Enclume LR12A Instruction manual

LR12A-Fire Center Rack

Enclosed you will find everything needed for the assembly

and use of your storage rack. Two people make assembly

and installation easier. The parts and hardware included are:

Hardware included:

4 – 3/8” x 3/4” Button head screws

4 – 3/8” x ½” Button head screws

1 – Allen wrench

4 – Soft floor glides

Components included:

2 – Arched uprights

2 – Kindling holders

2 – Rectangular newspaper holders

1 – Newspaper support bar

See reverse side for ASSEMBLY AND INSTALLATION INSTRUCTIONS

3/8" x 3/4" BUTTONHEAD SCREW

Thank you for choosing Enclume!

Enclume racks are the ultimate quality,

design, strength and function.

WARNING: READ ALL OF THE

INSTRUCTIONS BEFORE

ASSEMBLING AND USING YOUR

RACK

If you need help, please call 1-877-ENCLUME

Enclume Design Products

24 Colwell Street, Port Hadlock, WA 98339

Phone 360-385-6100 Fax 360-385-6156

www.enclume.com

ASSEMBLY AND INSTALLATION INSTRUCTIONS

Rack Assembly

1) Slip the plastic floor glides over the ends of the arched uprights.

2) Position each rectangular newspaper holder so the threaded hole in the center of one long side is on the bottom,

next to the floor. Using the Allen wrench and the four 3/4” button head screws, attach the holders inside the

arched uprights.

3) Attach the newspaper support bar to the inside of the newspaper holder with two of the ½” button head screws.

The screws should be inserted from the interior of the rack toward the floor. The bar should span the bottom of

the newspaper holder.

4) Attach the kindling holders the arched uprights with the two remaining ½” button head screws.

5) Square up the rack and tighten all the screws.

It is important that your rack is assembled correctly. If the unit is assembled or used incorrectly, it

could become unstable and collapse, possibly causing injury.

WARNING

3/8" x 3/4" BUTTONHEAD SCREW

Limited Warranty: This product is warranted to be free of material defects for a period of five years from the date of purchase. Customer's exclusive remedy shall

be the repair or replacement of the defective product and shall be subject to the following conditions: (1) notice of any defect is received by Enclume within the

warranty period and (2) customer returns the defective product to Enclume Design Products, 24 Colwell St., Port Hadlock, WA 98339, postage prepaid within 20

days following a return authorization number (which may be obtained by telephoning the number at the top of this instructions) being provided to the customer by

Enclume. There are no other warranties, expressed or implied. THERE ARE NO WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. ENCLUME SPECIFICALLY DISCLAIMS ANY AND ALL INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING

OUT OF THE PURCHASE OR USE OF ENCLUME'S PRODUCTS.

3/8" x 3/4" BUTTONHEAD SCREW
