Franke FF6000 User manual
KITCHEN
SYSTEMS
FF6000 . FF7000
INSTRUCTION MANUAL
Franke Consumer Products, Inc., Kitchen Systems Division extends the following
warranty to the original purchaser of its faucets effective January 1, 2003.
All faucets installed in a private residence will carry a limited lifetime warranty on all
mechanical parts to be free of manufacturing defects in material and workmanship
under normal usage. All chrome finishes carry a limited lifetime warranty; all other
finishes are warranted for five (5) years form the original date of purchase.
This warranty applies only to the original owner, providing the product has been
installed in accordance with our installation instructions, used as recommended and in
a normal residential application. In the event of a warranty claim, the owner will be
required to provide proof of purchase - save sales receipt. This warranty covers all
components which make the product operational. Franke, at its option, may repair or
replace the product or components necessary to restore the product to good working
condition. Franke reserves the right to inspect the installation prior to the actual
replacement of the product or component part.
This warranty does not cover misuse or abuse, accidental damages, scuffs or scratches,
improper installation, abnormal usage, negligence or damage caused by improper
maintenance or cleaning. Normal wear of parts is excluded from the warranty. Damage
caused by impurities or acts beyond our control are not covered. Any product or part
which has been repaired or altered in any manner outside of Franke's factory, unless
previously authorized in writing by Franke, will void warranty. Any replacement
excludes transportation and any labor re-installation costs. This warranty does not
allow recovery of incidental or consequential damages such as loss of use, delay,
property damage or other consequential damage, and Franke accepts no liability for
such damages.
The Franke warranty is limited to the above conditions and to the warranty period
specified herein and is exclusive. Franke DISCLAIMS all other warranties, expressed
or implied, including IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR
FITNESS FOR AS PARTICULAR PURPOSE. This warranty gives you specific legal
rights that may vary from state to state.
Further information
For any further information about our products, about the installation of them or about
the guarantee, please dial the number of the customer service:
Phone number +1-215-822-6590 Franke Consumer Products Inc. - Kitchen Systems Division
Or: 1-800-626-5771 3050 Campus Drive, Suite Hatfield, PA 19440
Fax number + 1-215-822-5873
8/8
LIMITED LIFETIME WARRANTY
InstallationGuide(Print)-FF6000&FF7000_I
2/8
ENGLISH
7/8
1. Remove all contents from the package and check for completeness. NOTE:
Product comes pre-assembled.
NOTE:
Call us immediately if you see inconsistencies.
(1-800-626-5771)
or visit
www.frankeksd.com
FAUCET INSTALLATION
1
2
45
3
CONTENTS IN BOX
1 Faucet
2 Sidespray Assembly
3 Diverter Connection
4 Tee Valve & Diverter
5 Mounting Nut
Standard water flow 1.5 gpm - 45 PSI
Maximum water flow 2.2 gpm - 60 PSI
Recommended pressure range 25-100 PSI - Over 100 PSI PRV required
Complies with Proposition 65, NSF 61, UPC and C-UPC requirements
TECHNICAL DATA SPARE / REPLACEMENT PARTS LIST - FF7000
1 Cartridge Cold, Lead Free
2 Cartridge Hot, Lead Free
3 Banjo Diverting Locknut
4 Aerator 2.2 GPM (For Aerator 1.5 GPM = 10560)
Handle, Standard Lever Lalingua
Handle, Decorative Lalingua
Tee Body & Diverter
Sidespray Head & Grip
Diverting Hose & Banjo Fitting
Valve Body & Connection Hoses
Locknut for Faucet
10210
10211
10418
10698
3-021 *
3-022 *
3-033
3-034 *
3-047
3-048
92038
5
6
7
8
9
10
11
Locknut for Sidespray92037
12
Hose for Sidespray10564
13
Sidespray Base Shank10406 *
14
Escutcheon Flange10407 *
15
Bridge Faucet Sealing Kit3-058
16
*NOTE: Specify color finish when
ordering replacement parts
1
4
5
6
10
11
15
14
13
16
12
16
2
3
7
9
16
16
16
8
16
Aerator 2.2 GPM (For Aerator 1.5 GPM = 10560)
3/86/8
SPARE / REPLACEMENT PARTS LIST - FF6000
1 Cartridge Cold, Lead Free
2 Cartridge Hot, Lead Free
3
4
Handle, Standard Lever Swan
Handle, Decorative Swan
Tee Body & Diverter
Sidespray Head & Grip
Diverting Hose & Banjo Fitting
Valve Body & Connection Hoses
Locknut for Faucet
10210
10211
10418
10698
3-019 *
3-020 *
3-033
3-034 *
3-047
3-048
92038
5
6
7
8
9
10
11
2. Flush pipe work to ensure it is free from debris.
3. Cut mounting holes 1 3/8" diameter (8” center-to-center spread requirement for
faucet) in the desired position in sink.
4. Remove faucet and hardware from its protective packaging. Faucet comes
assembled.
8. Place the escutcheons (for FF6000) and large 'O'rings (for FF6000 and/or FF7000)
over the faucet shanks and place the faucet into the desired position.
ATTENTION: The rubber ‘O’ring should be sitting on top of the countertop and
between the faucet escutcheons. DO NOT use putty or other sealant at this location.
NOTES:
Solid surface installation: The sub-countertop mounting surface needs to be flat and
free of debris; otherwise the faucet will not sit properly.
Tile installation: Avoid installations near or on top of grout lines. The faucet will not sit
secure when sitting on such.
5. Detach hose fittings from tee body, temporarily remove locknut from diverting side.
6. Slide banjo fitting down from its location.
7. Unscrew plastic mounting nuts from the faucet shanks.
9. Assure that the handles and spout are properly aligned in correct positions; spout
should swivel face forward into sink and handles should point outward parallel with
bridge faucet. Handles should 1/4" turn towards front of sink (counter-clockwise
1/4" turn for hot side & clockwise 1/4" turn for cold side).
10. Slide plastic mounting nuts over supply lines. Install the plastic mounting nuts to
the threaded shanks from underneath the sink.
11. Tighten plastic mounting nuts with required plumbers wrench (1 7/16" size).
12. Slide banjo-divert fitting over the cold side supply lines followed with the thread
brass locknut into its location. Ensure fitting hose is positioned between both
shanks and fitting hose turns downwards inline with other supply lines.
13. Tighten threaded brass locknut with required plumbers wrench (1 7/16" size).
Escutcheon
‘O’ Ring
*NOTE: Specify color finish when
ordering replacement parts
Banjo Diverting Locknut
Locknut for Sidespray92037
12
Hose for Sidespray10564
13
Sidespray Base Shank10406 *
14
Escutcheon Flange10407 *
15
Bridge Faucet Sealing Kit3-058
16
1
2
3
4
5
6
7
9
10
11
8
15
14
13
16
12
16
16
16
16
4/8 5/8
STANDARD MAINTENANCE AND
TROUBLE SHOOTING
CLEANING OF THE SPRAY HEAD
Any deposits which may accumulate on the nozzle can be removed by simply running
a finger over the face of the sprayer and then running the water for a few seconds.
In extreme cases this step may have to be repeated.
REPLACING THE CARTRIDGE
1. Shut off the water supply to the faucet.
2. Open the faucet briefly to relieve any pressure
inside the faucet.
3. Move the faucet handles to the “OFF” position.
5. Disconnect supply lines from angle wall valves
and from diverting tee.
6. Use an adjustable wrench to untighten bottom valve
body.
7. Remove cartridge from valve body seat.
8. Install the new cartridges into valve body.
13. Re-assemble faucet in reverse order.
14. Test for leakage.
GENERAL MAINTENANCE
Clean aerator periodically.
Do not use harsh detergents, solvents, chemical agents, metallic sponges, etc. that could
harm the surface and damage the finish.
Clean only with a soft sponge and soapy water.
REQUIRED TOOLS:
17mm Socket Wrench
3/4” Wrench
14. Connect and tighten shorter supply hoses onto diverter-tee. Use open end wrench.
15. Next, install the sidespray assembly by installing rubber gasket & escutcheon
flange along with base shank into 1-3/8” mounting hole.
16. From underneath the sink, install plastic mounting nut onto base shank until fully
tightened.
17. Set sidespray into place. Insert spray hose into base.
18. Install and tighten end of hose onto diverter (M15 fitting).
19. Connect the inlet supply lines to the angle stop wall valves. Do not allow the
supply tubes to twist or bend sharply.
20. Open faucet handle - cold side first - by turning handle clockwise. Let the faucet
run on cold for 15 to 30 seconds.
21. Turn off cold side handle.
22. Open faucet handle - hot side second - by turning handle counter-clockwise. Let the
faucet run on hot for 15 to 30 seconds.
23. Open both faucet handles. Let the faucet run for 15 to 30 seconds.
24. Pull sidespray hose out of its base and point the open end towards the sink drain.
25. Let the sidespray run for 15 to 30 seconds. When sidespray is depressed, ensure
spout turns off and turns back on when spray is not in use.
26. Turn faucet off.
27. Check / test for leaks under the cabinet.
Banjo Fitting
Sidespray Hose
