Franke FAID100 User manual

Installation and operating instructions Istruzioni per il montaggio e l’uso

Notice de montage et de mise en service Montage- en bedrijfsinstructies

Instrucciones de montaje y uso Návod pro montáž a provoz

Istruzioni per il montaggio e l’uso Asennus- ja käyttöohje

Montage- en bedrijfsinstructies Инструкция по монтажу ивводу в

эксплуатацию

ZMI_001_2000101100-FAID100_#SALL_#AQU_#V8.fm / 27.01.14

EA-Nr.: 7612982001291

FAR-Best.-Nr.: 2000101100

FAID100

EA-Nr.: 7612982001307

FAR-Best.-Nr.: 2000101101

FAID101

EA-Nr.: 7612982001789

FAR-Best.-Nr.: 2000105425

FAID102

EA-Nr.: 7612982001314

FAR-Best.-Nr.: 2000101102

FAID103

Inhaltsverzeichnis35.fm

- 2 -

...................................................................................... 3

Please refer to the graphics in the German Installation and

Operating Instructions.

...................................................................................... 11

Les graphiques sont disponibles dans la notice de montage et de

mise en service allemande.

...................................................................................... 19

Por favor, consulte los gráficos en las instrucciones alemanas de

montaje y uso.

...................................................................................... 27

Per le grafiche fare riferimento alle Istruzioni per il montaggio e

l’uso in tedesco.

...................................................................................... 35

De tekeningen kunt u in de Duitse montage- en bedrijfsinst-

ructies vinden.

...................................................................................... 43

Prosimy przyjąć grafikęz niemieckiej instrukcji montażu i

obsługi.

...................................................................................... 51

Bilderna finns i den tyska monterings- och bruksanvisningen.

...................................................................................... 59

Obrázky najdete v nìmeckém návodu k montáži a obsluze.

...................................................................................... 67

Kuvat löydätte saksankielisestä asennus- ja käyttöohjeesta.

...................................................................................... 75

Рисунки приведены винструкции по монтажу иэксплуатации

на немецком языке.

- 3 -

ZMI_001_2000101100-FAID100_#SEN_#AQU_#V8.fm

0English

FAID100 ..................... Table mounting

FAID101 ..................... Wall mounting

FAID102 ..................... Wall-mounting to laboratory furniture

FAID103 ..................... Wall-mounting with spiral hose

Please refer to the graphics in the German Installation and Operating Instructions.

0Table of Contents

1. Abbreviations and units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2. Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4. Important notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Description of product

5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

6. Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

7. Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

8. Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

9. Installation example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Assembly, function and commissioning

10. Table installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

11. Wall-mounted assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

12. Assembly with wall feedthrough . . . . . . . . . . . . . . . . . . . . . . . . . . 7

13. Wall-mounted assembly with spiral hose . . . . . . . . . . . . . . . . . . . 7

14. Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Maintenance

15. Maintenance and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

16. Replacing a filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

17. Replacing the flow rate regulator . . . . . . . . . . . . . . . . . . . . . . . . . 9

18. Replace the non-return valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

19. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

20. Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

ZMI_001_2000101100-FAID100_#SEN_#AQU_#V8.fm

- 4 -

1. Abbreviations and units

2. Key

Warning!

Failure to observe can result in bodily injury or even death.

Caution!

Failure to observe can result in material damage.

☞Important!

Failure to observe can cause the product to malfunction.

☞Useful information for optimal handling of the product.

3. Warranty

Liability is accepted in accordance with the General Terms and Conditions of

Business and Supply.

Use original spare parts only!

4. Important notes

• Installation, commissioning and maintenance are to be performed only by a

qualified expert in accordance with the provided instructions, legal requirements,

and the recognised engineering standards.

• All technical connection regulations specified by the local water and electricity

supply companies must be observed.

• The eye shower contains an uncontrolled non-return valve according to

DIN EN 1717. Depending on the place of installation and the expected water flow

category, the customer may have to provide additional safety facilities.

• We reserve the right to make changes.

5. Application

Emergency showers are prescribed first aid installations for work stations where

hazardous materials are being handled.

EA-Nr. International article number

FAR-Best.-Nr. Franke Aquarotter order number

Conversion 1 mm = 0.03937 inches

1 inch = 25.4 mm

All length specifications in the graphics are in mm.

- 5 -

ZMI_001_2000101100-FAID100_#SEN_#AQU_#V8.fm

6. Technical specifications

7. Scope of delivery

8. Dimensions

9. Installation example

Version: Hand shower, plastic, green/white, with table

mounting (EPS-coated brass) or plastic wall

mounting, 20° tilted forward,

with stainless steel-coated or spiral water supply

hose,

safety cap with user instructions

Connection: Cap nut G 3/8

Table feedthrough: M 28 × 1.5; length 80 mm; and fastening nut

Minimum flow

pressure:

1 bar

Flow pressure area: 1-4 bar

This area meets the requirements of EN 15154.

Volumetric flow: 6-9 l/min at a flow pressure of 1 bar

FAR-Best.-Nr. Positions Pos. Name

2000101100 1, 2, 6, x 1 Eye shower with safety cap

2000101101 1, 3, 6, x 2 Table mounting with attachment set

2000105425 1, 3, 4, 6, x 3 Wall mounting with attachment set

2000101102 1, 3, 5, 7, x 4 Wall feedthrough

5 Spiral supply hose with filter

6 Connection hose with filter, seal

7 Connection bracket with rosette

x Sticker with first-aid sign - eye

shower

x Installation and operating instructions

ZMI_001_2000101100-FAID100_#SEN_#AQU_#V8.fm

- 6 -

10. Table installation

☞Important!

• Prior to the assembly process, flush the pipework in accordance with DIN 1988.

• Mount the emergency shower in accordance with EN 15154 Part 2.

10.1

Mount the table mounting (a) on the table top (b).

10.2

Connect the eye shower (c) to the seal and the hose (d).

10.3

Insert the hose (d) through the table bracket (a).

Important!

Note the installation position of the filter.

10.4

Insert the filter (f) into the hose (d).

☞The appropriate water connection (e) for the cap nut G 3/8 must be provided by the

customer.

10.5

Screw the hose (d) to the water supply.

10.6

Check the water connection for leaks.

11. Wall-mounted assembly

☞Important!

• Prior to the assembly process, flush the pipework in accordance with DIN 1988.

• Mount the emergency shower in accordance with EN 15154 Part 2.

11.1

Mount the wall bracket (b) to the extension (a).

11.2

Mark the drill holes for the wall bracket at a height (c) of 590 mm to 990 mm from the

upper edge of the finished floor.

11.3

Drill holes in accordance with these markings.

11.4

Insert the wall plugs.

11.5

Mount the extension (a).

11.6

Connect the eye shower (d) to the seal and the hose (f).

11.7

Insert the hose (f) into the wall bracket (b).

11.8

The handle bar (e) must face forwards.

Important!

Note the installation position of the filter.

11.9

Insert the filter (h) into the hose (f).

☞The appropriate water connection (g) for the cap nut G 3/8 must be provided by the

customer.

11.10

Screw the hose (f) to the water supply.

11.11

Check the water connection for leaks.

- 7 -

ZMI_001_2000101100-FAID100_#SEN_#AQU_#V8.fm

12. Assembly with wall feedthrough

☞Important!

• Prior to the assembly process, flush the pipework in accordance with DIN 1988.

• Mount the emergency shower in accordance with EN 15154 Part 2.

12.1

Mounting the wall bracket, see step 11.1 to 11.5.

12.2

Insert the eye shower (a) into the wall bracket (b), see Arbeitsschritt 11.8 to 11.8.

12.3

Mount the wall feedthrough (c) on the perforation provided.

12.4

Insert the hose (d) through the wall feedthrough (c).

Caution!

Note the installation position of the filter (e).

12.5

Insert the filter (e) into the hose.

☞The appropriate water connection (f) for the cap nut G 3/8 must be provided by the

customer.

12.6

Screw the hose (d) to the water supply.

12.7

Check the water connection for leaks.

13. Wall-mounted assembly with spiral hose

☞Important!

• Prior to the assembly process, flush the pipework in accordance with DIN 1988.

• Mount the emergency shower in accordance with EN 15154 Part 2.

13.1

Mounting the wall bracket, see step 11.1 to 11.5.

Caution!

Note the installation position of the filter.

13.2

Insert the filter (b) into the hose (c).

13.3

Connect the eye shower (a) to the hose (c).

13.4

Insert the hose (c) into the wall bracket (e).

13.5

The handle bar (d) must face forwards.

13.6

Fit the connection bracket (f) with the rosette (g) to seal it.

13.7

Screw the hose (c) onto the connection bracket (f), using an open-ended wrench.

13.8

Check the water connection for leaks.

ZMI_001_2000101100-FAID100_#SEN_#AQU_#V8.fm

- 8 -

14. Function

Stationary use

14.1

Press the trigger button.

• The water will flow.

• The safety cap will fall off.

14.2

Press the red stop button.

• The water flow will stop.

☞The fitting is not self-closing. The user can use both hands to keep their eyes open!

Mobile use

☞Depending on the length of the hose, the eye shower can also be pulled out of its

bracket.

15. Maintenance and care

Check once a month that the eye shower is in working order. (Guidelines for Labora-

tories BGI/GUV-I 850-0)

As a preventative measure to reduce microbiological contamination, it is recom-

mended to replace the water in the fitting at shorter intervals by opening the valve.

Use suitable cleaning agents which are not harmful to the fitting in a proper manner

and rinse with water after use. High-pressure cleaners must not be used for

cleaning.

16. Replacing a filter

FAR-Best.-Nr.: 2000101100

2000101101

2000105425

16.1

Close the water supply.

16.2

Loosen the cap nut (b).

16.3

Replace the filter (a).

☞Important!

Note the installation position of the filter.

☞The handle bar (d) must face forwards.

16.4

Reassemble in reverse order.

- 9 -

ZMI_001_2000101100-FAID100_#SEN_#AQU_#V8.fm

FAR-Best.-Nr.: 2000101102

16.5

Close the water supply.

16.6

Take the eye shower (c) out of the wall bracket.

16.7

Loosen the eye shower (c) from the hose (f).

16.8

Replace the filter (e).

☞Important!

Note the installation position of the filter.

☞The handle bar (d) must face forwards.

16.9

Reassemble in reverse order.

17. Replacing the flow rate regulator

17.1

Close the water supply.

17.2

Take the eye shower (a) out of the wall bracket.

17.3

Loosen the hose (b).

17.4

Use a bent wire to lift out the flow volume regulator and replace it.

Caution!

Note the installation position of the non-return valves.

☞Do not forget the seal.

17.5

Reassemble in reverse order.

18. Replace the non-return valve

Caution!

The non-return valve must be replaced every 2 years.

18.1

Loosen the screw (a).

18.2

Remove the shower base (b).

18.3

Remove the spray heads (c) and the seals (d).

18.4

Unscrew the attachment part (e).

18.5

Remove the disc (f).

18.6

Push out the non-return valve (g).

18.7

Reassemble in reverse order.

ZMI_001_2000101100-FAID100_#SEN_#AQU_#V8.fm

- 10 -

19. Troubleshooting

If you cannot rectify a fault or if it is not in the list, please contact our customer

service department!

20. Spare parts

Fault Cause Remedy

Water volume too low – Flow volume regulator faulty ➯Replace it

– Dirty filter ➯Clean it

Description Order No.

1 Hand shower complete . . . . . . . . . . . 2000105863

2 Spray head (packaging unit 4x) . . . . . 2000104725

3 Safety cap

with ball chain. . . . . . . . . . . . . . . . 2000105849

4 Non-return valve

(packaging unit 10x). . . . . . . . . . . 2000104744

5 Flow volume regulator . . . . . . . . . . . . 2000105842

6 Connection pipe. . . . . . . . . . . . . . . . . 2000105845

7 Seal (packaging unit 10x) . . . . . . . . . 2000104668

8 Filter (packaging unit 10x) . . . . . . . . . 2000104702

Maintenance set consisting of:

O-rings . . . . . . . . . . . . . . . . . . . . . 2000105864

FAR-Best.-Nr.: 2000101100

2000101101

2000105425

FAR-Best.-Nr.: 2000101102

Description Order No.

1 Hand shower complete . . . . . . . . . . . 2000105863

2 Spray head (packaging unit 4x) . . . . 2000104725

3 Safety cap

with ball chain . . . . . . . . . . . . . . . 2000105849

4 Non-return valve

(packaging unit 10x) . . . . . . . . . . 2000104744

5 Flow volume regulator. . . . . . . . . . . . 2000105842

6 Filter (packaging unit 10x). . . . . . . . . 2000104732

7 Spiral connection hose . . . . . . . . . . . 2000109548

Maintenance set consisting of:

O-rings. . . . . . . . . . . . . . . . . . . . . 2000105864

Other manuals for FAID100

This manual suits for next models

Table of contents

Languages:

Other Franke Plumbing Product manuals

Franke

Franke AQUA421 User manual

Franke

Franke MARIS FREE Manual

Franke

Franke AQUA420 User manual

Franke

Franke EMERGENCYSHOWERS ZFAID694 User manual

Franke

Franke FMA 2.0 607 User manual

Franke

Franke F5ET2007 User manual

Franke

Franke AQLN0005 User manual

Franke

Franke FS HF SWSP Manual

Franke

Franke RONDA ZANMW0030 User manual

Franke

Franke ACXX2008 2030051217 User manual

Franke

Franke CAMPUS CMPX538 User manual

Franke

Franke 7612982104701 User manual

Franke

Franke AQFU0240 2030064986 User manual

Franke

Franke F5ET2040 User manual

Franke

Franke HELIX User manual

Franke

Franke FAID0002 User manual

Franke

Franke F4 F4LT1002 User manual

Franke

Franke F5EM1006 User manual

Franke

Franke CMPX532WF User manual

Franke

Franke PWC3O0002 User manual

Franke

Franke PROTRONIC-S PRTRS0013 User manual

Franke

Franke MIRANIT F5ST2024 User manual

Franke

Franke FSTP NG 605 X User manual

Franke

Franke ACXX2016 2030057071 User manual

Popular Plumbing Product manuals by other brands

Weka

Weka 506.2020.00E ASSEMBLY, USER AND MAINTENANCE INSTRUCTIONS

Kohler

Kohler K-6228 Installation and care guide

UBERHAUS DESIGN

UBERHAUS DESIGN 75175017 Operator's manual

American Standard

American Standard DetectLink 6072121 manual

Uponor

Uponor Contec TS Mounting instructions

Pfister

Pfister Selia 49-SL Quick installation guide

Fortis

Fortis VITRINA 6068700 quick start guide

Fortis

Fortis MILANO 78211JS installation instructions

Kohler

Kohler K-12183 Homeowner's guide

Maxxus

Maxxus MX-M206-01 instruction manual

Moen

Moen 5922 Series installation instructions

Viega

Viega Prevista Pure 8512 Instructions for use

Kohler

Kohler Centerset K-15240 Homeowner's guide

Viega

Viega Prevista Dry 8522.33 Instructions for use

Sanela

Sanela Lema SLP 59RB Instructions for use

Elkay

Elkay EDF15AC Installation, care & use manual

Hans Grohe

Hans Grohe AXOR Citterio E 36702000 Instructions for use/assembly instructions

baliv

baliv WT-140 manual
