receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver

is connected.

– Consult the dealer or an

experienced radio/TV technician for help
