Frigidaire FFHP093WS2 User manual

Refer to Page 2 for table of contents.

www.frigidaire.com USA 1-866-942-1567 www.frigidaire.ca Canada 1-866-942-1567

2020323B2335 (June 2009)

All about the

Installation

of your

Split Type Room Air Conditioner

Welcome

Welcome to the world of

simple handling and no worries

Environmental advices

Attention!!

Thank you for choosing Frigidaire. This manual contains all of the information

required to guarantee your safety and the appropriate use of your air

conditioner.

Please read all of the instructions before using the air conditioner and keep

this manual for future reference.

We know you will enjoy your new air conditioner and thank you for choosing

our product.

We hope you will consider us for future purchases.

The packaging material used is recyclable. We

recommend that you separate plastic, paper and

cardboard and give them to recycling companies.

If you need to dispose of this appliance in the

future, do not throw it away with the rest of your

domestic garbage.

The air conditioner that you have bought may be slightly different from

the one illustrated in this manual. Please refer to the information related

to the model you have.

This air conditioner is for domestic use only. It is not recommended for

heavy commercial or industrial use.

Contents

01. Welcome..........................................................................................01

02. Environmental advices........................................................................01

03. Contents...........................................................................................02

04. Safety precautions.............................................................................03

05. Installation:

5.1 Choosing the installation site.................................................04

5.2 Parts list..............................................................................06

5.3 Indoor unit installation..........................................................08

5.4 Outdoor unit installation.......................................................12

5.5 Refrigerant piping connection................................................14

5.6 Electrical work.....................................................................16

5.7 Purging the system...............................................................20

5.8 Electrical safety....................................................................23

5.9 Gas leak check....................................................................23

5.10 Initial operation test..............................................................24

Satety precautions

Safety precautions

This appliance must be installed by a qualified licensed HVAC

technician in accordance with all applicable codes. All electrical

connections should be performed by a licensed electrician.

Manufacturer's warranty will be voided with failure to comply.

Incorrect Handling could result in Serious Injury or Death!

1. Do not attempt to install the split air

conditioner by yourself.

2. This air conditioner contains no

user-serviceable parts. Always call

an authorized Electrolux servicer

for repairs.

3. When moving the air conditioner,

always call an authorized Frigidaire

servicer for disconnection and re-

installation.

4. Do not insert fingers or place

objects into the discharge area in

the front of the indoor unit.

5. Do not insert fingers or place

objects into the discharge area in

the front of the outdoor unit.

6. Do not start or stop the air

conditioner by turning off the power

at the electrical box.

7. In the event of a malfunction (sparks,

burning smell, etc.) immediately

power off unit and call an

authorized Frigidaire servicer.

8. Do not operate the air conditioner

with wet hands.

9. Do not drink any water or

condensation that is drained from

the air conditioner.

.Provide occasional ventilation

during use. Do not direct airflow

at fire places or other heat related

sources as this could cause flare

ups or make units run excessively.

11. Do not climb on or place objects

on the outdoor unit.

12. Do not hang objects off the indoor

unit.

13. Do not place objects containing

water on the indoor and/or

outdoor units.

14. Turn off the air conditioner at the

power source when it will not be

used for an extended period of

time.

15. Periodically check the condition of

the outdoor unit’s installation base

for any damage.

16. Do not apply heavy pressure to

the coil fins of the indoor and/or

outdoor units.

17. Operate the indoor unit with air

filters in place.

18. Do not block or cover the intake

grille, discharge area and outlet

ports.

19. Ensure that any electrical/

electronic equipment is 36” away

from the indoor unit and outdoor

unit.

20. Do not use or store flammable

gases near the indoor and/or

outdoor units.

Choosing the installation site 04

Choosing the installation site

Installation Warnings

1. Carefully read the installation manual before beginning.

2. Follow each step as shown.

3. Observe all local, state and national electric codes. This appliance must

be installed by a qualified licensed HVAC technician in accordance with

all applicable codes. All electrical connections should be performed

by a licensed electrician. Failure to comply will result in a void of the

manufacturer's warranty.

4. Pay attention to all safety notices.

Precautions for Installation

Installation at the following sites may cause problems. If you must inevitably

install the unit at one of these sites, please consult your local distributor

beforehand:

1. Sites with machine oil.

2. Sites with a high concentration of salinity, such as coastal areas.

3. Sites with sulfuric gas, such as hot water springs.

4. Sites with high frequency equipment, such as wireless equipment, welding

machines and medical installations.

5. Sites with flammable gases or volatile material.

6. Sites with special environmental conditions.

7. Laundry rooms.

05 Choosing the installation site

Indoor Unit

1. Install unit where air flow will not

be obstructed.

2. The installation location must

support the weight of the indoor

unit.

3. The site must be easily accessible

for maintenance and replacement

of the air filter.

4. The installation location must allow

for the necessary space around the

indoor unit, as shown in the figure

1.1.

5. There should be at least 3 feet (1

meter) between the unit and radio

or television devices. It is ideal that

the unit be installed at the center of

the wall.

6. The indoor unit must be kept away

from fire, smoke and flammable

gases.

Outdoor Unit

1. The outdoor unit must be installed

at a convenient site that is not

exposed to strong winds. The site

should be dry and well ventilated.

2. The site must support the weight

of the outdoor unit and allow for

vertical installation.

3. The site must be kept away from

flammable gases.

4. The site must provide enough space

around the unit, as shown in figure

1.2.

5. Children must not be able to access

the installation site.

7. We recommend the indoor unit to

be installed as high up as possible

on the inside wall (minimum of 7

feet high), always leaving a space

of at least 6" between the top of the

indoor unit and the ceiling.

8. The installation location must

allow for the easy removal of the

connector pipe and drain hose.

9. The unit must be installed at a

location protected from direct

sunlight.

than 6"

than 12" than 8.5"

than 2"

than 12"

than 18.5"

than 78"

Figure 1.1

Figure 1.2

Part list

Tools needs for installation

1. Level gauge

2. Screw driver

3. Electric drill

4. Hole core drill (ø55mm /

ø70mm)

5. Flaring tool set

6. Specied torque wrenches

7. Spanner (half union)

8. A glass of water

9. Hexagonal wrench (4mm)

10. Gas-leak detector

11. Vacuum pump

12. Gauge manifold

13. Users manual

14. Thermometer

15. Multimeter

16. Pipe cutter

17. Measuring tape

Accessories

Number Name of Accessories Quantity

Indoor unit mounting plate 1

Clip anchor Not supplied

Self-tapping screw A ST3.9X25 5-8

Remote control 1

Remote control holder (Optional) 1

Screw for remote holder ST2.9X10 (Optional) 2

Battery (AAA 1.5V) 2

Insulation material Not supplied

Connection piping assembly(Optional) 1

Insulation hose for refrigerant piping Not supplied

Drain hose Not supplied

Wall clamp Not supplied

Connection power cable Not supplied

Drain connector (Heat Pump model only) 1

Drain plug (Heat Pump model only) (Optional) 2-3

Thermal insulating pipe for extending drain hose 1

Flare nut (for suction pipe) (Optional) 1

Flare nut (for liquid pipe) (Optional) 1

Note: Other necessary parts for the installation, besides the above mentioned, must

be provided by the customer/installer.

Part Lists

Part list

Product Description

NOTE

All the pictures in this manual are for explanation purposes only. The actual

shape of the indoor unit you purchased may be slight different on front panel

and display window.The actual shape shall prevail.

15cm above

Space to the wall

Space to obstruction

30cm above

2m above

Air outlet side

Air inlet side

30cm above

50cm above

Space to the wall

Space to the ceiling

15cm above

Space to the wall

3m above

Air outlet side

Space to the wall

Indoor

Unit

50cm above

1 23

Indoor unit installation

Wall mounting brackets and dimensions

Indoor unit outline

Wall mounting bracket

the ceiling

from the wall from the wall

Refrigerant pipe

6" or more from

6" or more

hole (right) Ø 2.56"

6" or more

3.39"

4.21"

%WXV$%

3.39"

4.21"

Refrigerant pipe

hole (right) Ø 2.56"

1.58''

7.91'' 5.31''

1.58''

the ceiling

6" or more from

=18000 Btu's (A:36.97" B:11.73")

Refrigerant pipe

hole (right) Ø 2.56"

from the wall

6" or more

Wall mounting bracket

Refrigerant pipe

hole (right) Ø 2.56"

Indoor unit outline

from the wall

6" or more

1.97'' 1.97''

3.94'' 4.88''

=22000 Btu's (A:39.69" B:12.40")

Refrigerant pipe

hole (right) Ø 2.56"

from the wall

6" or more

Wall mounting bracket

the ceiling

6" or more from

Refrigerant pipe

hole (right) Ø 2.56"

Indoor unit outline

from the wall

6" or more

09 Indoor unit installation

1.97'' 1.97''

3.94'' 4.88''

%WXV $%

5HIULJHUDQWSLSH

KROHULJKW

IURPWKHZDOO

RUPRUH

:DOOPRXQWLQJEUDFNHW

WKHFHLOLQJ

RUPRUHIUom

5HIULJHUDQWSLSH

KROHULJKW

,QGRRUXQLWRXWOLQH

IURPWKHZDOO

RUPRUH

Installing the Wall Mounting Bracket

Drilling the Hole

1. Install the wall mounting bracket

horizontally over the structural

parts on the wall using the spaces

indicated on the bracket, as shown

in figure 1.3.

2. In the case of tiled, concrete or

similar walls, create 13/64"

diameter holes. Place anchor

supports for the appropriate

assembly screws.

3. Install the wall mounting bracket to

1. Determine the position of the

hole for the pipes using the wall

mounting bracket and drill the

pipe hole so that it is tilted slightly

downward.

2. Always use a pipe cover with an

opening when drilling.

Wall mounting bracket

Wall

Indoor unit Outdoor unit

0.2"-0.

28"

Attention!!!

Fit the wall mounting bracket and drill holes in the wall according to the

wall structure and corresponding mounting points on the wall mounting

bracket (Dimensions are in “inches” unless otherwise stated).

the wall with eight A type screws.

4. At all times securing to the wall

studs is recommended.

Figure 1.3

This manual suits for next models

Table of contents

Other Frigidaire Air Conditioner manuals

Frigidaire

Frigidaire FRS12PYS1 Installation instructions

Frigidaire

Frigidaire FAS184J2A5 User manual

Frigidaire

Frigidaire FAA063M7A1 User manual

Frigidaire

Frigidaire FAA062P7 User manual

Frigidaire

Frigidaire FRA122BU1 Installation instructions

Frigidaire

Frigidaire ELECTRONIC CONTROL AIR CONDITIONER User manual

Frigidaire

Frigidaire FAS155J1A1 User manual

Frigidaire

Frigidaire FRS123LS1 Installation instructions

Frigidaire

Frigidaire FRS093LS1 Installation instructions

Frigidaire

Frigidaire FRA106CV1 User manual

Frigidaire

Frigidaire FAH10EM2T1 Quick start guide

Frigidaire

Frigidaire FAX050S7A14 User manual

Frigidaire

Frigidaire FFRA0522R1 Owner's manual

Frigidaire

Frigidaire FAS156N1A Quick start guide

Frigidaire

Frigidaire FRA065AT7 Installation instructions

Frigidaire

Frigidaire CRA084KT711 Owner's manual

Frigidaire

Frigidaire FAK104R1V 10,000 User manual

Frigidaire

Frigidaire FRA064VU1 Owner's manual

Frigidaire

Frigidaire LRA107BU113 Owner's manual

Frigidaire

Frigidaire FAS25EQ2A2 Quick start guide

Frigidaire

Frigidaire LRA107CV114 Instruction Manual

Frigidaire

Frigidaire FRA054XT7 Owner's manual

Frigidaire

Frigidaire FFMS121CQ10 User manual

Frigidaire

Frigidaire FAP094P1Z - 9,000-BTU Portable Air... User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Samsung

Samsung AS09HM3N user manual

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual

Webasto

Webasto Frigo Top 25 DS Instructions for use

Mitsubishi Electric

Mitsubishi Electric MSC-GE20VB operating instructions
