Friedrich QuietMaster SL28L30 User manual

QuietMaster Programmable

Room Air Conditioners

PURCHASER P.O. # DATE

PROJECT LOCATION

ENGINEER ARCHITECT

SUBMITTED BY FOR APPROVAL FOR REFERENCE

ITEM PLAN DESIGNATION QUANTITY COOLING BTU/H VOLTAGE FRIEDRICH MODEL

QUITEMASTER_PROGRAMMABLE_SUBMITTAL_08

DIGITAL CONTROL FEATURES

• 24-hour timer lets you program on/o times

• 4-speed fan with ultraquiet “Sleep Setting”

• Smart Fan adjusts fan speed to maintain desired temperature

• Unique Comfortwatch technology

• MoneySaver® setting saves energy by cycling the fan with the

compressor

• Memory backup saves settings if power is interrupted

• Check lter reminder light

DELUXE FEATURES

• Ultraquiet operation

• 8-way air ow control

• Fresh air intake/ stale air exhaust vents

• Washable, antimicrobial lter for protection against fungal and

bacterial growth

• Slide-out chassis for more permanent window or

wall installation

8,400 to 23,500 BTU/h EERs up to 12.0

FI T S W I N D O W S – M I N I M U M : 27 7/ 8 ” W I D E . M A X IM U M : 4 2 ” W I D E

ONE TOUCH

OPER ATION

REMOTE

CONTROL

24 HR.

TIMER

MONEY SAVER

FEATURE

SMART

FAN

ANTIMICROBIAL

FILTER

SLIDE-OUT

CHASSIS

FI T S W I N D O W S – M I N I M U M : 27 7/ 8 ” W I D E . M A X IM U M : 4 2 ” W I D E

FULL SIZE FOR MORE PERMANENT INSTALLATION | 8,400 to 23,500 BTU/h EERs up to 12.0

Model

Circuit Rating

Breaker or

T-D Fuse

Plug Face

(NEMA#)

Wall Outlet

Appearance

SS08L10, SS10L10, SS12L10 and SS14L10. 125V - 15A 5 - 15P

SS12L30, SS16L30, SM18L30A and SM21L30. 250V - 15A 6 - 15P

SM24L30 and SL28L30 250V - 20A 6 - 20P

Installation Information / Sleeve Dimensions

Circuit Rating/ Breaker

The consumer- through the AHAM Room Air Conditioner Certification Program- can be certain that the AHAM Certification Seal accurately

states the unit’s cooling and heating capacity rating, the amperes and the energy efficiency ratio.

Specications

 As an ENERGY STAR® partner, Friedrich Air Conditioning Co. has determined that the selected ENERGY STAR®() models meet the ENERGY STAR®guidelines for energy efficiency.

ENERGY STAR® Models

Sleeve Height Width

Depth

with Front

Depth

Hood to

Louvers

Minimum

Extension

Into Room

Minimum

Extension

Outside

Window Width

Thru-the-wall

Finished Hole

Minimum Maximum Height Width

S15 15∕16" 25 15∕16" 27 3∕8" 8 ¾" 3 1∕16" 16 15∕16" 27 7∕8" 42" 16 3∕16" 26 3∕16"

M17 15∕16" 25 15∕16" 27 3∕8" 8 ¾" 3 1∕16" 16 15∕16" 27 7∕8" 42" 18 3∕16" 26 3∕16"

Cooling

Capacity

BTU/h

Heating

Capacity

Rated

Electrical Characteristics (60 Hertz) Energy

Efficiency

Ratio

EER

Moisture

Removal

Pints/Hr.

Room Side

Air Circulation

CFM Sleeve*

Net

Weight

Lbs.Model

Volts

Rated

Cooling

Amps

Cooling

Watts

Heating

Amps

Heating

Watts

COMMERCIAL GRADE

QUIETMASTER Programmable

SS08L10 8400 — 115 6.6 737 — — 11.4 1.6 265 S 108

SS10L10 10400 — 115 7.5 867 — — 12.0 2.5 260 S 115

SS12L10 11800 — 115 9.0 1000 — — 11.8 2.5 350 S 114

SS14L10 14000 — 115 12.0 1305 — — 10.7 3.5 377 S 128

SS12L30 12100/11900 — 230/208 4.8/5.0 1052/1017 — — 11.5/11.7 2.9 320 S 114

SS16L30 16200/15900 — 230/208 7.4/8.0 1653/1656 — — 9.8/9.6 4.7 360 S 119

SM18L30A 17500/17300 — 230/208 7.2/7.7 1620/1570 — — 10.8/10.8 4.5 375 M 163

SM21L30 20600/20200 — 230/208 9.4/10.1 2081/2020 — — 9.9/10.0 6.0 425 M 154

SM24L30 23500/23000 — 230/208 11.2/12.1 2479/2421 — — 9.5/9.5 7.0 400 M 154

Friedrich room air conditioners are designed to operate in outdoor temperatures from 50° F to 115°F.

Due to continuing research in new energy-saving technology, specifications are subject to change without notice.
