Fuji Xerox DocuPrint P225 d User manual

Unpack the machine and check the components

Read the Safety Guide first, then read this Quick Setup Guide for the correct installation

procedure.

NOTE:

• The components included in the box and the AC power plug may differ depending on your

country.

• The available connection interfaces vary depending on the model.

• The illustrations in this Quick Setup Guide are based on the DocuPrint P265 dw.

• The USB cable is a standard accessory.

Network cable

Use a straight-through Category 5 (or greater) twisted-pair cable for 10BASE-T or

100BASE-TX Fast Ethernet Network.

Remove the packing materials and install the toner cartridge

Load paper in the paper tray

Connect the machine to your computer/mobile device

Connect the power cord and turn on the machine

Select your language (Only for certain models)

Drum Unit

(Pre-installed)

AC Power Cord

(only for certain models)

Quick Setup Guide

USB Interface Cable Inbox/Starter Toner

Cartridge

CD‑ROM Safety Guide

1. Press ▼ or ▲ to select General Setup, and then press OK.

2. Press OK to select Local Language.

3. Press ▼ or ▲ to select your language, and then press OK.

Adjust the paper guides.

• Windows®PC with a CD-ROM drive, go to step 5A

• Windows®PC without a CD-ROM drive, go to step 5B

• Macintosh, go to step 5B

• Mobile device users with a WPS/AOSS-supported access point/router, go to step 5C

Back Front

Remove the orange part. Remove the orange part.

Quick Setup Guide

DocuPrint P225 d / DocuPrint P265 dw

LJB476001-00

604E 77060 MB3547E2-1 (Edition 1)

September 2014

Fuji Xerox Co., Ltd. Printed in Vietnam

Configuration using the CD-ROM (Windows®)

Follow the on-screen

instructions until the

Connection Type screen

appears.

Finish

Download the full driver and software package by visiting the Fuji Xerox website at http://www.fujixeroxprinters.com/.

After you download the driver and software package, follow the on-screen instructions until the Connection Type screen appears. Refer to 5A Configuration using the CD-ROM

(Windows®).

If your wireless LAN access point/router supports automatic wireless (one-push) setup (WPS/AOSS™), you can set up your machine without using a computer.

Connection Type

For USB Connection

For Wired Network Connection

Connect a network cable first.

For Wireless Network Connection

We recommend preparing a USB cable

to use temporarily during the wireless

setup.

Follow the on-screen

instructions to continue

installation.

NOTE:

If connection is unsuccessful, repeat this step.

One-push wireless setup for mobile devices (Wireless models only)

Wireless Network Connection

[Recommended]

Select this option if you have a USB cable to

use temporarily for wireless setup.

Select this option if you do not have a USB cable.

Follow the on-screen

instructions to continue

installation.

NOTE:

If connection is unsuccessful, repeat this step.

Configuration without using the CD-ROM (Windows®without CD-ROM drive or Macintosh)

Wireless setup is now complete.

Finish

Press the WPS or AOSS™ button on your

wireless LAN access point/router.

Press the WiFi button on your machine.

NOTE:

If the Fuji Xerox screen does not appear automatically, go to Computer.

(For Windows®8: click the (File Explorer) icon on the taskbar, and then go to Computer.)

Double-click the CD-ROM icon, and then double-click start.exe.

604E 77060 MB3547E2-1 LJB476001-00
