FIC PA-2011 User manual
PA-2011
MAINBOARD
MANUAL
DOC No. : 15739
Rev. : A2
Date : 5, 1997
Part No. : 25-10738-06
Handling Precautions
Warning :
1. Static electricity may cause damage to the integrated circuits on the
mainboard.
Before handling any mainboard outside of its protective packaging,
ensure that there is no static electric charge in your body.
2. There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or an equivalent type recommended by the
manufacturer.
3. Discard used batteries according to the manufacturer’s instructions.
Observe the following basic precautions when handling the mainboard or other
computer components:
■Wear a static wrist strap which fits around your wrist and is connected to a
natural earth ground.
■Touch a grounded or anti-static surface or a metal fixture such as a water
pipe.
■Avoid contacting the components on add-on cards, boards and modules and
with the “gold finger” connectors plugged into the expansion slot. It is best
to handle system components by their mounting bracket.
The above methods prevent static build-up and cause it to be discharged
properly.
Trademark
All trademarks mentioned in this manual are registered properly of the respective owners.
Copyright
This manual may not, in whole or in part, be photocopied, reproduced, transcribed,
translated, or transmitted in whatsoever form without the written the consent of the
manufacturer, except for copies retained by the purchaser for personal archival purposes.
Notice
i
Chapter 1 Overview
Package Checklist....................................................................................... 2
Main Features............................................................................................. 3
Advanced Features ..................................................................................... 5
PC ’97 Compliant ............................................................................. 7
Infrared (IR) Connections................................................................. 8
Highly Convenient Integrated I/O Connectors.................................. 9
Chapter 2 Installation Procedures
Mainboard Layout...................................................................................... 12
1). Set System Jumpers............................................................................... 13
Jumpers............................................................................................. 13
Clear Password: CPW............................................................... 14
Flash EPROM Type Selection: EP1, EP2................................. 14
CPU to SRAM Data Transacting Mode Selection: SRAM....... 15
2). Install System RAM Modules............................................................... 16
DRAM and SDRAM......................................................................... 16
RAM Module Configuration............................................................. 17
Install SIMMs................................................................................... 18
Remove SIMMs................................................................................ 18
Install DIMMs................................................................................... 19
Remove DIMMs ............................................................................... 19
Cache Memory.................................................................................. 20
3). Install the CPUs .................................................................................... 21
CPU External Clock (Bus) Frequency:
CLK1, CLK2, CLK3................................................................. 22
CPU to Bus Frequency Ratio:
FREQ1, FREQ2, FREQ3.......................................................... 23
Intel Pentium CPUs................................................................... 24
Frequency............................................................................. 24
Voltage................................................................................. 25
AMD-K5/K6 CPUs................................................................... 26
Frequency............................................................................. 26
Voltage................................................................................. 27
Cyrix 6x86 CPUs ...................................................................... 28
Frequency............................................................................. 28
Voltage................................................................................. 29
Table of Contents
PA-2011 Mainboard Manual
ii
IBM 6x86 CPUs........................................................................ 30
Frequency............................................................................. 30
Voltage................................................................................. 31
4). Install Expansion Cards......................................................................... 32
5). Connector Cables and Power Supply.................................................... 34
Serial Port Connectors: COM1 and COM2............................... 34
CPU Fan Connector: CPU_FAN .............................................. 34
Floppy Diskette Drive Connector: FLOPPY............................. 35
Infrared Connector: IR.............................................................. 35
Front Panel Block Connector: F_PNL...................................... 36
PS/2 Keyboard Connector: PS2_KB......................................... 37
PS/2 Mouse Connector: PS2_MS............................................. 37
ATX Power Connector: ATX_PWR......................................... 38
Standard Power Supply Connector: AT_PWR.......................... 38
IDE HDD Device Connectors:
PRIMARY and SECONDARY................................................. 39
Printer Connector: PRINTER ................................................... 39
Remote Power Supply Connector: RPW_CON........................ 40
Universal Serial Bus Connectors: USB1 and USB2 ................. 40
Chapter 3 AMI BIOS Setup
Main Setup ................................................................................................. 41
Advanced Setup.......................................................................................... 42
Advanced CMOS Setup.................................................................... 43
Advanced Chipset Setup................................................................... 47
Power Management Setup................................................................. 50
Plug and Play Setup.......................................................................... 53
Peripheral Setup................................................................................ 56
Security Setup............................................................................................. 58
Exit Setup................................................................................................... 60
Installation Procedures
iii
Appendix A BIOS Update Instruction
Flash Process.............................................................................................. 61
Appendix B ICW/PhaseLink Clock Generator
CPU External Clock (Bus) Frequency:
CLK1, CLK2, CLK3.................................................................................. 63
Intel Pentium CPUs.................................................................................... 64
Frequency.............................................................................................. 64
AMD-K5/K6 CPUs.................................................................................... 65
Frequency.............................................................................................. 65
Cyrix 6x86 CPUs........................................................................................ 66
Frequency.............................................................................................. 66
IBM 6x86 CPUs......................................................................................... 67
Frequency.............................................................................................. 67
PA-2011 Mainboard Manual
iv
This Page Intentionally Left Blank
1
Overview
Based on the new highly-integrated VIA 590VP,the PA-2011 combines
blistering Pentiumprocessor performance with support for intelligent
diagnostic and power management features to provide a powerful and versatile
ATX-size platform for leading-edge PC ’97 compliant systems.
With its switching voltage regulator, the PA-2011 runs a complete range of Intel
Pentiumprocessors, including the Intel Pentium processor with MMX
technology, as well as the AMD-K5and Cyrix/IBM 6x86, and is easily
upgradable to the Cyrix/IBM M2 and the AMD-K6. For added power and
performance, the PA-2011 takes up to 512KB Pipeline Burst Level II cache and
up to 512MB DRAM via four-72 SIMM sockets and two 168-pin DIMM sockets
which accept high-speed EDO, and lightning-fast SDRAM memory types.
The PA-2011 comes with a full set of I/O features conveniently integrated on the
rear I/O panel, including two USB connectors. The board also has an integrated
PCI Bus Master Enhanced IDE controller with support for the new Ultra
DMA/33 protocol, which doubles ATA-2 Hard Disk Drive data transfer rates to
33MB/s while maintaining full backwards compatibility with existing PIO Mode
3, PIO Mode 4 and DMA Mode 2 devices.
Fully compliant with the Microsoft PC’97 standard at both the hardware and
BIOS levels, the PA-2011 comes with support for intelligent Hardware
Monitoring and DMI features which continuously check the thermal status of
your system and reduce the cost of ownership through improved manageability.
Chapter 1 of this manual gives you a brief overview of the PA-2011 mainboard,
including its main components and features. Chapter 2 contains advice on how to
upgrade and install key components on the mainboard, while Chapter 3 provides
detailed information about the board’s BIOS settings. For the most up-to-date
information about your mainboard and the latest FAQs and BIOS updates, visit
FIC Online at www.fic.com.tw.
Package Checklist
Please check that your package contains all the items listed below. If you
discover any item is damaged or missing, please contact your vendor.
Chapter 1
PA-2011 Mainboard Manual
2
■The PA-2011 mainboard
■This user manual
■One IDE device cable
■One floppy disk drive cable
Overview
3
Main Features
The PA-2011 mainboard comes with the following high-performance features:
■Easy Installation
AMI BIOS with support for auto-detection of Hard Disk Drives, Plug and
Play devices, and PS/2 keyboard and mouse, to facilitate the installation of
HDDs, expansion cards and other peripheral devices.
■Leading Edge Chipset
VIA 590VP chipset with integrated DRAM and LII cache controllers as well
as support for Intel’s new Dynamic Power Management Architecture
(DPMA), Concurrent PCI (PCI 2.1), and USB.
■Flexible Processor Support
Onboard 321-pin ZIF socket and switching voltage regulator support
complete range of leading-edge processors:
Intel PentiumP55C with MMXtechnology 166/200/233 MHz
processors.
Intel PentiumP54C/P54CS 90/100/120/133/150/166/200 MHz processors.
|||||||||AMD-K6-166 (166 MHz) / K6-200 (200 MHz) / K6-233 (233 MHz)
|||||||| processors.
|||||||||AMD-K5- PR90 (90 MHz) / K5-PR100 (100 MHz) / K5-PR120 (90
|||||||||MHz) / K5-PR133 (100 MHz) / K5-PR150 (105 MHz) / K5-PR166 (116
|||||||||MHz) / K5-PR200 (133 MHz) processors.
Cyrix M2 150/166/200/233 MHz processors.
|| || | Cyrix 6x86- PR133+ (110 MHz) / 6x86-PR150+ (120 MHz) / 6x86-
|||||||||PR166+ (133 MHz) / 6x86-PR200+ (150 MHz) processors.
IBM M2 150/166/200/233 MHz processors.
| IBM 6x86- P133+ (110 MHz) / 6x86-PR150+ (120 MHz) / 6x86-PR166+
(133 MHz) / 6x86-PR200+ (150 MHz) processors.
■Ultra-fast Level II Cache
Supports 256/512KB onboard Pipeline Burst Level II direct-mapped write-
back cache.
■Versatile Main Memory Support
Accepts up to 512MB RAM using four SIMMs of 8, 16, 32, 64, 128MB
with support for FPM and EDO DRAM and two DIMMs of 8, 16, 32, 64,
128MB with support for EDO DRAM and lightning-fast SDRAM.
PA-2011 Mainboard Manual
4
■ISA & PCI Expansion Slots
Four 16-bit ISA and four 32-bit PCI expansion slots provide all the room
you need to install a full range of add-on cards.
■Enhanced PCI Bus Master IDE Controller with Ultra DMA/33 Support
Integrated Enhanced PCI Bus Master IDE controller features two dual-
channel connectors that accept up to four Enhanced IDE devices, including
CD-ROM and Tape Backup Drives, as well as Hard Disk Drives supporting
the new Ultra DMA/33 protocol which doubles data transfer rates to
33MB/sec. Standard PIO Mode 3, PIO Mode 4, and DMA Mode 2 devices
are also supported.
■Super Multi I/O
Integrated SMC669/UMC8669 Plug and Play multi-I/O chipset features two
high-speed 16550A compatible serial ports, one EPP/ECP capable parallel
port, and one FDD connector. COM2 can be configured as an SIR compliant
port for infrared connections.
■USB Support
Two USB ports integrated in the rear I/O panel allow convenient, high-
speed Plug and Play connections to the growing number of USB compliant
external peripheral devices on the market.
■Onboard IrDA Connector
An IrDA connector for wireless infrared connections is available.
Table of contents
Other FIC Motherboard manuals
